USED MORI SEIKI ZT-2500Y – 2007

The 2007 MORI SEIKI ZT-2500Y is a high-capacity CNC twin-turret, twin-spindle turning center with Y-axis and live tooling capability. Designed for multitasking production, the ZT-2500Y can combine turning, milling, drilling, tapping, and secondary-spindle operations in a single machine, reducing the number of setups required for complex components.

The ZT-2500Y is particularly attractive for manufacturers that need to machine components requiring operations on both ends. Its twin-spindle configuration allows a workpiece to be transferred between the main and sub spindle, while the twin-turret arrangement allows multiple tools to remain available for simultaneous or sequential machining operations. A documented 2007 machine is equipped with Y-axis capability, C-axis live tooling, twin turrets, twin spindles, a parts catcher, and chip conveyor.

The 2007 ZT-2500Y has a substantial machining envelope, with listings reporting approximately 27.7 inches of swing over the bed, 16.5 inches over the cross slide, and up to 13.7 inches of turning length. The main spindle has a 3.5-inch through-hole, while the machine is capable of spindle speeds up to approximately 4,000 RPM.

Its upper turret incorporates approximately ±2.8 inches of Y-axis travel, allowing milling and drilling operations to be performed away from the spindle centerline. The two 12-station turrets provide considerable tooling flexibility, with driven tooling available for the live-tooling operations.

A 2007 specification listing identifies Fanuc CNC control, while other ZT-2500Y examples from the same generation are equipped with Mori Seiki MSG-501/MSG-501III or related control configurations. The exact control on an individual 2007 machine should therefore be confirmed before purchase.

For shops machining complex turned components, the MORI SEIKI ZT-2500Y 2007 offers the major advantage of multitasking capability in a heavy-duty production platform.

---

MORI SEIKI ZT-2500Y – SPECIFICATIONS

Specification	Value
Manufacturer	MORI SEIKI
Model	ZT-2500Y
Year	2007
Machine Type	CNC Twin-Turret Twin-Spindle Turning Center
Axes	Multi-Axis
Main Spindle	Yes
Sub Spindle	Yes
Turrets	2
Turret Capacity	12 Stations Each
Y Axis	Yes
Live Tooling	Yes
Main Spindle Speed	4,000 RPM
Main Spindle Through Hole	Approx. 3.5 in
Main Spindle Nose	A2-8
Max Swing Over Bed	Approx. 27.7 in
Max Swing Over Cross Slide	Approx. 16.5 in
Max Turning Diameter	Approx. 15.3 in
Max Secondary Turning Diameter	Approx. 14.1 in
Standard Turning Diameter	Approx. 10.2 in
Max Turning Length	Approx. 13.7 in
Distance Between Centers	Approx. 51.2 in
X Travel – Turret 1	Approx. 11 in
X Travel – Turret 2	Approx. 7.9 in
Y Travel	Approx. ±2.8 in
Z Travel	Approx. 37.8 in
Sub-Spindle Travel	Approx. 38 in
Rotary Tool Speed	Up to 4,000 RPM
C-Axis Indexing	0.001°
Control	Fanuc / Configuration Dependent
Chip Conveyor	Configuration Dependent
Parts Catcher	Configuration Dependent

Specifications can vary by machine configuration and options; the figures above are based primarily on documented 2007 ZT-2500Y listings.

---

MORI SEIKI ZT-2500Y – TURNING CAPACITY

Specification	Approximate Capacity
Max Swing Over Bed	27.7 in
Max Swing Over Cross Slide	16.5 in
Max Turning Diameter – Main	15.3 in
Max Turning Diameter – Secondary	14.1 in
Standard Turning Diameter	10.2 in
Max Turning Length	13.7 in
Distance Between Centers	51.2 in
Main Bar Capacity	Approx. 3 in
Main Spindle Through Hole	Approx. 3.5 in

The combination of large swing, twin spindles, and relatively substantial bar capacity makes the ZT-2500Y suitable for production components that require multiple turning and secondary operations.

---

MORI SEIKI ZT-2500Y – MAIN SPINDLE

Specification	Value
Spindle Type	Main Turning Spindle
Spindle Nose	A2-8
Speed Range	Approximately 40–4,000 RPM
Through Hole	Approx. 3.5 in
Spindle Bearing Inner Diameter	Approx. 5.1 in
C-Axis	Yes
C-Axis Indexing	0.001°
Spindle Motor	Configuration Dependent
Chuck	Approximately 10 in on documented machine

A 2007 ZT-2500Y listing specifies 40–4,000 RPM, a 3.5-inch spindle through-hole, 5.1-inch spindle bearing inner diameter, and 0.001° C-axis indexing. Another documented machine lists a 10-inch chuck.

---

MORI SEIKI ZT-2500Y – SUB SPINDLE

The sub spindle is one of the most important features of the ZT-2500Y. It allows components to be transferred from the main spindle for secondary machining, making it possible to complete operations on both ends without removing the part from the machine.

Feature	Specification
Sub Spindle	Yes
Sub-Spindle Travel	Approx. 38 in
C-Axis	Yes
C-Axis Indexing	0.001°
Spindle Speed	Configuration Dependent
Spindle Nose	Configuration Dependent
Secondary Turning Diameter	Approx. 14.1 in

The twin-spindle architecture is particularly useful for production parts where front- and back-side operations would otherwise require separate machines or manual repositioning.

---

MORI SEIKI ZT-2500Y – TWIN TURRETS

The ZT-2500Y uses two independent turrets, giving the machine substantially more tooling flexibility than a conventional single-turret CNC lathe.

Feature	Turret 1	Turret 2
Tool Stations	12	12
X Travel	Approx. 11 in	Approx. 7.9 in
Z Travel	Approx. 37.8 in	Approx. 37.8 in
Live Tooling	Yes	Configuration Dependent
C-Axis Operations	Yes	Configuration Dependent

Twin turrets can reduce cycle time by allowing different machining operations to be performed without repeatedly changing tools or waiting for a single turret to complete every operation.

---

MORI SEIKI ZT-2500Y – Y AXIS AND LIVE TOOLING

The Y-axis is what transforms the ZT-2500Y from a conventional turning center into a much more capable multitasking machine.

The upper turret provides approximately ±2.8 inches of Y-axis travel, allowing driven tools to move above and below the spindle centerline. This is useful for milling flats, slots, keyways, cross holes, off-center holes, and other features that cannot be produced efficiently with conventional turning tools.

Typical live-tooling applications include:

• Cross drilling
• Radial drilling
• End-face drilling
• Milling flats
• Slot milling
• Keyway machining
• Tapping
• Thread milling
• Off-center hole patterns
• Small contour milling

A documented ZT-2500Y configuration provides rotary-tool speeds of approximately 4,000 RPM, while other examples list driven-tool speeds as high as 6,000 RPM depending on configuration.

---

MORI SEIKI ZT-2500Y – CNC CONTROL

The 2007 ZT-2500Y can be found with different control configurations, so the exact control should be verified on the machine being purchased.

Control Feature	Availability
CNC Control	Yes
Fanuc Control	Documented 2007 Configuration
Mori Seiki MSG Control	Available on Other Configurations
C-Axis Programming	Yes
Y-Axis Programming	Yes
Live Tool Programming	Yes
Sub-Spindle Programming	Yes
Tool Offsets	Yes
Work Offsets	Yes
Diagnostics	Yes
Custom Macros	Configuration Dependent

One documented 2007 machine is identified as having a Fanuc CNC control, while other ZT-2500Y machines use Mori Seiki MSG-501-series controls.

---

MORI SEIKI ZT-2500Y – CHIP MANAGEMENT

A chip conveyor is listed on a documented 2007 ZT-2500Y, making it well suited to production environments where large volumes of turning chips are generated.

Feature	Availability
Chip Conveyor	Configuration Dependent
Flood Coolant	Yes
Coolant System	Configuration Dependent
Parts Catcher	Documented
Coolant Filtration	Configuration Dependent
High-Pressure Coolant	Configuration Dependent

When evaluating a used machine, the chip conveyor should be cycled under load and checked for damaged flights, worn bearings, motor problems, and chip buildup.

---

MORI SEIKI ZT-2500Y – MACHINE DIMENSIONS AND WEIGHT

Specification	Approximate Value
Length	Approx. 165 in
Width	Approx. 109 in
Height	Approx. 109 in
Weight	Approx. 28,600–29,700 lb
Machine Type	Heavy-Duty Multitasking Turning Center

Published ZT-2500Y specifications vary slightly depending on configuration, but documented machines are approximately 28,600–29,700 lb, demonstrating the substantial construction of this turning center.

---

WHY BUY USED MORI SEIKI ZT-2500Y 2007

A used MORI SEIKI ZT-2500Y 2007 is an excellent option for manufacturers that need more than basic turning capability. Its combination of twin turrets, twin spindles, Y-axis movement, C-axis capability, and live tooling allows many complex components to be completed in fewer setups.

The biggest productivity advantage is the ability to perform operations on both ends of a component. Instead of removing the part from the machine and transferring it to another lathe for secondary work, the sub spindle can take over the component and allow additional operations to be completed.

The twin-turret design further increases productivity by providing two separate tool stations. With 12 stations per turret on documented machines, operators have considerable flexibility when setting up jobs requiring turning, boring, grooving, drilling, threading, and live-tool operations.

The Y-axis adds another important capability. Milling and off-center drilling operations can be performed directly on the turning center, reducing the need for a separate milling machine for certain components.

The machine’s substantial swing and turning capacity make it suitable for a wide variety of medium and larger turned components. Its approximately 3-inch bar capacity also makes it practical for production work involving larger bar stock.

For manufacturers purchasing used CNC equipment, the ZT-2500Y can therefore provide multitasking capability at a lower acquisition cost than buying a comparable newer twin-spindle Y-axis turning center.

---

HOW MUCH DOES A USED MORI SEIKI ZT-2500Y 2007 COST?

The price of a used MORI SEIKI ZT-2500Y 2007 can vary significantly depending on spindle hours, machine condition, control configuration, included tooling, live-tool equipment, chip conveyor, parts catcher, bar feeder, and overall maintenance history.

Because the ZT-2500Y is a complex multitasking machine, buyers should evaluate considerably more than the main spindle. The sub spindle, both turrets, Y-axis, C-axis functions, live tooling, and tool-changing systems all need to operate correctly.

Spindle condition should be one of the first priorities. Test the main and sub spindle throughout their operating ranges and listen for bearing noise, vibration, unusual temperature increases, or acceleration problems. The spindle taper and chuck condition should also be inspected.

The Y-axis should be moved through its complete range while checking for servo alarms, unusual noise, backlash, or positioning problems. Live tooling should also be tested at multiple speeds.

Both turrets should be cycled through all positions. Buyers should verify that every station indexes correctly and that the turrets clamp and unclamp properly.

The sub-spindle transfer operation is particularly important. A machine may appear to run correctly while still having problems with synchronization, positioning, or part transfer.

Buyers should also inspect the chip conveyor, coolant system, hydraulic system, lubrication system, electrical cabinet, way covers, ballscrews, linear guides, and chuck cylinders.

A well-maintained 2007 MORI SEIKI ZT-2500Y with good spindle condition, accurate axes, functioning twin turrets, reliable sub-spindle operation, and working live tooling can be significantly more valuable than a lower-priced machine requiring major repairs.

---

INDUSTRIES THAT USE MORI SEIKI ZT-2500Y

• Aerospace Manufacturing
• Automotive Manufacturing
• Oil & Gas
• Hydraulic Manufacturing
• Medical Component Manufacturing
• General Machining
• Contract Manufacturing
• Defense Manufacturing
• Industrial Equipment
• Heavy Equipment
• Precision Engineering
• Energy Equipment
• Job Shops
• Production Machining

---

TYPICAL PARTS PRODUCED ON MORI SEIKI ZT-2500Y

• Shafts
• Flanges
• Bushings
• Housings
• Couplings
• Hydraulic Components
• Valve Components
• Pump Components
• Automotive Components
• Aerospace Components
• Fittings
• Spacers
• Sleeves
• Rotating Components
• Complex Turned Components
• Multi-Sided Machined Parts

---

WHAT TO INSPECT BEFORE BUYING MORI SEIKI ZT-2500Y 2007

Main Spindle

• Test the complete RPM range.
• Check spindle noise.
• Check spindle vibration.
• Inspect spindle taper.
• Measure spindle runout.
• Test C-axis operation.
• Inspect chuck and hydraulic cylinder.

Sub Spindle

• Test complete spindle movement.
• Check spindle synchronization.
• Test C-axis.
• Check transfer operation.
• Inspect chuck condition.
• Check spindle runout.

Y Axis

• Test the complete Y-axis travel.
• Check backlash.
• Listen for ballscrew noise.
• Check servo operation.
• Verify positioning accuracy.

Twin Turrets

• Cycle every tool position.
• Check turret clamping.
• Test indexing.
• Inspect tool holders.
• Check driven-tool stations.

Live Tooling

• Test multiple RPM ranges.
• Check driven-tool bearings.
• Test milling.
• Test drilling.
• Test tapping if available.

CNC Control

• Check display.
• Test keyboard.
• Review alarm history.
• Test program loading.
• Check memory.
• Verify axis controls.
• Confirm available software options.

Chip Conveyor

• Run conveyor under load.
• Check motor.
• Inspect flights.
• Check bearings.
• Look for excessive chip accumulation.

Hydraulic and Lubrication Systems

• Check hydraulic pressure.
• Inspect for leaks.
• Verify automatic lubrication.
• Check lubrication lines.
• Inspect hydraulic hoses.

Overall Machine

• Review spindle hours.
• Review power-on hours.
• Request maintenance records.
• Inspect way covers.
• Check electrical cabinet.
• Check for crash damage.
• Run the machine under power.

---

WHY CHOOSE MORI SEIKI ZT-2500Y 2007

The MORI SEIKI ZT-2500Y 2007 stands out because it combines several machining functions into one production platform. Its twin-spindle and twin-turret architecture, combined with Y-axis and live-tool capability, allows manufacturers to perform turning and secondary milling operations with significantly fewer setups.

With approximately 15.3 inches of maximum main turning diameter, 13.7 inches of turning length, 37.8 inches of Z travel, 11 inches of X travel on the primary turret, ±2.8 inches of Y travel, and a 4,000 RPM spindle, the ZT-2500Y provides substantial capacity for production machining.

Its 12-station twin turrets, C-axis functionality, sub-spindle, live tooling, and chip-management options make it especially useful for complex parts requiring multiple operations.

For a manufacturer looking for a used multitasking CNC turning center, the MORI SEIKI ZT-2500Y – 2007 offers a combination of capacity and functionality that can still make it a highly productive machine when the individual unit has been properly maintained and passes a thorough inspection.
