USED OKUMA MB-5000H – 2016

The OKUMA MB-5000H is a versatile and highly productive horizontal machining center engineered for precision machining, high-volume production, and automated manufacturing environments. The 2016 OKUMA MB-5000H combines Okuma’s proven machine rigidity, advanced thermal stability technology, high-speed spindle performance, and the powerful OSP-P300M CNC Control to deliver exceptional accuracy, reliability, and productivity.

Designed to maximize spindle utilization and minimize downtime, the MB-5000H features a horizontal spindle configuration that naturally improves chip evacuation by allowing chips to fall away from the cutting area. This reduces chip recutting, improves surface finishes, extends tool life, and supports long unattended machining cycles. The machine’s rigid cast iron structure provides excellent vibration dampening and thermal stability, making it ideal for both roughing and finishing operations.

The machine incorporates a dual-pallet automatic pallet changer system, allowing operators to load and unload workpieces while machining continues on the active pallet. Combined with rapid axis movements, fast tool changes, and automation-ready capabilities, the MB-5000H is an outstanding solution for aerospace, automotive, medical, energy, defense, and precision contract manufacturing applications.

The 2016 OKUMA MB-5000H remains highly sought after in the used CNC marketplace because of its proven reliability, advanced control technology, and ability to maintain precision in demanding production environments.

---

OKUMA MB-5000H – AXIS

Specification	Details
Machine Type	Horizontal Machining Center
Axis Configuration	4-Axis
X-Axis Travel	30.71″
Y-Axis Travel	31.50″
Z-Axis Travel	35.43″
B-Axis Rotary Table	Full NC Rotary
Rotary Positioning Increment	0.001°
Rotary Travel	Continuous 360°

---

OKUMA MB-5000H – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
X-Axis Travel	30.71″
Y-Axis Travel	31.50″
Z-Axis Travel	35.43″
Pallet Size	19.69″ x 19.69″
Maximum Workpiece Diameter	31.50″
Maximum Workpiece Height	39.37″
Maximum Workpiece Weight	1,760 lbs

---

OKUMA MB-5000H – CAPACITY / TABLE

Specification	Details
Number of Pallets	2 Standard
Pallet Changer	Automatic
Pallet Dimensions	19.69″ x 19.69″
Maximum Pallet Load	1,760 lbs
Table Type	Precision Rotary Pallet
Multi-Sided Machining Capability	Yes
Automation Integration	Available

---

OKUMA MB-5000H – SPINDLE

Specification	Details
Standard Spindle Speed	6,000 RPM
Optional Spindle Speed	10,000 RPM / 15,000 RPM
Spindle Motor Power	40 HP
Spindle Taper	CAT 50 / BT50
Spindle Type	High-Torque Integral Motor Spindle
Through-Spindle Coolant	Available
Heavy-Duty Cutting Capability	Excellent

---

OKUMA MB-5000H – TOOL CHANGER

Specification	Details
Standard Tool Capacity	48 Tools
Optional Tool Capacity	64 / 100 / 146 Tools
Tool Changer Type	Automatic Tool Changer
Tool-to-Tool Change Time	Approx. 1.8 Seconds
Chip-to-Chip Time	Approx. 4.8 Seconds
Random Tool Selection	Standard

---

OKUMA MB-5000H – CONTROL SYSTEM

Specification	Details
CNC Control	OSP-P300M
Programming Format	Conversational & G-Code
Ethernet Networking	Standard
Thermo-Friendly Concept	Standard
Tool Life Management	Standard
Collision Avoidance System	Available
Advanced Diagnostics	Included

---

OKUMA MB-5000H – COOLANT / CHIP MANAGEMENT

Specification	Details
Flood Coolant System	Standard
Through-Spindle Coolant	Available
High-Pressure Coolant	Optional
Chip Conveyor	Standard
Coolant Filtration System	Standard
Automatic Chip Removal	Yes

---

OKUMA MB-5000H – PROBING & AUTOMATION OPTIONS

Specification	Details
Renishaw Work Probe	Available
Tool Measurement System	Available
Automatic Tool Setter	Available
Flexible Manufacturing System Ready	Yes
Multi-Pallet Automation	Available
Robotic Integration	Available
Lights-Out Manufacturing Capability	Yes

---

OKUMA MB-5000H – POWER REQUIREMENTS

Specification	Details
Voltage	220V / 440V / 480V
Electrical Requirement	3 Phase
Connected Load	Approx. 55 kVA
Air Requirement	Shop Air Required

---

OKUMA MB-5000H – DIMENSIONS

Specification	Details
Machine Weight	Approx. 28,500 lbs
Construction	Heavy-Duty Cast Iron Structure
Installation Type	Industrial Foundation Recommended
Production Class	Mid-Size Horizontal Machining Center

---

OKUMA MB-5000H – GENERAL INFORMATION

Specification	Details
Manufacturer	Okuma Corporation
Model	MB-5000H
Year	2016
Machine Category	Horizontal Machining Center
Country of Origin	Japan
Primary Application	Precision Production Machining
Production Environment	Medium to High Volume Manufacturing

---

INDUSTRIES THAT USE OKUMA MB-5000H

The OKUMA MB-5000H is widely utilized throughout aerospace, automotive, defense, medical, energy, industrial automation, and electronics manufacturing industries. Aerospace manufacturers commonly machine aircraft structural components, actuator housings, hydraulic assemblies, and precision aluminum and titanium parts.

Automotive manufacturers use the machine for transmission housings, engine components, steering assemblies, suspension parts, and drivetrain components. The machine’s high-speed spindle and pallet-changing system make it ideal for continuous production environments.

Medical device manufacturers rely on the MB-5000H for surgical instrumentation, orthopedic tooling, implant fixtures, and precision medical equipment components. Additional applications include robotics, semiconductor equipment manufacturing, and contract machining operations.

---

TYPICAL PARTS OKUMA MB-5000H CAN PRODUCE

The MB-5000H is capable of producing a wide variety of precision-machined components. Common applications include gearbox housings, valve bodies, hydraulic manifolds, aerospace brackets, robotic structures, tooling fixtures, transmission cases, and industrial automation components.

The machine excels at multi-sided machining operations where multiple surfaces must be machined in a single setup. This reduces setup time, improves dimensional accuracy, and increases overall production efficiency.

Other applications include pump housings, semiconductor equipment structures, transportation system components, medical device parts, energy equipment components, and custom-engineered industrial products.

---

WHY CHOOSE OKUMA MB-5000H

The OKUMA MB-5000H delivers an excellent combination of precision, reliability, flexibility, and production efficiency. One of its key advantages is Okuma’s Thermo-Friendly Concept, which helps maintain machining accuracy despite temperature fluctuations in the manufacturing environment.

Its horizontal spindle design improves chip evacuation and supports longer unattended machining cycles. The rigid machine structure ensures stable cutting performance across a wide range of materials and machining applications.

The automatic pallet changer increases spindle utilization by minimizing setup-related downtime. Combined with the OSP-P300M control system and automation-ready architecture, the machine provides excellent productivity and operational flexibility.

For manufacturers seeking a proven horizontal machining center capable of supporting demanding production schedules, the MB-5000H remains one of the industry’s most respected machining platforms.

---

WHY BUY USED OKUMA MB-5000H

Purchasing a used 2016 OKUMA MB-5000H allows manufacturers to obtain advanced horizontal machining technology at a significantly lower cost than purchasing a comparable new machine.

Many used machines include valuable options such as through-spindle coolant, Renishaw probing systems, expanded tool magazines, pallet automation, chip conveyors, and advanced monitoring software. These options can significantly improve productivity while reducing future capital expenditures.

Okuma machines are known worldwide for their durability, long service life, and excellent resale value. Properly maintained MB-series machines continue to provide dependable production performance for many years.

Another major advantage is immediate availability. Used equipment can often be installed and producing parts much faster than new machine purchases with extended factory lead times.

---

HOW MUCH DOES A USED OKUMA MB-5000H COST?

The value of a used 2016 OKUMA MB-5000H depends on machine condition, spindle hours, maintenance records, tooling packages, installed options, and current market demand.

Machines equipped with larger tool magazines, probing systems, high-pressure coolant, pallet automation, and documented service histories generally command higher resale values. Demand remains strong among aerospace suppliers, automotive manufacturers, medical device companies, and precision contract machining operations.

In addition to the machine purchase price, buyers should consider transportation, rigging, installation, electrical requirements, tooling, operator training, programming support, and facility preparation costs. These factors contribute to the total ownership investment and should be evaluated carefully.

Compared with purchasing a new horizontal machining center, a used 2016 OKUMA MB-5000H can provide substantial savings while still delivering excellent machining capability, automation readiness, production efficiency, and long-term reliability. For manufacturers seeking a versatile and highly productive horizontal machining platform, the MB-5000H remains one of the strongest values available in the used CNC equipment market.
