The Mazak VCN-530C is a high-performance vertical machining center built for precision, speed, and reliability. Known for its robust design and high-rigidity structure, this machine is ideal for manufacturers requiring accurate 3-axis milling on medium to large components. The VCN-530C belongs to Mazak’s VCN (Vertical Center Nexus) series and represents a perfect blend of affordability and performance for high-speed milling and drilling applications.
Engineered with a spindle speed of up to 12,000 rpm and large-axis travels, the VCN-530C offers a generous work envelope and a rapid traverse rate of up to 42 m/min, ensuring efficient machining cycles. It is powered by Mazatrol SmoothG CNC control, known for its ease of use, fast programming, and enhanced processing capabilities.
This machine is particularly suitable for automotive, aerospace, die/mold, and general job shop applications, thanks to its excellent part accessibility, wide Y-axis range, and high chip removal rates. With optional through-spindle coolant, chip conveyors, and high-capacity tool magazines, the VCN-530C can also be optimized for extended unattended machining.
MAZAK VCN-530CSPECIFICATIONS
TRAVELS
X-Axis: 1,050 mm (41.34 in)
Y-Axis: 530 mm (20.87 in)
Z-Axis: 510 mm (20.08 in)
TABLE / WORKPIECE
Table Size: 1,300 mm × 550 mm
Max Table Load: 1,200 kg (2,645 lbs)
T-slots: 5 slots × 18 mm wide
SPINDLE
Spindle Taper: CAT-40 or BT-40
Max Speed: 12,000 rpm (standard)
Spindle Power: ~18.5 – 22 kW (~25 – 30 hp)
Drive Type: Belt or direct-drive (based on configuration)
FEEDRATES
Rapid Traverse (X/Y/Z): 42 m/min
Cutting Feedrate: Up to 10 m/min (depending on material/tool)
TOOL CHANGER
Magazine Capacity: 30 tools (standard), optional up to 48
Tool-to-tool Time: ~1.3 seconds
Max Tool Diameter: 80 mm (adjacent), 125 mm (non-adjacent)
Max Tool Length: 300 mm
Max Tool Weight: 8 kg
COOLANT & CHIP MANAGEMENT
Through-Spindle Coolant (optional): Up to 70 bar
Flood Coolant System: Standard
Chip Conveyor: Optional
Mist Extraction: Optional
CONTROL SYSTEM
Control: Mazatrol SmoothG
Interface: Touchscreen with conversational and EIA/ISO programming
Connectivity: USB and Ethernet
AIR & ELECTRICAL
Air Pressure: ~0.5 MPa
Electrical Power Requirement: ~35 – 40 kVA
MAZAK VCN-530C – GENERAL INFORMATION
Model: Mazak VCN-530C
Machine Type: Vertical Machining Center (3-Axis)
Control: Mazatrol SmoothG CNC
Structure: C-frame with rigid base and column
Purpose: High-speed, high-accuracy milling and drilling
MAZAK VCN-530C – KEY CAPABILITIES
Powerful 12,000 rpm spindle for fast material removal
High-speed rapid traverse (X/Y/Z: up to 42 m/min)
Ideal for 3-axis contouring, pocketing, and surface milling
