The Mazak VERSATECH V-100N/200 is a large-format 5-axis double-column (gantry-type) machining center designed for high-precision machining of very large and heavy workpieces. As part of Mazak’s VERSATECH series, it is built to handle complex multi-surface machining in industries such as aerospace, energy, heavy equipment, and die & mold. The machine features a rigid double-column structure with a wide span between columns, ensuring exceptional stability and accuracy even under heavy cutting conditions.
One of the defining features of the V-100N/200 is its large table size of approximately 4000 mm × 2100 mm with a load capacity of around 43,000 kg, allowing it to machine extremely large components efficiently. The machine is equipped with a CAT 50 spindle, typically offering 8,000 rpm as standard, with options for high-speed (12,000 rpm) or high-torque configurations depending on application requirements.
A key advantage is its multi-position spindle head, capable of machining vertical, horizontal, and angled surfaces without manual head changes, significantly reducing non-cutting time. Optional simultaneous 5-axis capability with B- and C-axis movements allows complex geometries to be machined in a single setup. Overall, the VERSATECH V-100N/200 is engineered for high-productivity, large-part machining with excellent precision and process integration.
MAZAK VERSATECH V-100N/200SPECIFICATIONS
MAZAK VERSATECH V-100N/200 – AXIS
Number of Axes: 5 (X, Y, Z, W, B)
Axis Configuration: Vertical moving column with horizontal spindle
MAZAK VERSATECH V-100N/200 – POWER & AIR REQUIREMENTS
Power Requirement: Approx. 80–120 kVA
Voltage: 3-phase industrial supply
Air Requirement: Clean, dry compressed air
Air Pressure: Approx. 5–7 bar
MAZAK VERSATECH V-100N/200 – DIMENSIONS
Machine Footprint: Extremely large floor-standing machine
Structure: Moving column design
Construction: Heavy-duty cast iron
Accessibility: Operator-friendly large work area
Installation: Requires reinforced foundation
MAZAK VERSATECH V-100N/200 – GENERAL INFORMATION
Machine Type: Vertical machining center with horizontal spindle
Capability: Large-part multi-face machining
Design Focus: Heavy-duty and high precision
Advantage: Reduced repositioning for large parts
Ideal For: Large structural and complex components
INDUSTRIES THAT USE MAZAK VERSATECH V-100N/200
Aerospace
Energy
Heavy Equipment
Oil & Gas
Industrial Machinery
TYPICAL PARTS MAZAK VERSATECH V-100N/200 CAN PRODUCE
Structural aerospace components
Turbine housings
Large frames and bases
Heavy machine components
Energy sector parts
WHY CHOOSE MAZAK VERSATECH V-100N/200
Designed for very large and heavy workpieces
High rigidity and stability for heavy cutting
Multi-axis capability for complex parts
Reduced setups for large components
Ideal for high-precision heavy-duty machining
WHY BUY USED MAZAK VERSATECH V-100N/200
Buying a used Mazak VERSATECH V-100N/200 is a highly strategic investment for manufacturers working with large-scale components, as it provides access to advanced 5-axis gantry machining at a significantly reduced cost. These machines are built for heavy-duty applications and long-term durability, meaning they can continue delivering strong performance for many years if properly maintained.
One of the most critical factors when evaluating a used V-100N/200 is cutting time rather than just the machine’s age. Machines used in industries such as energy, shipbuilding, or aerospace often accumulate high cutting hours due to long machining cycles and demanding materials. This can lead to wear in key components such as the spindle, guideways, and ball screws, potentially requiring refurbishment. These machines are typically priced lower but may involve higher maintenance costs.
On the other hand, machines used in low-volume production or specialized applications often have lower cutting hours and better preserved geometry, making them more desirable even if older. Another major advantage is that many used machines come equipped with valuable options such as high-torque spindles, 5-axis heads, and automation systems like PALLETECH, which would be extremely costly to add to a new machine.
Overall, a used VERSATECH V-100N/200 offers exceptional capacity, flexibility, and cost efficiency for large-part machining operations.
HOW MUCH DOES A USED MAZAK VERSATECH V-100N/200COST?
The cost of a used Mazak VERSATECH V-100N/200 varies significantly depending on year of manufacture, configuration, and most importantly, cutting hours. Due to its large size and specialized application, pricing is typically higher than standard 5-axis machines.
For machines comparable to early large gantry systems (pre-2000), prices generally range from $150,000 to $350,000, although availability is limited and these machines often have very high cutting hours and outdated controls.
For machines built between 2000 and 2010, prices typically range from $350,000 to $800,000 depending on condition, spindle configuration, and included features such as 5-axis heads or turning tables. Machines with lower cutting hours, upgraded controls, or recent rebuilds command higher prices within this range.
For newer machines from 2010 to 2025, prices generally range from $800,000 to $2,500,000 or more. Machines equipped with advanced Mazatrol Smooth controls, high-torque spindle options, and automation systems such as PALLETECH or large pallet systems are priced at the top end due to their high productivity and capability.
Cutting hours remain the most important pricing factor. Low-hour machines with strong maintenance records command premium pricing, while heavily used machines are discounted due to potential refurbishment costs, particularly for spindle systems, guideways, and large structural components.
