USED HAAS MINI MILL 2 – 2019

The 2019 Haas Mini Mill 2 is a compact yet highly capable vertical machining center designed for precision machining across a wide range of manufacturing applications. Built by Haas Automation, one of the most recognized CNC machine tool manufacturers in North America, the Mini Mill 2 has become a popular choice for machine shops, prototype facilities, educational institutions, and production manufacturers seeking a reliable and cost-effective CNC milling solution.

The Haas Mini Mill 2 is a 3-axis vertical machining center that offers increased travels compared to the standard Mini Mill, allowing users to machine larger components while maintaining a relatively small footprint. This combination of compact size and impressive machining capability makes it ideal for facilities where floor space is limited but productivity remains a priority. Equipped with a CAT 40 spindle taper, automatic tool changer, and the powerful Haas Next Generation Control, the machine delivers the performance required for both simple and complex machining operations.

Manufacturers commonly use the Mini Mill 2 to machine aluminum, steel, stainless steel, brass, plastics, and composite materials. The machine excels at producing precision components, prototypes, fixtures, tooling, molds, and production parts. Its high spindle speeds and rigid construction allow operators to achieve excellent surface finishes while maintaining tight tolerances.

Industries including aerospace, automotive, medical device manufacturing, electronics, defense, energy, and general contract machining regularly utilize Haas Mini Mill machines due to their versatility and ease of operation. The user-friendly Haas control helps reduce training requirements and allows operators to become productive quickly.

The 2019 Haas Mini Mill 2 remains highly desirable in the used CNC marketplace because it combines modern control technology with proven mechanical reliability. Buyers benefit from Haas’s extensive service network, readily available replacement parts, and strong resale value. For companies looking to expand machining capacity without investing in a new machine, a used 2019 Haas Mini Mill 2 offers an attractive balance of performance, affordability, and long-term productivity.

---

HAAS MINI MILL 2 – AXIS

Specification	Value
Number of Axes	3 Axis
Simultaneous Axis Control	3 Axis
Positioning Type	CNC Controlled

---

HAAS MINI MILL 2 – AXIS TRAVELS / WORK ENVELOPE

Specification	Value
X-Axis Travel	20″
Y-Axis Travel	16″
Z-Axis Travel	14″
Maximum Work Envelope	20″ x 16″ x 14″

---

HAAS MINI MILL 2 – CAPACITY / TABLE

Specification	Value
Table Length	36″
Table Width	12″
Maximum Table Load	500 lbs
T-Slots	3

---

HAAS MINI MILL 2 – SPINDLE

Specification	Value
Spindle Speed	10,000 RPM
Spindle Taper	CAT 40
Spindle Motor	20 HP
Drive Type	Direct Drive

---

HAAS MINI MILL 2 – TOOL CHANGER

Specification	Value
Tool Capacity	20 Tools
Tool Changer Type	Automatic Carousel
Maximum Tool Weight	12 lbs

---

HAAS MINI MILL 2 – CONTROL SYSTEM

Specification	Value
CNC Control	Haas Next Generation Control
Programming Capability	G-Code and Conversational
Connectivity	Ethernet and USB
Display	Color LCD

---

HAAS MINI MILL 2 – COOLANT / DUST / WATER MANAGEMENT

Specification	Value
Coolant System	Flood Coolant
Coolant Tank Capacity	Approx. 20 Gallons
Chip Removal	Optional Chip Auger
Enclosure	Fully Enclosed

---

HAAS MINI MILL 2 – POWER REQUIREMENTS

Specification	Value
Voltage	220V / 240V
Phase	3 Phase
Power Consumption	Approx. 25 kVA
Air Requirement	Shop Air Required

---

HAAS MINI MILL 2 – DIMENSIONS

Specification	Value
Length	Approx. 92″
Width	Approx. 87″
Height	Approx. 100″
Weight	Approx. 4,000 lbs

---

HAAS MINI MILL 2 – GENERAL INFORMATION

Specification	Value
Manufacturer	Haas Automation
Machine Type	Vertical Machining Center
Year	2019
Construction	Cast Iron
Country of Origin	USA

---

INDUSTRIES THAT USE HAAS MINI MILL 2

The Haas Mini Mill 2 is widely used across numerous industries that require precision machining, fast setup times, and flexible manufacturing capabilities. Its compact design and dependable performance make it suitable for both high-mix, low-volume production and dedicated manufacturing environments.

Industries commonly using the Haas Mini Mill 2 include:

• Aerospace Manufacturing
• Automotive Components Manufacturing
• Medical Device Production
• Electronics and Semiconductor Manufacturing
• Defense and Military Contracting
• Tool and Die Shops
• Mold Making Facilities
• Energy Industry Suppliers
• Contract Manufacturing Companies
• Prototype Development Centers
• Research and Development Departments
• Educational and Technical Training Institutions
• Industrial Equipment Manufacturers
• Robotics Manufacturers
• Consumer Product Manufacturing

The machine’s ability to accurately machine aluminum, steel, stainless steel, plastics, and exotic materials makes it highly versatile. Many shops utilize the Mini Mill 2 as their primary machining center for short-run production work, while larger manufacturers often use it for secondary operations, fixture production, and prototype development. Its relatively small footprint allows businesses to maximize productivity without sacrificing valuable floor space.

---

TYPICAL PARTS HAAS MINI MILL 2 CAN PRODUCE

The Haas Mini Mill 2 is capable of producing a broad range of precision-machined components. Thanks to its rigid construction, high-speed spindle, and reliable CNC control, the machine can efficiently manufacture both simple and complex parts.

Typical parts produced include:

• Aerospace Brackets
• Mounting Plates
• Medical Device Components
• Surgical Instrument Parts
• Tooling Plates
• Custom Fixtures
• Production Jigs
• Mold Inserts
• Mold Bases
• Electronic Enclosures
• Heat Sinks
• Sensor Housings
• Hydraulic Components
• Pneumatic Components
• Precision Aluminum Components
• Stainless Steel Parts
• Robotics Components
• Prototype Parts
• Automotive Components
• Industrial Machine Parts
• Custom OEM Components
• Research and Development Prototypes

The machine is particularly popular among manufacturers requiring precision milling, drilling, tapping, contouring, pocketing, and engraving operations. Its flexibility allows users to move quickly from prototype work to production machining with minimal setup changes.

---

WHY CHOOSE HAAS MINI MILL 2

The Haas Mini Mill 2 has established itself as one of the most successful compact vertical machining centers available today. Manufacturers choose the machine because it delivers professional-grade CNC milling performance while remaining affordable and easy to operate.

One of the biggest advantages of the Mini Mill 2 is its larger travel capacity compared to the standard Mini Mill. This allows shops to machine larger parts without upgrading to a significantly larger and more expensive machining center. The machine’s CAT 40 spindle taper and automatic tool changer provide the capability required for demanding machining applications.

Another reason manufacturers choose the Haas Mini Mill 2 is the simplicity of the Haas control system. The Haas Next Generation Control is widely recognized for its user-friendly interface, making programming, setup, and operation straightforward for both experienced machinists and new operators.

The machine also benefits from strong aftermarket support. Replacement parts, service technicians, software updates, and operator training resources are readily available throughout North America. This reduces downtime and lowers long-term ownership costs.

For manufacturers seeking a compact, reliable, and highly productive CNC machining center, the Haas Mini Mill 2 continues to deliver exceptional value and dependable performance.

---

WHY BUY USED HAAS MINI MILL 2

A used 2019 Haas Mini Mill 2 represents one of the best values in the CNC machine tool market. Buyers gain access to a modern vertical machining center equipped with proven technology, reliable performance, and strong industry support at a significantly lower cost than purchasing a new machine.

One of the primary reasons shops purchase used Haas Mini Mill 2 machines is the immediate cost savings. New machining centers require substantial capital investment, whereas a used machine can often provide similar productivity for a fraction of the price. This allows manufacturers to preserve capital for tooling, workholding, inspection equipment, and business growth initiatives.

Another major advantage is availability. New machine lead times can stretch for months depending on factory production schedules. Used machines are often available immediately, enabling businesses to increase capacity quickly and begin generating revenue sooner.

The Mini Mill 2’s reputation for reliability further strengthens its appeal in the used market. Haas machines are designed for long service life, and properly maintained units frequently remain productive for many years. The machine’s simple design and extensive support network help minimize maintenance concerns.

Buyers also appreciate the widespread availability of replacement parts and qualified service technicians. Because Haas machines are so common throughout North America, finding technical support is typically easier than with many competing brands.

The machine’s compact footprint provides another significant advantage. Shops can add machining capacity without requiring major facility modifications or additional floor space. This is especially beneficial for small manufacturers, startups, and job shops.

Strong resale values also contribute to the machine’s popularity. The Haas brand remains highly recognized, helping owners maintain asset value over time. As a result, purchasing a used Haas Mini Mill 2 can be viewed as both a productive manufacturing investment and a relatively secure equipment acquisition.

---

HOW MUCH DOES A USED HAAS MINI MILL 2 COST?

The market value of a used 2019 Haas Mini Mill 2 typically falls between $30,000 and $50,000, depending on machine condition, spindle hours, installed options, tooling packages, maintenance history, and overall market demand.

Machines located near the lower end of the price range generally have higher operating hours, fewer options, or may require minor maintenance. Machines priced toward the upper end are often low-hour examples equipped with desirable features such as probing systems, high-speed machining packages, fourth-axis capability, chip augers, programmable coolant systems, and extensive tooling packages.

Spindle condition is one of the most important factors affecting resale value. Buyers often pay a premium for machines with documented maintenance records and evidence of proper care. Machines that have been operated in clean environments and maintained according to manufacturer recommendations tend to command higher prices.

The availability of included tooling can also significantly influence pricing. Tool holders, vises, probes, rotary tables, and workholding equipment can add considerable value to a used machine package. Buyers should always evaluate the total package rather than focusing solely on the machine itself.

Market conditions play an important role as well. Demand for Haas machines remains consistently strong due to the brand’s reputation and extensive support infrastructure. As a result, clean late-model Haas Mini Mill 2 machines often sell quickly when they become available.

Compared to purchasing a new vertical machining center, a used 2019 Haas Mini Mill 2 offers substantial savings while still providing modern CNC technology and dependable performance. For many machine shops, contract manufacturers, and prototype facilities, the machine delivers an excellent balance of affordability, capability, and long-term value, making it one of the most desirable compact machining centers in the used CNC marketplace.
