USED HYUNDAI WIA LV800R – 2022

The Hyundai Wia LV800R – 2022 is a heavy-duty vertical CNC turning center designed for machining large-diameter components with exceptional rigidity and stability. Part of Hyundai Wia’s highly respected LV Series, the LV800R is engineered for high-torque cutting of castings, rings, housings, and other large workpieces commonly found in aerospace, energy, automotive, and heavy equipment manufacturing.

The 2022 HYUNDAI WIA LV800R features a maximum turning diameter of 31.5″ (800 mm), maximum turning height of 31.5″ (800 mm), and an 18″ hydraulic chuck as standard, with optional 21″ and 24″ chucks. X-axis travel is approximately 17.3″ (440 mm) and Z-axis travel is 31.5″ (800 mm). The geared spindle delivers up to 2,000 RPM and is powered by a 40 HP class motor, providing excellent torque for heavy roughing and precision finishing. The machine uses a 12-station servo turret and hardened box guideways for superior durability and cutting performance.

Most 2022 machines are equipped with the Fanuc 31i-B Plus or Fanuc 0i-TF Plus CNC control, offering advanced turning cycles, rigid tapping, Ethernet networking, and comprehensive diagnostics. Common options include C-axis, live tooling (LV800RM/LM variants), automatic tool measurement, chip conveyor, and high-pressure coolant. Used listings for 2022 machines often include Fanuc controls, chip conveyors, and milling holders.

Industries that use the HYUNDAI WIA LV800R include oil and gas, aerospace, wind energy, automotive, mining, and heavy equipment manufacturing. Typical parts include bearing housings, brake drums, valve bodies, pump casings, turbine rings, and large flanges.

The HYUNDAI WIA LV800R remains highly desirable in the used CNC market because it offers modern control technology, excellent heavy-cutting capability, and premium Korean engineering at a competitive price point.

HYUNDAI WIA LV800R – AXIS

HYUNDAI WIA LV800R – CAPACITY

HYUNDAI WIA LV800R – SPINDLE

HYUNDAI WIA LV800R – TURRET

HYUNDAI WIA LV800R – CONTROL SYSTEM

HYUNDAI WIA LV800R – COOLANT / CHIP MANAGEMENT

HYUNDAI WIA LV800R – POWER REQUIREMENTS

HYUNDAI WIA LV800R – DIMENSIONS

HYUNDAI WIA LV800R – GENERAL INFORMATION

INDUSTRIES THAT USE HYUNDAI WIA LV800R

• Oil and Gas
• Aerospace
• Wind Energy
• Automotive
• Mining Equipment
• Heavy Equipment
• Power Generation
• Precision Contract Machining

TYPICAL PARTS HYUNDAI WIA LV800R CAN PRODUCE

• Bearing Housings
• Pump Casings
• Valve Bodies
• Brake Drums
• Turbine Rings
• Large Flanges
• Gear Components
• Structural Rings

WHY CHOOSE HYUNDAI WIA LV800R

The HYUNDAI WIA LV800R is engineered specifically for large-diameter turning where rigidity and chip control are critical. The vertical design supports heavy workpieces securely and minimizes deformation during machining.

Its geared spindle delivers substantial torque at low RPM, making it ideal for cast iron, stainless steel, and alloy materials. Box guideways and a rigid one-piece column provide long-term accuracy and dependable performance under heavy cutting loads.

For manufacturers needing a modern and durable vertical turning solution, the LV800R offers excellent productivity and reliability.

WHY BUY USED HYUNDAI WIA LV800R – 2022

Purchasing a used HYUNDAI WIA LV800R – 2022 is an excellent way to obtain a nearly new heavy-duty vertical turning center while saving significantly compared to the cost of ordering a new machine. Because a 2022 model is very recent, buyers benefit from current-generation Fanuc controls, modern electrical systems, and advanced productivity features that remain highly competitive in today’s manufacturing environment.

Many used machines include valuable options such as larger chuck sizes, chip conveyors, high-pressure coolant, automatic tool setters, and specialized tooling packages. These accessories can represent substantial additional value and help the machine go directly into production with minimal setup costs.

The LV800R is built for heavy-duty turning of large components and is known for its robust construction, stable vertical architecture, and powerful geared spindle. These characteristics make it especially well suited for industries such as oil and gas, wind energy, and heavy equipment manufacturing.

For companies seeking a modern vertical CNC lathe with high torque and proven reliability, purchasing a used 2022 HYUNDAI WIA LV800R offers outstanding performance and excellent return on investment.

HOW MUCH DOES A USED HYUNDAI WIA LV800R – 2022 COST?

The cost of a used HYUNDAI WIA LV800R – 2022 depends on spindle hours, machine condition, installed options, and included tooling and fixtures.

Machines equipped with larger chucks, C-axis capability, live tooling, high-pressure coolant, and low operating hours generally command stronger resale values. Buyers should inspect spindle condition, turret indexing, axis accuracy, and maintenance records before making a purchase.

Because the LV800R is a modern premium vertical turning center, used prices remain strong. However, purchasing used still provides substantial savings over the cost of a new machine while delivering advanced turning capability and long-term value.
