The Mazak VC-PRIMOS 400 L is a compact, high-efficiency vertical machining center designed for precision machining of small to medium-sized components. As part of Mazak’s PRIMOS series, it focuses on simplicity, reliability, and cost-effective performance while maintaining the quality and accuracy associated with Mazak machines. The “L” variant features an extended table, allowing for longer workpieces or multiple part setups, improving flexibility in production environments.
The machine is equipped with a BT40 spindle, typically capable of speeds up to 12,000 RPM, providing a good balance of speed and torque for machining materials such as aluminum, mild steel, and cast iron. The VC-PRIMOS 400 L offers X/Y/Z travels of approximately 700 × 400 × 400 mm and an extended table size of around 1,000 × 400 mm, making it suitable for a wide range of precision components and fixtures.
Its rigid C-frame structure ensures stable machining performance and consistent accuracy, even during longer machining cycles. The machine is typically equipped with a 20- to 30-tool automatic tool changer and Mazak’s MAZATROL SmoothEz CNC control, enabling easy programming and efficient operation. Overall, the VC-PRIMOS 400 L is designed to deliver dependable performance, ease of use, and efficient machining for small to medium production environments.
MAZAK VC-PRIMOS 400 LSPECIFICATIONS
MAZAK VC-PRIMOS 400 L – AXIS
Number of Axes: 3 Axes
Axis Configuration: Vertical Machining Center
Axis Movement Type: Linear X, Y, Z axes
Design: Compact structure optimized for small-part machining
MAZAK VC-PRIMOS 400 L – AXIS TRAVELS
X-Axis Travel: 500 mm
Y-Axis Travel: 400 mm
Z-Axis Travel: 350 mm
Feature: Efficient travel range for precision small components
MAZAK VC-PRIMOS 400 L – CAPACITY
Table Size: 600 mm x 400 mm
Max Workpiece Size: Approx. 500 x 400 x 350 mm
Workpiece Capability: Small to medium precision parts
Load Capacity: Approx. 300 kg
MAZAK VC-PRIMOS 400 L – SPINDLE
Spindle Speed: 12,000 RPM standard (optional 20,000 RPM)
Spindle Taper: BT30
Spindle Power: Approx. 6 – 9 kW
Feature: High-speed compact spindle for efficient machining
MAZAK VC-PRIMOS 400 L – TABLE
Table Size: 600 mm x 400 mm
Table Type: Fixed table
Table Design: T-slot configuration
Feature: Supports fixtures and automation setups
MAZAK VC-PRIMOS 400 L – TOOL TURRET
Tool Magazine Capacity: 14 tools (up to 21 optional)
Tool Holder Type: BT30
Tool Change System: High-speed ATC (armless)
Feature: Fast tool change (~2.6 sec chip-to-chip)
MAZAK VC-PRIMOS 400 L – FEEDRATES
Rapid Traverse Rate: Up to 60 m/min
Cutting Feed Rate: Programmable
Guideways: Linear guideways
Performance: High-speed positioning and smooth motion
MAZAK VC-PRIMOS 400 L – COOLANT & CHIP MANAGEMENT
Coolant System: Flood coolant
Through-Spindle Coolant: Optional
Chip Management: Rear chip disposal system
Feature: Efficient chip evacuation with minimal maintenance space
MAZAK VC-PRIMOS 400 L – CONTROL SYSTEM
CNC Control: MAZATROL SmoothC / Mazak FZ
Programming: Conversational and G-code
Interface: User-friendly control system
Feature: High-speed processing with intuitive operation
MAZAK VC-PRIMOS 400 L – POWER & AIR REQUIREMENTS
Power Supply: 3 Phase industrial power
Power Consumption: Approx. 10 – 15 kW
Air Requirement: Clean compressed air
Air Pressure: Standard industrial pressure
MAZAK VC-PRIMOS 400 L – DIMENSIONS
Machine Footprint: Compact (approx. 1280 mm width)
Machine Weight: Approx. 3,800 kg
Structure: Rigid compact frame
Design: Space-saving for production lines
MAZAK VC-PRIMOS 400 L – GENERAL INFORMATION
Machine Type: Compact vertical machining center
Application: High-speed small-part machining
Build: High precision and efficient
Advantage: Ideal for automation and production lines
INDUSTRIES THAT USE MAZAK VC-PRIMOS 400 L
Automotive
Electronics
Medical Device
Precision Engineering
General Manufacturing
TYPICAL PARTS MAZAK VC-PRIMOS 400 L CAN PRODUCE
Small housings
Precision brackets
Electronic components
Medical parts
High-volume small machined parts
WHY CHOOSE MAZAK VC-PRIMOS 400 L
Compact footprint saves floor space
High-speed spindle for productivity
Fast tool changing system
Ideal for automation integration
Excellent for high-volume small parts production
WHY BUY USED MAZAK VC-PRIMOS 400 L
Buying a used Mazak VC-PRIMOS 400 L is a practical choice for manufacturers seeking a reliable and cost-effective vertical machining center. The PRIMOS series is designed to provide essential machining capabilities without unnecessary complexity, making it ideal for job shops, toolrooms, and small to medium production facilities.
One of the key advantages is simplicity and efficiency. The machine offers straightforward operation and maintenance while still delivering the precision and reliability expected from Mazak. This makes it particularly attractive for businesses looking to increase capacity without investing in more complex or expensive equipment.
From a productivity standpoint, the extended table design allows for machining longer components or running multiple parts in a single setup, improving efficiency and reducing downtime. Machines with moderate cutting hours (6,000–15,000 hours) typically provide the best balance between cost and remaining operational life, especially since this is a relatively newer model.
Cost savings are significant, with used machines generally priced 30–60% lower than new models. However, cutting time remains an important factor—machines with higher hours (15,000–20,000+) may require maintenance in spindle or axis components. A well-maintained, low-hour machine can still deliver near-new performance and strong return on investment.
HOW MUCH DOES A USED MAZAK VC-PRIMOS 400 LCOST?
The cost of a used Mazak VC-PRIMOS 400 L depends on manufacturing year, condition, configuration, and most importantly, cutting hours. As a relatively newer and cost-focused machine, it does not have older pre-2000 variants, and pricing is primarily influenced by usage and condition.
Machines from the early production years (approximately 2015–2020) typically range from $40,000 to $70,000. These machines may have moderate cutting hours (8,000–18,000 hours) and can offer good value if properly maintained.
Models from 2020–2023 generally fall within the $70,000 to $100,000 range. This segment offers strong value, particularly for machines with lower cutting hours (5,000–12,000 hours) and good maintenance records. Machines with additional tooling or upgraded features may command higher prices.
Newer machines from 2023–2025 typically range from $100,000 to $150,000+, depending on condition, features, and usage. Low-hour machines (under 5,000–8,000 cutting hours) can achieve premium pricing due to minimal wear and extended service life.
Ultimately, cutting time is more important than age. A heavily used newer machine may be less valuable than a lightly used older one, making spindle condition, maintenance history, and overall machine health critical factors in determining true market value.
