The used Doosan DCM 3250F is a large-capacity CNC double-column (gantry/bridge-type) machining center designed for high-precision, heavy-duty, five-face machining. It is part of the DCM series, which is specifically engineered for machining large, complex components in a single setup.
This machine features an elevating cross rail (W-axis), a RAM-type spindle, and compatibility with multiple attachment heads, enabling full 5-face machining capability. Its rigid double-column construction minimizes vibration and ensures long-term accuracy, making it ideal for mold & die, aerospace, and heavy structural applications.
When buying a used DCM 3250F, important inspection areas include spindle condition, cross-rail accuracy, ram wear, and attachment head performance.
DOOSAN DCM 3250FSPECIFICATIONS
DOOSAN DCM 3250F – AXIS TRAVELS
X-Axis Travel: 5250 mm
Y-Axis Travel: 3700 mm
Z-Axis Travel: 700–1000 mm
W-Axis (Cross Rail): 1100 mm
C-Axis Rotation: 360°
Designed for Extra-Large Components
DOOSAN DCM 3250F – CAPACITY
Table Size: ~5100 × 2700 mm
Table Load Capacity: ~33,000 kg
Large Work Envelope
Suitable for Heavy Components
Ideal for Mold & Die
Inspect Table Condition
DOOSAN DCM 3250F – SPINDLE
Spindle Type: RAM-Type
Max Spindle Speed: 6,000–8,000 RPM
Spindle Taper: CAT 50 / BT50
Motor Power: ~22–26 kW (~30–35 HP)
Torque: ~700+ Nm
Designed for Heavy Cutting
DOOSAN DCM 3250F – TABLE
Table Configuration: Fixed Table
Working Surface: ~5100 × 2700 mm
Distance Between Columns: ~3200 mm
Heavy-Duty Construction
Supports Large Fixtures
High Stability Platform
DOOSAN DCM 3250F – TOOL TURRET
Tool Changer Type: Automatic Tool Changer
Tool Capacity: 40 (Optional up to 90)
Tool Taper: CAT 50
Supports Large Tooling
Automatic Head Changer Available
Verify Tool Change Reliability
DOOSAN DCM 3250F – FEEDRATES
Rapid Traverse X: ~16 m/min
Rapid Traverse Y: ~20 m/min
Rapid Traverse Z: ~15 m/min
Rapid Traverse W: ~3 m/min
Smooth Axis Motion
Stable Under Heavy Load
DOOSAN DCM 3250F – COOLANT & CHIP MANAGEMENT
Through-Spindle Coolant Available
Flood Coolant System
Chip Conveyor Included
Designed for Heavy Chip Removal
Large Coolant Tank
Maintain Clean System
DOOSAN DCM 3250F – CONTROL SYSTEM
CNC Control: Fanuc 31i Series
Multi-Axis Capability
Supports 5-Face Machining
Advanced Machining Functions
User-Friendly Interface
Verify Control Condition
DOOSAN DCM 3250F – POWER & AIR REQUIREMENTS
Power Requirement: 3 Phase
Voltage: 220–440 VAC
Approx Power: ~60–80 kVA
Air Requirement: ~6–8 bar
High Power Consumption
Ensure Facility Support
DOOSAN DCM 3250F – DIMENSIONS
Machine Length: ~13,600 mm
Machine Width: ~8,650 mm
Machine Height: ~6,700 mm
Machine Weight: ~82,000 kg
Requires Large Floor Space
Heavy Foundation Required
DOOSAN DCM 3250F – GENERAL INFORMATION
Machine Type: Double Column Gantry / Bridge Mill
5-Face Machining Center
Moving Cross-Rail Design
RAM-Type Spindle
High Rigidity Structure
Designed for Extra-Large Part Machining
INDUSTRIES THAT USE DOOSAN DCM 3250F
Aerospace
Mold & Die
Energy
Heavy Equipment
Shipbuilding
General Engineering
TYPICAL PARTS DOOSAN DCM 3250F CAN PRODUCE
Large Mold Bases
Structural Frames
Turbine Components
Machine Bases
Aerospace Panels
Heavy Plates & Castings
WHY CHOOSE DOOSAN DCM 3250F
Massive Work Envelope
5-Face Machining Capability
High Rigidity Gantry Design
Multi-Axis Flexibility
Reduced Setup Time
Reliable for Heavy Industrial Applications
WHY BUY USED DOOSAN DCM 3250F
Buying a used Doosan DCM 3250F is ideal for shops that require extremely large machining capacity with multi-face capability.
Its biggest advantage is the ability to machine multiple sides of a large component in a single setup, reducing handling time and improving accuracy.
The machine also offers a massive table capacity combined with a rigid gantry structure, making it highly effective for both heavy roughing and precision finishing.
HOW MUCH DOES A USED DOOSAN DCM 3250FCOST?
Pricing depends on year, condition, and configuration.
Typical pricing ranges:
2015–2018 models: around $300,000 to $500,000
2018–2023 models: around $450,000 to $700,000
Fully equipped machines: can exceed $800,000+
Machines with automatic head changers, high-capacity ATC, and probing systems command higher prices.
