The Mazak VERSATECH V-140N/360 is one of the largest and most capable double-column (gantry-type) 5-axis machining centers in Mazak’s lineup, engineered for machining extremely large, heavy, and complex components with high precision. Designed for industries such as aerospace, power generation, shipbuilding, and heavy equipment manufacturing, this machine is built to handle oversized parts while maintaining exceptional rigidity and accuracy. Its robust double-column construction with an extended column span ensures maximum structural stability during heavy-duty cutting operations.
The V-140N/360 features an extra-large table, typically around 8000 mm × 2800 mm or more, with a load capacity exceeding 50,000 kg, making it suitable for some of the largest workpieces in industrial manufacturing. It is equipped with a powerful CAT 50 spindle, generally operating at 8,000 rpm, with optional high-torque or high-speed configurations to handle a wide range of materials, including hardened steels and superalloys.
A key feature of the machine is its multi-position spindle head, which allows vertical, horizontal, and angular machining without manual head changes, significantly reducing setup time. Optional simultaneous 5-axis capability with B- and C-axis movements enables full multi-surface machining in a single setup. Overall, the VERSATECH V-140N/360 delivers unmatched capacity, precision, and productivity for large-scale machining applications.
MAZAK VERSATECH V-140N/360SPECIFICATIONS
MAZAK VERSATECH V-140N/360 – AXIS
Number of Axes: 5 (X, Y, Z, B, C)
Axis Configuration: Double-column gantry design
Simultaneous Control: Optional full 5-axis simultaneous machining
B-Axis Rotation: ±100° tilting spindle head
C-Axis Rotation: 360° continuous rotary
MAZAK VERSATECH V-140N/360 – AXIS TRAVELS
X-Axis Travel: Approx. 9,000 mm
Y-Axis Travel: Approx. 3,750 mm (between columns)
Z-Axis Travel: Approx. 700–1,000 mm
W-Axis Travel: Quill-type (optional)
B/C Axis Travel: Multi-angle machining capability
MAZAK VERSATECH V-140N/360 – CAPACITY
Maximum Workpiece Size: Approx. 8,000 mm × 3,750 mm × 1,750 mm
Maximum Workpiece Weight: Up to ~43,000 kg
Table Size: Approx. 3,100 mm × 8,000 mm
Load Capacity: Extremely heavy-duty machining
Pallet System: Optional pallet/turning table system
Machine Type: 5-axis double-column machining center
Capability: Multi-surface and complex geometry machining
Design Focus: Ultra-large part productivity
Advantage: Reduced setups with full multi-face machining
Ideal For: Very large, high-precision components
INDUSTRIES THAT USE MAZAK VERSATECH V-140N/360
Aerospace
Energy
Heavy Equipment
Oil & Gas
Industrial Machinery
TYPICAL PARTS MAZAK VERSATECH V-140N/360 CAN PRODUCE
Large aerospace structural components
Turbine and generator housings
Heavy machine bases
Large molds and dies
Energy infrastructure components
WHY CHOOSE MAZAK VERSATECH V-140N/360
Designed for ultra-large workpieces
True 5-axis machining capability
Extremely high load capacity
Reduced setup time for large parts
Ideal for heavy-duty, high-precision machining
WHY BUY USED MAZAK VERSATECH V-140N/360
Buying a used Mazak VERSATECH V-140N/360 is a highly strategic investment for manufacturers needing ultra-large machining capability at a significantly reduced cost. These machines are designed for heavy-duty industrial use and long operational life, making them highly durable and capable of maintaining strong performance over decades when properly maintained.
One of the most critical factors when evaluating a used V-140N/360 is cutting time rather than just the machine’s age. Machines used in industries such as energy, shipbuilding, and large-scale fabrication often accumulate extremely high cutting hours due to long machining cycles and demanding materials. This can lead to wear in essential components such as the spindle, guideways, ball screws, and structural elements, potentially requiring refurbishment. These machines are usually priced lower but may involve higher maintenance costs.
On the other hand, machines used in low-volume production or specialized applications often have lower cutting hours and better preserved accuracy, making them more desirable even if older. Another key advantage is that many used units come equipped with expensive options such as 5-axis heads, high-torque spindles, and automation systems like PALLETECH, which significantly enhance productivity and would be costly to add to a new machine.
Overall, a used VERSATECH V-140N/360 offers unmatched size, capability, and long-term value for heavy-duty machining operations.
HOW MUCH DOES A USED MAZAK VERSATECH V-140N/360COST?
The cost of a used Mazak VERSATECH V-140N/360 varies significantly depending on year of manufacture, configuration, and most importantly, cutting hours. Due to its extreme size and specialized application, it is among the highest-priced machines in the used CNC market.
For machines comparable to early large gantry systems (pre-2000), prices generally range from $300,000 to $600,000, although availability is limited and these machines typically have very high cutting hours and outdated control systems.
For machines built between 2000 and 2010, prices typically range from $600,000 to $1,500,000 depending on condition, spindle configuration, and included features such as 5-axis heads or turning tables. Machines with lower cutting hours, upgraded controls, or recent rebuilds command higher prices within this range.
For newer machines from 2010 to 2025, prices generally range from $1,500,000 to $5,000,000 or more. Machines equipped with advanced Mazatrol Smooth controls, high-torque spindle options, large-capacity tool magazines, and automation systems such as PALLETECH or large pallet systems are priced at the top end due to their exceptional productivity and capability.
Cutting hours remain the most critical pricing factor. Low-hour machines command premium pricing, while heavily used machines are discounted due to potential refurbishment costs, particularly for spindle systems, guideways, and major structural components.
