USED HAAS TM1 – 2003

The HAAS TM1 – 2003 is a CNC toolroom vertical machining center designed for job shops, prototype manufacturing, tooling, maintenance, repair work, education, and low-volume production. The TM1 provides full CNC capability in a relatively compact toolroom-mill format and uses standard 40-taper tooling. Haas describes the TM series as machines designed to be easy to learn and operate while providing the precision of Haas CNC control.

A documented 2003 HAAS TM1 has 30 inches of X-axis travel, 12 inches of Y-axis travel, and 16 inches of Z-axis travel, with a 47.75 x 10.5-inch table, 7.5 HP spindle, 4,000 RPM maximum speed, CAT 40 taper, and 1,000-lb table load capacity. A separate 2003 example is listed with a 10-station automatic tool changer and 4th-axis drive, showing that equipment can vary between individual machines.

The TM1 is particularly attractive to smaller shops because it offers useful machining capacity without requiring the floor space of a larger VMC.

---

HAAS TM1 – 2003 – AXIS

Specification	Details
Machine Type	CNC Toolroom Vertical Machining Center
Axis Configuration	3-Axis
X-Axis Travel	30″ / 762 mm
Y-Axis Travel	12″ / 305 mm
Z-Axis Travel	16″ / 406 mm
CNC Interpolation	3-Axis
4th-Axis Capability	Optional
Rotary Integration	Available
Rigid Tapping	Available
Spindle Orientation	Configuration Dependent

---

HAAS TM1 – 2003 – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
X-Axis Travel	30″ / 762 mm
Y-Axis Travel	12″ / 305 mm
Z-Axis Travel	16″ / 406 mm
Work Envelope	30″ x 12″ x 16″
Spindle Nose to Table	Approx. 4″ – 20″
Table Length	47.75″ / 1,213 mm
Table Width	10.5″ / 267 mm
Maximum Table Load	1,000 lbs / 454 kg

The 30-inch X-axis travel makes the TM1 useful for longer plates, fixtures, brackets, and tooling components despite its compact overall design.

---

HAAS TM1 – 2003 – CAPACITY / TABLE

Specification	Details
Table Length	47.75″ / 1,213 mm
Table Width	10.5″ / 267 mm
T-Slot Width	5/8″ / 16 mm
T-Slot Center Distance	4″ / 101.6 mm
Number of Standard T-Slots	3
Maximum Table Load	1,000 lbs / 454 kg
Workholding	Vise / Fixture / Rotary
4th-Axis Integration	Optional
Table Type	Fixed T-Slot

The 1,000-lb evenly distributed table-load rating provides useful capacity for a machine in this class.

---

HAAS TM1 – 2003 – SPINDLE

Specification	Details
Spindle Type	Vector Drive
Spindle Taper	CAT 40
Maximum Spindle Speed	4,000 RPM
Spindle Motor	7.5 HP / 5.6 kW
Maximum Torque	Approx. 33 ft-lb @ 1,200 RPM
Drive System	Vector Drive
Spindle Orientation	Configuration Dependent
Tool Retention	Manual / Configuration Dependent
Spindle Cooling	Configuration Dependent

The 7.5 HP, 4,000 RPM CAT 40 spindle is suited to general-purpose milling and provides adequate rigidity for machining common materials such as steel, aluminum, and cast iron. A 2003 machine listing confirms the 7.5 HP, 4,000 RPM configuration.

---

HAAS TM1 – 2003 – TOOLING

Specification	Details
Standard Tool Changer	None / Configuration Dependent
Tool Change	Manual / Configuration Dependent
Tool Taper	CAT 40
Tool Capacity	Configuration Dependent
Automatic Tool Changer	Optional
Tool Weight	Up to Approx. 12 lbs
Toolholding	40-Taper Tooling
Production Style	Toolroom / Prototype / Low Volume

The standard TM1 is a toolroom mill, but used 2003 machines can differ in equipment. One documented 2003 example is equipped with a 10-station tool changer, so the actual machine should be checked before listing the tooling configuration.

---

HAAS TM1 – 2003 – CONTROL SYSTEM

Specification	Details
CNC Control	Haas CNC Control
Programming	G-Code / Conversational
Conversational Programming	Yes
Intuitive Programming	Available
Program Memory	Approx. 1 MB on period configuration
Color LCD	Configuration Dependent
RS-232	Available
USB	Configuration Dependent
Rigid Tapping	Available
Digital Readout	Available

A documented 2003 TM1 was equipped with Haas conversational control, a 10-inch color LCD, dual RS-232 ports, rigid tapping, Visual Quick Code, and full CNC/manual operating modes.

---

HAAS TM1 – 2003 – FEEDRATES

Specification	Details
X-Axis Rapid Traverse	200 IPM / 5.1 m/min
Y-Axis Rapid Traverse	200 IPM / 5.1 m/min
Z-Axis Rapid Traverse	200 IPM / 5.1 m/min
Maximum Cutting Feedrate	200 IPM / 5.1 m/min
X-Axis Maximum Thrust	2,000 lbf / 8,896 N
Y-Axis Maximum Thrust	2,000 lbf / 8,896 N
Z-Axis Maximum Thrust	2,000 lbf / 8,896 N
Feedrate Override	Standard
Linear Interpolation	Yes
Circular Interpolation	Yes

Haas’ TM1 specifications list 200 IPM rapid rates and maximum cutting feedrate for X, Y, and Z.

---

HAAS TM1 – 2003 – COOLANT & CHIP MANAGEMENT

Specification	Details
Flood Coolant	Available
Coolant Pump	Available
Coolant Tank	Configuration Dependent
Programmable Coolant	Available
Chip Auger	Optional
Chip Conveyor	Configuration Dependent
Air Blast	Available
Through-Spindle Coolant	Optional
Coolant Filtration	Configuration Dependent
Mist Collector	Optional

A documented 2003 TM1 included an optional coolant system with tank and pump. Actual coolant and chip-management equipment varies between used machines.

---

HAAS TM1 – 2003 – AUTOMATION / PROBING

Specification	Details
Automatic Tool Changer	Optional / Configuration Dependent
Tool Capacity	Configuration Dependent
Work Probe	Optional
Tool Probe	Optional
4th-Axis Drive	Optional
4th-Axis Wiring	Optional
Rigid Tapping	Available
Rotary Table Integration	Available
Conversational Programming	Yes
Manual Operation	Available

One 2003 TM1 currently listed in the used market is configured as a 4-axis machine with a 10-station tool changer and 4th-axis drive.

---

HAAS TM1 – 2003 – POWER REQUIREMENTS

Specification	Details
Spindle Motor	7.5 HP / 5.6 kW
Electrical Input	Approx. 230 VAC
Electrical Service	Single- or Three-Phase, Configuration Dependent
Shop Air	Required
Air Requirement	Approx. 4 SCFM @ 100 PSI
Electrical Cabinet	Haas CNC
Industrial Power	Required

A documented 2003 machine is listed with 230-volt, three-phase electrical service, while Haas specifies single- or three-phase operation for the TM series depending on configuration.

---

HAAS TM1 – 2003 – DIMENSIONS

Specification	Details
Approximate Machine Length	55″
Approximate Machine Width	60″
Approximate Machine Height	87″
Approximate Machine Weight	4,200 lbs
Floor Space	Compact Toolroom Configuration
Installation	Industrial
Rigging	Required

A 2003 TM1 documented by Midwest Machinery is approximately 55 x 60 x 87 inches and weighs approximately 4,200 lbs. Individual machines can vary based on enclosure, coolant equipment, and other options.

---

HAAS TM1 – 2003 – GENERAL INFORMATION

Specification	Details
Manufacturer	Haas
Model	TM1
Year	2003
Machine Category	Vertical Machining Center
Machine Type	CNC Toolroom Mill
Axis Configuration	3-Axis / 4-Axis Capable
X-Axis Travel	30″
Y-Axis Travel	12″
Z-Axis Travel	16″
Table Size	47.75″ x 10.5″
Table Load	1,000 lbs
Spindle Speed	4,000 RPM
Spindle Power	7.5 HP
Spindle Taper	CAT 40
Maximum Feedrate	200 IPM
CNC Control	Haas CNC
Tool Changer	Configuration Dependent
4th-Axis Capability	Optional
Coolant	Configuration Dependent
Approx. Machine Weight	4,200 lbs

---

INDUSTRIES THAT USE HAAS TM1

The HAAS TM1 is suitable for:

• General machine shops
• Aerospace
• Automotive
• Defense
• Tool and die
• Mold manufacturing
• Prototype manufacturing
• Maintenance and repair
• Educational facilities
• Industrial machinery
• Contract manufacturing
• Precision engineering
• Small-batch production

---

TYPICAL PARTS HAAS TM1 CAN PRODUCE

The TM1 can produce:

• Brackets
• Mounting plates
• Fixtures
• Jigs
• Housings
• Flanges
• Tooling components
• Prototype parts
• Machine components
• Automotive components
• Aerospace components
• Industrial brackets
• Repair components
• Custom production parts

Typical operations include face milling, pocketing, contouring, drilling, boring, tapping, reaming, slotting, and 3-axis profiling.

---

WHY CHOOSE HAAS TM1

The main advantage of the HAAS TM1 is its combination of a 30 x 12 x 16-inch work envelope, 40-taper spindle, 7.5 HP motor, and compact footprint. It provides considerably more capability than a conventional manual toolroom mill while remaining relatively straightforward to operate.

The CAT 40 spindle provides useful rigidity for general machining, while the 4,000 RPM maximum speed is suitable for conventional milling applications.

The machine can also support rotary equipment, and some used 2003 examples were configured with a fourth axis. This can expand the machine’s capabilities for indexing, multi-sided machining, and more complex components.

---

WHY BUY USED HAAS TM1 – 2003

A used 2003 HAAS TM1 can be an economical way for a machine shop, maintenance department, or educational facility to add CNC milling capability.

The machine provides a useful 30-inch X-axis travel and 1,000-lb table capacity for its class. The 40-taper spindle and 7.5 HP motor make it suitable for a broad range of general-purpose machining work.

However, because this is a machine more than two decades old, condition should be prioritized over year. Buyers should inspect the spindle, ballscrews, linear guides, table, way covers, control electronics, drawbar, lubrication system, coolant system, and electrical cabinet.

A documented 2003 example had only 2,602 spindle hours, 2,580 motion hours, and 9,617 power-on hours, demonstrating why obtaining actual machine-hour data can make a major difference when evaluating an older TM1.

Buyers should also check axis backlash, spindle runout, spindle noise, positioning accuracy, servo alarms, control operation, and evidence of crashes.

---

HOW MUCH DOES A USED HAAS TM1 – 2003 COST?

Used pricing for a 2003 HAAS TM1 can vary considerably based on condition, hours, control generation, tooling, coolant equipment, tool changer, enclosure, and fourth-axis equipment.

Current used-market references include a 2003 TM1 listed as a 4-axis machine with a 10-station tool changer and 4th-axis drive, while another 2003 machine is described as a low-hour machine with 2,602 spindle hours and a 7.5 HP CAT 40 spindle.

For inventory valuation, I would use:

USED HAAS TM1 – 2003 PRICE RANGE	ESTIMATED COST
High Hours / Basic Configuration	$8,000 – $11,000
Functional Used Machine	$11,000 – $14,000
Good Condition / Production Ready	$14,000 – $17,000
Excellent / Well Equipped	$17,000 – $20,000
Low Hours / 4th Axis / Premium Configuration	$20,000+

For a 2003 HAAS TM1 in good working condition, I would estimate approximately $12,000–$17,000 USD.

For your inventory listing, I would recommend a practical asking-price range of $14,000–$17,000 USD for a clean, operational machine.

A low-hour machine with 4th-axis capability, tool changer, good spindle condition, coolant equipment, and complete tooling could potentially command $18,000–$21,000+.

A high-hour machine with significant backlash, spindle wear, outdated controls, or repair requirements could fall closer to $8,000–$12,000.

Best estimated listing value: $14,000–$17,000 USD.
