USED TSUGAMI B0385L – 2011

The TSUGAMI B0385L is a high-performance Swiss-type CNC automatic lathe designed for manufacturers that require exceptional precision, heavy-duty turning capability, and efficient production of larger diameter components. Manufactured by Tsugami Corporation, one of the world’s most respected builders of Swiss-type machine tools, the B0385L combines advanced sliding headstock technology with powerful spindle performance and extensive tooling flexibility. The machine is specifically designed for machining complex parts from bar stock up to 38 mm in diameter, making it an ideal solution for industries such as medical, aerospace, automotive, defense, fluid power, oil and gas, and precision engineering. The B0385L features a guide-bushless design, dual spindles, live tooling capability, and advanced CNC controls that allow manufacturers to complete highly complex parts in a single setup while maintaining exceptional accuracy and productivity.

One of the primary advantages of the TSUGAMI B0385L is its ability to machine larger diameter workpieces while maintaining the precision traditionally associated with Swiss-type machining. The machine incorporates both a main spindle and sub-spindle, enabling simultaneous front and back machining operations that significantly reduce cycle times and eliminate secondary operations. This multitasking capability improves throughput while maintaining tight tolerances and superior surface finishes. The machine’s guide-bushless configuration also reduces material waste and shortens remnant lengths, helping manufacturers improve material utilization and lower production costs.

The B0385L is commonly equipped with a Fanuc CNC control system, multiple live tooling stations, full C-axis functionality, and extensive tooling capacity. With up to 23-31 tool positions depending on configuration, the machine can perform turning, milling, drilling, tapping, threading, cross drilling, and back-working operations within a single cycle. These capabilities make it particularly attractive for manufacturers producing highly complex precision components in medium-to-high production volumes.

Even though the machine was manufactured in 2011, the TSUGAMI B0385L remains highly sought after in the used CNC machinery market due to its robust construction, proven reliability, and ability to produce complex parts efficiently. For manufacturers seeking Swiss-type precision combined with larger diameter machining capacity, the B0385L continues to be one of the industry’s most respected production platforms.

---

TSUGAMI B0385L – AXIS

Specification	Details
Number of Axes	5 Axis
Main Spindle	Yes
Sub-Spindle	Yes
C-Axis	Main & Sub Spindle
Live Tool Capability	Yes

---

TSUGAMI B0385L – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
Maximum Bar Capacity	38 mm
Maximum Machining Length	100 mm
Headstock Stroke	Approx. 100 mm
Cross Tool Travel	Approx. 110 mm
Back Working Capability	Full Sub-Spindle Machining

---

TSUGAMI B0385L – CAPACITY / TABLE

Specification	Details
Maximum Bar Diameter	38 mm
Maximum Chucking Diameter	38 mm
Maximum Drilling Diameter	13 mm
Maximum Tapping Capacity	M12
Production Type	Heavy-Duty Swiss Machining

---

TSUGAMI B0385L – SPINDLE

Specification	Details
Main Spindle Speed	6,000 RPM
Sub-Spindle Speed	7,000 RPM
Main Spindle Motor	11 kW
Sub-Spindle Motor	5.5 kW
Spindle Configuration	Dual Spindle Swiss-Type

---

TSUGAMI B0385L – TOOL CHANGER

Specification	Details
Total Tool Positions	23 – 31 Tools
Live Tool Stations	Up to 5
Gang Slide Tool Positions	8
Front Tool Positions	5
Back Working Positions	5

---

TSUGAMI B0385L – CONTROL SYSTEM

Specification	Details
CNC Control	Fanuc Oi-TD
Programming	G-Code
Conversational Features	Available
Ethernet Connectivity	Optional
DNC Capability	Supported

---

TSUGAMI B0385L – COOLANT / DUST / WATER MANAGEMENT

Specification	Details
Coolant System	High-Pressure Coolant
Coolant Pressure	Up to 1,000 PSI (Optional)
Filtration System	Integrated
Chip Removal	Automatic Chip Conveyor
Mist Collection	Optional

---

TSUGAMI B0385L – POWER REQUIREMENTS

Specification	Details
Voltage	200V / 220V
Phase	3 Phase
Frequency	50/60 Hz
Connected Load	Approx. 25 kVA

---

TSUGAMI B0385L – DIMENSIONS

Specification	Details
Length	2,520 mm
Width	1,345 mm
Height	1,970 mm
Machine Weight	4,600 – 4,850 kg

---

TSUGAMI B0385L – GENERAL INFORMATION

Specification	Details
Manufacturer	Tsugami
Model	B0385L
Year	2011
Machine Type	Swiss-Type CNC Automatic Lathe
Country of Manufacture	Japan
Primary Function	Precision Turning, Milling & Back Working

---

INDUSTRIES THAT USE TSUGAMI B0385L

The TSUGAMI B0385L is widely used by manufacturers that require larger diameter Swiss-machined components while maintaining extremely high precision. Medical device manufacturers utilize the machine for surgical instruments, orthopedic implant components, fixation devices, and specialized medical hardware. Aerospace companies rely on the machine for hydraulic fittings, bushings, connectors, fasteners, and precision aircraft components that require consistent dimensional accuracy.

Automotive suppliers use the B0385L to produce injector bodies, transmission components, sensor housings, fuel system parts, and precision drivetrain components. The machine’s larger 38 mm bar capacity allows it to handle components that exceed the capabilities of smaller Swiss lathes while still delivering Swiss-level precision.

Fluid power manufacturers machine hydraulic fittings, valve bodies, couplings, adapters, and pneumatic components. Oil and gas suppliers utilize the machine for specialty fittings, connectors, pressure-control components, and instrumentation hardware. Additional industries include defense, robotics, telecommunications, industrial automation, electronics, and contract precision machining.

The machine’s combination of larger diameter capacity, multitasking capability, and Swiss-type precision makes it particularly attractive for manufacturers producing high-value parts that require multiple operations within a single machining cycle.

---

TYPICAL PARTS TSUGAMI B0385L CAN PRODUCE

The TSUGAMI B0385L is capable of producing a wide range of precision-machined components. Medical applications include surgical instrument shafts, implant components, fixation devices, dental hardware, and catheter fittings. Aerospace manufacturers commonly produce hydraulic fittings, precision bushings, connectors, sensor housings, fasteners, and structural hardware.

Automotive suppliers manufacture injector bodies, transmission fittings, valve components, sensor housings, fuel system parts, and drivetrain components. Fluid power manufacturers machine hydraulic valves, couplings, adapters, manifolds, and pneumatic fittings.

Additional applications include defense hardware, instrumentation components, precision shafts, threaded connectors, robotic components, telecommunications hardware, semiconductor tooling, and custom-engineered precision parts. The machine’s dual-spindle design allows complete front and back machining operations to be completed without secondary setups, improving both productivity and accuracy.

---

WHY CHOOSE TSUGAMI B0385L

The TSUGAMI B0385L offers manufacturers a unique combination of Swiss-type precision and larger diameter machining capability. One of its greatest advantages is the ability to process bar stock up to 38 mm in diameter while maintaining the exceptional accuracy and repeatability associated with Swiss machining technology.

The machine’s dual-spindle configuration enables simultaneous front and back machining operations, significantly reducing cycle times and improving throughput. Multiple live tooling stations allow complex milling, drilling, tapping, and contouring operations to be performed within a single setup, eliminating secondary operations and improving overall efficiency.

The guide-bushless design helps reduce material waste, shorten remnant lengths, and lower operating costs. Manufacturers also benefit from improved setup flexibility and reduced material requirements compared to traditional Swiss machines.

Tsugami machines are recognized worldwide for reliability, durability, and long-term performance. Combined with the proven Fanuc control platform, the B0385L offers dependable operation, strong service support, and ease of programming. For manufacturers seeking a Swiss lathe capable of handling larger workpieces without sacrificing precision, the TSUGAMI B0385L remains an outstanding solution.

---

WHY BUY USED TSUGAMI B0385L

Purchasing a used TSUGAMI B0385L provides manufacturers with access to premium Swiss machining technology at a substantially lower investment than purchasing a comparable new machine. Swiss-type lathes represent a significant capital expense, making high-quality used equipment particularly attractive for growing manufacturing operations.

One of the primary benefits is acquiring advanced dual-spindle machining capability, live tooling functionality, and larger diameter bar capacity while preserving capital for tooling, automation, and production expansion. Many used B0385L machines are available with bar feeders, chip conveyors, high-pressure coolant systems, tooling packages, and spare parts inventories that further enhance value.

The B0385L is known for exceptional durability and long service life. Machines that have been properly maintained often continue producing precision parts for many years while maintaining high levels of productivity and accuracy. Tsugami’s reputation for engineering quality contributes to strong long-term value and dependable operation.

Immediate availability is another important advantage. New Swiss-type machines frequently require extended lead times, while used machines can often be installed and placed into production quickly. For manufacturers facing increasing demand or expanding production capacity, this can provide a significant competitive advantage.

A used TSUGAMI B0385L offers an excellent balance of performance, reliability, and value for companies seeking advanced Swiss machining capability.

---

HOW MUCH DOES A USED TSUGAMI B0385L COST?

The value of a used TSUGAMI B0385L depends on machine condition, spindle hours, maintenance history, tooling packages, included automation equipment, and overall configuration. Because the B0385L is a specialized Swiss-type production machine with larger diameter capacity, pricing can vary considerably based on equipment level and operational condition.

Machines with low spindle hours, documented maintenance records, and comprehensive tooling packages generally command higher prices. Buyers often evaluate spindle condition, live tooling functionality, guide systems, CNC control performance, and overall machine accuracy when assessing value.

Included accessories such as automatic bar feeders, high-pressure coolant systems, chip conveyors, mist collectors, fire suppression systems, tooling inventories, and spare parts packages can significantly increase the value of a machine package. Well-equipped machines often provide a faster return on investment by reducing startup costs and improving productivity.

Demand remains strong among aerospace manufacturers, medical suppliers, automotive companies, fluid power manufacturers, defense contractors, and contract machining facilities. The machine’s combination of Swiss precision and 38 mm bar capacity helps maintain strong resale demand throughout the used CNC market.

As a general guideline, a used 2011 TSUGAMI B0385L typically sells within a range of approximately $65,000 to $160,000, depending on machine condition, spindle hours, included tooling, automation equipment, and overall configuration. Machines equipped with premium accessories and extensive tooling packages may command higher values. Even after accounting for installation, training, and tooling costs, a used TSUGAMI B0385L often provides exceptional value compared to purchasing a comparable new Swiss-type machine.
