MAZAK MAZATECH ULTRA 550 – 1999

MAZAK MAZATECH ULTRA 550 – 1999

MAKE: MAZAK
MODEL: MAZATECH ULTRA 550
TYPE: Horizontal Machines
YEAR: 1999
SKU: 103386
DEALER: Toolquip, Inc
COUNTRY: USA

USED MAZAK MAZATECH ULTRA 550 – 1999

The MAZAK MAZATECH ULTRA 550 is a high-performance horizontal machining center designed for precision production machining, automated manufacturing, and multi-sided component processing. The 1999 MAZATECH ULTRA 550 combines a rigid machine structure, high-speed spindle technology, pallet automation capabilities, and Mazak’s proven CNC control platform to provide manufacturers with exceptional productivity and reliability. The machine was engineered to support continuous production environments where speed, accuracy, and efficient material handling are critical.

Built around a robust cast iron frame, the ULTRA 550 offers excellent rigidity and thermal stability during demanding machining operations. Its horizontal spindle configuration naturally promotes chip evacuation by allowing chips to fall away from the cutting area, reducing chip recutting, improving surface finishes, and extending cutting tool life. This design is especially beneficial during long production runs and complex multi-face machining applications.

The machine utilizes a rotary pallet system that enables efficient workpiece loading and unloading while machining continues on another pallet. Many ULTRA 550 installations were configured with pallet pool systems, allowing manufacturers to maximize spindle utilization and support unattended production operations.

The 1999 MAZAK MAZATECH ULTRA 550 is commonly found in aerospace, automotive, defense, industrial equipment, medical device, energy, and precision contract manufacturing facilities. Its combination of speed, automation capability, and proven reliability continues to make it a desirable machine in the used CNC equipment market.

MAZAK MAZATECH ULTRA 550 – AXIS

SpecificationDetails
Machine TypeHorizontal Machining Center
Axis Configuration4-Axis
X-Axis Travel28.3″
Y-Axis Travel25.6″
Z-Axis Travel25.6″
B-Axis Rotary TableFull 4th Axis Rotary
Rotary PositioningContinuous Indexing

Specifications may vary by machine configuration.

MAZAK MAZATECH ULTRA 550 – AXIS TRAVELS / WORK ENVELOPE

SpecificationDetails
X-Axis Travel28.3″
Y-Axis Travel25.6″
Z-Axis Travel25.6″
Pallet Size20″ x 20″
Maximum Table Load2,200 lbs
Workpiece AccessMulti-Sided Machining
Rapid Traverse RateUp to 1,000 IPM

MAZAK MAZATECH ULTRA 550 – CAPACITY / TABLE

SpecificationDetails
Pallet Size20″ x 20″
Pallet SystemRotary Pallet
Maximum Pallet Load2,200 lbs
Number of PalletsConfiguration Dependent
Automated Pallet Pool CapabilityAvailable
Multi-Face MachiningYes

MAZAK MAZATECH ULTRA 550 – SPINDLE

SpecificationDetails
Maximum Spindle Speed7,500 – 15,000 RPM
Spindle Motor Power20 – 30 HP
Spindle TaperCAT 50
Drive TypeHigh-Speed Production Spindle
Rapid Feed CapabilityHigh-Speed Machining

Machine specifications vary depending on installed spindle package and options.

MAZAK MAZATECH ULTRA 550 – TOOL CHANGER

SpecificationDetails
Standard Tool Capacity60 Tools
Optional Tool Capacity80 Tools or More
Tool Changer TypeAutomatic Tool Changer
Tool-to-Tool Change TimeApprox. 2.5 Seconds
Maximum Tool Diameter10.2″
Maximum Tool Length18.5″
Maximum Tool WeightHeavy-Duty Capacity

MAZAK MAZATECH ULTRA 550 – CONTROL SYSTEM

SpecificationDetails
CNC ControlMazatrol M-Plus
Programming FormatMazatrol Conversational & G-Code
EIA/ISO CompatibilityYes
Tool Management SystemStandard
Networking CapabilityAvailable
Production MonitoringAvailable

MAZAK MAZATECH ULTRA 550 – COOLANT / CHIP MANAGEMENT

SpecificationDetails
Flood Coolant SystemStandard
Through-Spindle CoolantAvailable
High-Pressure CoolantOptional
Chip ConveyorStandard
Coolant Filtration SystemStandard
Automatic Chip RemovalYes

MAZAK MAZATECH ULTRA 550 – POWER REQUIREMENTS

SpecificationDetails
Voltage220V / 440V / 480V
Electrical Requirement3 Phase
Connected LoadApprox. 40–50 kVA
Air RequirementShop Air Required

MAZAK MAZATECH ULTRA 550 – DIMENSIONS

SpecificationDetails
Machine WeightApprox. 30,800 lbs
ConstructionHeavy Cast Iron Frame
FootprintLarge Production Cell Configuration

MAZAK MAZATECH ULTRA 550 – GENERAL INFORMATION

SpecificationDetails
ManufacturerMazak Corporation
ModelMAZATECH ULTRA 550
Year1999
Machine CategoryHorizontal Machining Center
Country of OriginJapan
Primary ApplicationProduction Machining
Production EnvironmentMedium to High Volume Manufacturing

INDUSTRIES THAT USE MAZAK MAZATECH ULTRA 550

The MAZAK MAZATECH ULTRA 550 is widely used in aerospace, automotive, industrial equipment, defense, energy, and contract manufacturing operations. Aerospace manufacturers utilize the machine for structural components, mounting brackets, actuator housings, and aircraft support parts requiring precise multi-sided machining.

Automotive manufacturers commonly produce transmission housings, steering components, suspension parts, engine components, and drivetrain assemblies. The machine’s horizontal spindle design and automation capabilities support efficient production workflows and reduced cycle times.

Industrial equipment manufacturers frequently machine gearbox housings, hydraulic manifolds, pump bodies, automation components, tooling plates, and machine structures. The machine’s pallet system helps maximize spindle uptime and improve manufacturing throughput.

TYPICAL PARTS MAZAK MAZATECH ULTRA 550 CAN PRODUCE

The MAZATECH ULTRA 550 is capable of machining a wide variety of precision components. Typical applications include transmission cases, valve bodies, hydraulic manifolds, gearbox housings, structural brackets, tooling fixtures, aerospace fittings, robotic components, and industrial machine parts.

The machine is particularly effective for workpieces requiring multiple operations on several faces because the rotary pallet system and 4-axis capability reduce setup requirements while improving overall part accuracy.

Other common applications include energy system components, transportation equipment parts, medical equipment housings, mold bases, fixture plates, and custom-engineered production components.

WHY CHOOSE MAZAK MAZATECH ULTRA 550

The MAZAK MAZATECH ULTRA 550 provides manufacturers with a proven horizontal machining platform that delivers excellent productivity, reliability, and machining flexibility. One of its greatest strengths is the combination of high-speed spindle performance and pallet automation, allowing manufacturers to maintain high spindle utilization rates.

The horizontal spindle configuration improves chip evacuation and reduces interruptions caused by chip accumulation. This contributes to better surface finishes, longer tool life, and more consistent machining performance during extended production runs.

The Mazatrol M-Plus control remains highly respected throughout the machining industry for conversational programming and production efficiency. Many machinists continue to value Mazatrol programming for rapid job setup and shop-floor flexibility.

For manufacturers seeking a dependable horizontal machining center with strong automation capabilities, the ULTRA 550 remains a highly capable production machine.

WHY BUY USED MAZAK MAZATECH ULTRA 550

Purchasing a used 1999 MAZAK MAZATECH ULTRA 550 allows manufacturers to acquire proven horizontal machining technology at a substantially lower investment than a comparable new machine.

Many used machines include valuable options such as pallet pools, through-spindle coolant systems, probing packages, spindle chillers, chip conveyors, expanded tool magazines, and high-pressure coolant systems. These features can significantly improve productivity while reducing future upgrade costs.

Mazak machines have earned a strong reputation for durability and long-term service life. Well-maintained ULTRA 550 machines continue to provide reliable production performance decades after their original installation.

Another significant advantage is availability. While new production machining centers may involve lengthy lead times, used machines can often be delivered and installed much faster.

HOW MUCH DOES A USED MAZAK MAZATECH ULTRA 550 COST?

The value of a used 1999 MAZAK MAZATECH ULTRA 550 depends on machine condition, spindle hours, maintenance history, tooling packages, pallet system configuration, installed options, and overall market demand.

Machines equipped with larger tool magazines, pallet pool systems, through-spindle coolant, probing systems, and documented maintenance records generally command higher resale values. Demand remains steady among contract manufacturers, aerospace suppliers, automotive companies, and industrial equipment manufacturers seeking cost-effective horizontal machining capacity.

In addition to purchase price, buyers should consider transportation, rigging, installation, electrical requirements, tooling, operator training, and facility preparation costs when evaluating total ownership investment.

Compared to purchasing a new horizontal machining center, a used 1999 MAZAK MAZATECH ULTRA 550 can provide substantial savings while still delivering excellent machining capability, pallet automation, production efficiency, and long-term reliability. For manufacturers seeking a proven horizontal machining platform, the ULTRA 550 remains a strong value in the used CNC equipment market.
