The Mazak FJV-60/80 is a double-column (gantry-style) vertical machining center designed for high-precision machining of medium-to-large workpieces. As part of Mazak’s FJV BT50 series, it is built for rigidity, stability, and consistent performance in heavy-duty applications. The machine typically features a BT50 spindle with speeds up to 6,000–10,000 RPM, delivering high torque for efficient machining of materials such as steel, cast iron, and aluminum.
The FJV-60/80 offers a balanced working envelope with X/Y/Z travels of approximately 2,000 × 1,400 × 660 mm and a table size around 2,000 × 1,250 mm. This makes it suitable for machining medium-to-large plates, molds, and structural components. Its double-column construction eliminates spindle overhang found in C-frame machines, significantly improving rigidity and ensuring consistent accuracy across the full machining area.
The machine is typically equipped with a 30–60 tool automatic tool changer and Mazak’s MAZATROL CNC control, enabling efficient programming and smooth workflow. Optional multi-surface or angle head attachments allow machining of multiple faces in a single setup, reducing repositioning time and improving productivity. Overall, the FJV-60/80 is designed to deliver stable machining accuracy, strong cutting performance, and reliable operation in demanding manufacturing environments.
MAZAK FJV-60/80SPECIFICATIONS
MAZAK FJV-60/80 – AXIS
Number of Axes: 3 Axes
Axis Configuration: Double Column (Gantry Type) Vertical Machining Center
Axis Movement Type: Linear X, Y, Z axes
Design: Rigid double-column structure for precision and stability
MAZAK FJV-60/80 – AXIS TRAVELS
X-Axis Travel: 2,000 mm (78.74 in)
Y-Axis Travel: 1,400 mm (55.12 in)
Z-Axis Travel: 660 mm (25.98 in)
MAZAK FJV-60/80 – CAPACITY
Table Size: 2,000 mm x 1,250 mm
Max Table Load: Approx. 3,000 – 4,000 kg
Workpiece Capability: Medium to large components
Distance Between Columns: Approx. 1,500 mm
MAZAK FJV-60/80 – SPINDLE
Spindle Speed: Up to 10,000 RPM
Spindle Taper: BT50 / CAT 50
Spindle Power: Approx. 30 – 37 kW
Spindle Type: High-torque, heavy-duty spindle
MAZAK FJV-60/80 – TABLE
Table Size: 2,000 mm x 1,250 mm
Table Type: Fixed worktable
Table Design: Large platform for stable machining
Load Capacity: Suitable for heavy-duty applications
Build: Engineered for high precision and durability
INDUSTRIES THAT USE MAZAK FJV-60/80
Aerospace
Automotive
Heavy Equipment
Tool & Die
Energy Sector
TYPICAL PARTS MAZAK FJV-60/80 CAN PRODUCE
Large plates and panels
Structural components
Machine bases
Heavy-duty housings
Precision industrial parts
WHY CHOOSE MAZAK FJV-60/80
Excellent rigidity for heavy machining
Large work envelope for bigger parts
High-torque spindle for demanding cuts
Reliable performance in industrial environments
Ideal balance between size and capability
WHY BUY USED MAZAK FJV-60/80
Buying a used Mazak FJV-60/80 is a cost-effective way to acquire a rigid, large-capacity machining center without the high investment required for a new double-column machine. These machines are engineered for durability and heavy-duty use, allowing them to maintain accuracy and performance over long periods when properly maintained.
One of the key advantages is rigidity and stability. The double-column design minimizes vibration and ensures consistent machining accuracy, especially during heavy cutting operations or extended machining cycles. This makes the machine ideal for industries such as aerospace, energy, and mold and die manufacturing where precision is critical.
From a productivity standpoint, the FJV-60/80 offers a powerful spindle and a spacious work envelope, enabling efficient machining of larger components. Optional angle heads or multi-surface attachments allow multiple operations to be completed in a single setup, reducing downtime and increasing throughput.
Cost savings are a major benefit, with used machines typically available at 40–70% less than new models. Machines with moderate cutting hours (10,000–20,000 hours) provide the best balance between cost and remaining lifespan. However, cutting time is critical—machines with higher hours (20,000+) may require spindle or axis refurbishment. A well-maintained, low-hour machine can still deliver strong performance and excellent return on investment.
HOW MUCH DOES A USED MAZAK FJV-60/80COST?
The cost of a used Mazak FJV-60/80 varies depending on manufacturing year, condition, configuration, and most importantly, cutting hours. As a mid-size double-column machining center, it is priced higher than standard VMCs but more affordable than larger gantry machines.
Machines manufactured before 2000 typically range from $25,000 to $70,000. These machines often have high cutting hours (20,000–40,000+) and may require refurbishment, particularly in spindle assemblies, guideways, and ball screws.
Models from 2000–2010 generally fall between $70,000 and $150,000. This segment offers the best value, especially for machines with 10,000–20,000 cutting hours and good maintenance records. Machines equipped with larger tool magazines, upgraded controls, or angle heads tend to command higher prices.
Newer machines from 2010–2025 typically range from $150,000 to $300,000+, depending on condition, features, and usage. Low-hour machines (under 10,000 cutting hours), particularly those used in lighter applications such as aluminum machining, can achieve premium pricing due to reduced wear.
Ultimately, cutting time is more important than age. A heavily used newer machine may be less valuable than an older, well-maintained one, making spindle condition, maintenance history, and overall machine health critical factors in determining true market value.
