USED HAAS VF2SS 2021

The HAAS VF2SS 2021 is a high-performance CNC Vertical Machining Center (VMC) designed for manufacturers that require high spindle speeds, rapid axis movement, quick tool changes, and reliable production performance. The VF2SS belongs to the Haas Super-Speed series and is designed to reduce machining cycle times while maintaining excellent accuracy and surface quality. The 2021 HAAS VF2SS is well suited for aerospace, automotive, medical, electronics, mold and die, tooling, robotics, defense, and precision contract manufacturing. Haas describes the VF2SS as its most popular Super-Speed model, combining a 12,000 RPM inline direct-drive spindle, fast rapids, and a high-speed side-mount tool changer.

The machine provides 762 mm (30″) X-axis travel, 406 mm (16″) Y-axis travel, and 508 mm (20″) Z-axis travel. The table measures approximately 914 × 356 mm (36″ × 14″). The VF2SS uses a 30 HP (22.4 kW) inline direct-drive spindle with a maximum standard speed of 12,000 RPM and CT40/BT40 tooling. The Super-Speed configuration includes a 30+1 side-mount automatic tool changer, with average tool-to-tool time of approximately 1.6 seconds and chip-to-chip time of approximately 2.2 seconds.

The 2021 model is also compatible with productivity options such as through-spindle coolant, probing, chip management systems, rotary tables, and additional spindle-speed configurations. Exact equipment can vary by individual machine, so buyers should verify the machine’s original build sheet and installed options.

---

HAAS VF2SS 2021 – AXIS

Specification	Value
X Axis	762 mm (30″)
Y Axis	406 mm (16″)
Z Axis	508 mm (20″)
Number of Controlled Axes	3
4th Axis Capability	Optional

---

HAAS VF2SS 2021 – AXIS TRAVELS / WORK ENVELOPE

Specification	Value
X Travel	762 mm (30″)
Y Travel	406 mm (16″)
Z Travel	508 mm (20″)
Spindle Nose to Table Maximum	610 mm (24″)
Spindle Nose to Table Minimum	102 mm (4″)
Table Length	914 mm (36″)
Table Width	356 mm (14″)

These dimensions correspond to the VF2SS platform specifications published by Haas.

---

HAAS VF2SS 2021 – CAPACITY

Specification	Value
Table Size	914 × 356 mm (36″ × 14″)
T-Slots	3
T-Slot Width	Approximately 15.9–16.0 mm
Maximum Table Load	Approximately 680 kg (1,500 lbs)

---

HAAS VF2SS 2021 – SPINDLE

Specification	Value
Standard Spindle Speed	12,000 RPM
Optional Spindle Speed	15,000 RPM
Spindle Motor	30 HP (22.4 kW)
Maximum Torque	90 ft-lb @ 2,000 RPM
Drive System	Inline Direct Drive
Spindle Taper	CT40 / BT40
Bearing Lubrication	Air / Oil Injection
Spindle Cooling	Liquid Cooled
Through Spindle Coolant	Optional

Haas specifies the standard Super-Speed spindle at 12,000 RPM and 30 HP, with a 15,000 RPM spindle available as an option.

---

HAAS VF2SS 2021 – TOOL CHANGER

Specification	Value
Tool Capacity	30+1
Tool Changer Type	High-Speed Side-Mount
Maximum Tool Diameter, Adjacent Pocket Empty	127 mm (5″)
Maximum Tool Diameter, Full	76 mm (3″)
Maximum Tool Length	279 mm (11″)
Maximum Tool Weight	Approximately 5 kg (12 lbs)
Tool-to-Tool Time	Approximately 1.6 seconds
Chip-to-Chip Time	Approximately 2.2 seconds

The high-speed side-mount tool changer is one of the primary features distinguishing the VF2SS from standard VF models.

---

HAAS VF2SS 2021 – FEEDRATES

Specification	Value
X Rapid Traverse	35.6 m/min (1,400 IPM)
Y Rapid Traverse	35.6 m/min (1,400 IPM)
Z Rapid Traverse	35.6 m/min (1,400 IPM)
Maximum Cutting Feedrate	21.2 m/min (833 IPM)

The high-speed rapid movements help reduce non-cutting time, particularly on production parts requiring frequent positioning.

---

HAAS VF2SS 2021 – CONTROL SYSTEM

Specification	Value
CNC Control	Haas CNC Control
Display	Widescreen Control Monitor
Ethernet	Standard
Wi-Fi	Standard
HaasConnect	Standard
HaasDrop	Standard
Rigid Tapping	Standard
Advanced Tool Management	Standard
Program Memory	1 GB
High-Speed Machining	Available / Option Dependent
Safe Run	Standard
ECO Mode	Standard

The modern Haas control platform provides connectivity and production-management features suited to contemporary machine-shop environments.

---

HAAS VF2SS 2021 – COOLANT / CHIP MANAGEMENT

Specification	Value
Coolant Tank Capacity	208 Liters (55 gal)
Coolant System	Multi-Stage Pump
Window Air Blast	Standard
Chip Washdown	Standard
Chip Conveyor	Optional
Through Spindle Coolant	Optional
Chip Auger	Configuration Dependent

Haas lists a 55-gallon coolant tank, multi-stage coolant pump, window air blast, and chip washdown among the VF2SS platform features.

---

HAAS VF2SS 2021 – POWER REQUIREMENTS

Specification	Value
Standard Input Voltage	220 VAC Three Phase
High-Voltage Configuration	380–480 VAC
Full Load Amps at 220 VAC	Approximately 70 A
Full Load Amps at 440 VAC	Approximately 35 A
Compressed Air	Approximately 4 SCFM @ 100 PSI
Minimum Air Pressure	Approximately 80 PSI

Electrical requirements should be confirmed against the specific 2021 machine’s electrical configuration before installation.

---

HAAS VF2SS 2021 – DIMENSIONS

Specification	Value
Approximate Shipping Length	101–103 in
Approximate Shipping Width	99–102 in
Approximate Shipping Height	101–106 in
Shipping Weight	Approximately 7,800 lbs
Shipping Weight with Conveyor	Configuration Dependent

Actual dimensions and shipping weight can vary according to options such as chip conveyors and other accessories.

---

HAAS VF2SS 2021 – GENERAL INFORMATION

Item	Details
Manufacturer	Haas Automation
Model	VF2SS
Year	2021
Machine Type	CNC Vertical Machining Center
Series	Super-Speed VF Series
CNC Control	Haas CNC Control
Spindle Taper	CT40 / BT40
Standard Spindle Speed	12,000 RPM
Spindle Power	30 HP
Tool Capacity	30+1
Controlled Axes	3
4th Axis	Optional

---

INDUSTRIES THAT USE HAAS VF2SS 2021

The HAAS VF2SS 2021 is suitable for aerospace, automotive, medical, electronics, defense, mold and die, tooling, robotics, industrial equipment, and precision contract manufacturing.

Its high-speed spindle and rapid axis movements make it particularly effective for production work involving numerous tool changes and frequent positioning. The machine can process aluminum, steel, stainless steel, titanium, engineering plastics, and other commonly machined materials when appropriate tooling and cutting parameters are used.

---

TYPICAL PARTS HAAS VF2SS 2021 CAN PRODUCE

The HAAS VF2SS 2021 can manufacture aerospace brackets, automotive components, mold inserts, fixture plates, medical components, electronic housings, robotics components, tooling, manifolds, machine components, and precision production parts.

Typical operations include high-speed milling, drilling, tapping, pocketing, contouring, boring, engraving, and finishing.

---

WHY CHOOSE HAAS VF2SS 2021

The HAAS VF2SS 2021 combines 12,000 RPM spindle performance, 30+1 tool capacity, 1,400 IPM rapid traverses, and fast tool changes in a compact vertical machining center. This combination helps reduce non-cutting time and improve productivity on complex parts requiring multiple tools and frequent axis movements.

The VF2SS is particularly attractive to job shops because it provides high-speed machining capability without requiring the floor space of a much larger machining center. Haas’ modern control connectivity, Wi-Fi, HaasConnect, and Advanced Tool Management also make the platform suitable for contemporary production environments.

---

WHY BUY USED HAAS VF2SS 2021

Purchasing a used HAAS VF2SS 2021 can provide manufacturers with a relatively recent high-speed machining center while reducing the capital investment compared with purchasing a new machine. A 2021 model can offer modern Haas control technology, high-speed spindle performance, and contemporary connectivity without the depreciation associated with buying new equipment.

The machine can also allow manufacturers to allocate more capital toward tooling, workholding, probing, rotary equipment, automation, and other production requirements.

When purchasing a used VF2SS, buyers should verify spindle hours, axis condition, machine geometry, maintenance history, control configuration, installed options, and overall accuracy.

---

HOW MUCH DOES A USED HAAS VF2SS 2021 COST?

The price of a used HAAS VF2SS 2021 depends on spindle hours, machine condition, maintenance history, factory options, tooling, and included accessories. Options such as through-spindle coolant, probing, chip conveyor, rotary-table capability, additional spindle speed, and automation-related equipment can have a significant effect on resale value.

Buyers should inspect spindle operation, axis movement, ballscrews, tool changer performance, coolant system, electrical cabinet, control functions, and machine geometry. A live demonstration and documented service history can provide valuable information about the machine’s condition.

Based on the relatively recent model year and the available used-market context, a reasonable estimated market range is approximately $55,000 to $80,000 USD for a used HAAS VF2SS 2021, depending heavily on hours, options, condition, and accessories. Exceptionally low-hour, heavily optioned machines can command more, while higher-hour or base-configured examples may sell for less. This is an estimated range rather than a fixed valuation; actual asking and transaction prices can vary considerably. Recent machining-community discussions around low-hour VF2SS machines illustrate how strongly hours and options can affect valuation.

A well-maintained HAAS VF2SS 2021 remains an excellent used CNC investment for shops seeking high-speed milling, fast tool changes, modern controls, and strong production capability in a compact VMC platform.
