USED HEM V130HM
The HEM V130HM is a heavy-duty vertical double miter band saw engineered for precision angle cutting and long-term durability. Built to handle demanding shop environments, the HEM V130HM delivers consistent accuracy with mitering capability up to 45 degrees both left and right. This versatile machine can currently be seen under power in Illinois, offering buyers the opportunity to inspect its performance firsthand.
Capacity & Cutting Performance
With a cutting capacity of 20” x 24”, the HEM V130HM is well suited for structural shapes, bar stock, and fabricated components. As part of the proven vertical series from HE&M Saw, the HEM V130HM reflects decades of refinement in vertical band saw engineering. These machines are widely recognized for their strength, stability, and repeatable cutting precision across a broad range of materials.
The double miter design allows operators to perform angle cuts efficiently without repositioning material unnecessarily—saving time while maintaining accuracy.
Engineered for Longevity
One of the defining characteristics of the HEM V130HM is its smart mechanical layout. The motor and gearbox are fully enclosed within the upper head of the saw, positioned away from coolant spray and chip accumulation. This elevated placement significantly extends component life compared to conventional designs.
Premium components are standard on the HEM V130HM, including:
Lincoln Electric variable speed motors
Borg Warner Morse gearboxes
Allen Bradley electrical systems
This commitment to high-quality components ensures long-term reliability and consistent machine performance.
Blade Control & Stability
Cut quality and blade life are enhanced through several key engineering features:
Perpendicular Guide Arm: Provides rigid support to the back of the blade, reducing vibration and improving cutting accuracy. The guide arm is fully adjustable to match material height.
Flat Carbide Blade Guides: Offer firm lateral blade support, improving stability through the cut. These guides are precision ground and relieved to accommodate blade twist, easing blade transition and reducing stress.
Counterbalanced Head Design: Because the motor and gearbox are mounted above, the saw head is counterweighted with dead weight. This results in a heavier, more stable cutting head that minimizes vibration and promotes longer blade life.
Advanced Vise System
The HEM V130HM features a robust vertical band saw vise engineered for both flexibility and operator safety. The vise includes infinitely variable clamping pressure, allowing precise adjustment based on material type and thickness. Stops are positioned off the front of the vise plate, preventing accidental damage to the vise during cutting operations.
A Legacy of Innovation
The HEM V130HM represents the ongoing innovation of HE&M Saw, founded in 1964 by Gerald Harris in Livermore, California. What began as a small garage operation grew during the post–World War II industrial expansion. In 1976, the company relocated to Pryor, Oklahoma, where it continues to manufacture equipment within more than 250,000 square feet of production space.
This legacy of engineering excellence is evident in the durability, performance, and long service life of the HEM V130HM, making it a trusted vertical band saw solution for fabrication shops and production facilities alike.
HEM V130HM SPECIFICATIONS AND EQUIPPED WITH
| FEATURE | DESCRIPTION |
| Adjustable Clamping Force | Allows precise control of material holding pressure |
| Adjustable Cutting Force | Optimizes cutting performance based on material type |
| Adjustable Feed Rate | Variable feed control for improved cut quality |
| Adjustable Main Vise | Flexible material positioning and secure clamping |
| Air Powered Blade Tension | Maintains proper blade tension for consistent cutting |
| Blade Brush | Removes chips from blade gullets for cleaner operation |
| Boltable Side Wings | Assists with coolant drainage and improved material support |
| Broken Blade Indicator | Automatically detects blade failure for safety |
| Carbide Blade Guides | Provides rigid blade stability and improved accuracy |
| Front-Mounted Manual Console | Easy-access control panel with manual swing-away design |
| Flood Coolant System w/ Wash-Down Hose | Integrated cooling and machine clean-up capability |
| Forward Cut Stop | Ensures repeatable length accuracy |
| Powered Guide Arm | Hydraulic guide arm adjusts for optimal blade support |
| Powered Tilt w/ Angle Readout | Hydraulic tilting head with angle display for precision mitering |
| Safety Guards | Protects operator during cutting operations |
| Hydraulic Tilting Head | Smooth and controlled angle adjustments |
| SPECIFICATION | DETAILS |
| Throat Capacity | 24″ |
| Work Height | 20″ |
| Capacity (Rectangular) | 20″ x 24″ |
| Capacity Miter Left | 20″ x 16″ |
| Capacity Miter Right | 20″ x 15″ |
| Capacity (Rounds) | 18″ |
| Blade Speed (Variable) | 72 – 400 FPM |
| Blade Width | 1.5″ |
| Blade Length | 17.5′ – 19′ |
| Guide Arm | Hydraulic |
| Hydraulic Vise Pressure | 0 – 1500 lbs |
| Hydraulic Blade Tension | Yes |
| Head Tilt | Hydraulic |
| Digital Readout Displays | Yes |
| Coolant System | Yes |
| Motor | 10 HP |
| Control | CNC (Manual Swing Away) |
| Year New | 2000 |
| Model | V130HM |
| Manufacturer | HE&M Saw |
INDUSTRIES THAT USE HEM V130HM
| INDUSTRY | APPLICATION |
| Structural Steel Fabrication | Angle cutting of beams, channels, and supports |
| Metal Fabrication Shops | Precision miter cutting for frames and assemblies |
| Construction & Infrastructure | Preparing structural members for building projects |
| Machinery Manufacturing | Cutting components for equipment frames |
| Steel Service Centers | Processing plate, bar, and structural stock |
| Custom Fabrication | Short-run and specialty angled parts |
TYPICAL PARTS HEM V130HM CAN PRODUCE
| PART TYPE | DESCRIPTION |
| Mitered Structural Beams | Accurate left and right angle cuts up to 45° |
| Frame Components | Structural pieces for welded assemblies |
| Round Bar Sections | Up to 18″ diameter |
| Rectangular & Square Tubing | Clean, straight or angled cuts |
| Support Brackets | Precision mitered fabrication parts |
| Heavy Plate Sections | Vertical cutting applications |
WHY CHOOSE THE HEM V130HM
| ADVANTAGE | BENEFIT |
| Double Miter Capability | Cuts 45° left and right without repositioning material |
| Hydraulic Tilt & Guide Arm | Smooth, precise angle adjustments |
| Adjustable Feed & Cutting Force | Optimized performance for various materials |
| Heavy-Duty Construction | Reduced vibration and improved blade life |
| Variable Blade Speeds | Handles multiple material types efficiently |
| Hydraulic Vise Pressure (0–1500 lbs) | Secure material control |
| Built by HE&M Saw | Proven reliability and long service life |
WHY BUY USED HEM V130HM
Investing in a used HEM V130HM offers exceptional value for fabrication shops and structural steel operations seeking dependable miter cutting capability without the premium price of new equipment. These machines are engineered for durability, featuring hydraulic tilt systems, heavy-duty guide arms, and industrial-grade motors designed to withstand years of demanding production.
A pre-owned HEM V130HM allows businesses to expand capacity quickly while preserving capital for other operational needs. With variable blade speeds, strong hydraulic clamping, and precision angle cutting, a well-maintained used unit can continue delivering consistent and accurate performance. For shops requiring versatile vertical miter cutting, purchasing used provides the performance of a premium machine at a significantly reduced investment cost.
