USED HAAS TM2P 2016

The HAAS TM2P 2016 is a 3-axis CNC toolroom mill designed for manufacturers that need the flexibility of a toolroom machine combined with the productivity and repeatability of CNC machining. Built by Haas Automation, the TM2P is well suited for job shops, prototype manufacturers, maintenance departments, tool and die shops, educational facilities, and small-batch production environments.

The 2016 HAAS TM2P provides 40″ X-axis travel, 16″ Y-axis travel, and 16″ Z-axis travel, giving it a long machining envelope that is particularly useful for plates, fixtures, tooling, molds, dies, brackets, and other elongated components. A documented 2016 machine is equipped with a 7.5 HP, 6,000 RPM CAT 40 spindle, while documented machines are available with either 10-station or 20-station automatic tool changers, depending on configuration.

The TM2P uses a long 57.75″ × 10.5″ table and provides a maximum spindle-to-table distance of approximately 20 inches. Its 400 IPM rapid traverse rates allow efficient movement between machining positions. The machine can also be configured with features such as a fourth-axis drive, rigid tapping, probing, programmable coolant, chip auger or conveyor, and Haas connectivity features.

For a used 2016 machine, the exact configuration should always be verified from the serial number and machine build sheet because options vary between individual machines.

HAAS TM2P 2016 – AXIS

The 40″ X-axis travel is a major advantage of the TM2P, giving it substantial capacity for long workpieces while retaining the compact characteristics of a toolroom mill.

HAAS TM2P 2016 – WORK ENVELOPE

The long table provides substantial room for vises, fixtures, rotary equipment, and long components. A documented 2016 TM2P lists a 57.75″ × 10.5″ table, while Haas specifications identify a maximum evenly distributed load of approximately 1,000 pounds.

HAAS TM2P 2016 – SPINDLE

The 2016 TM2P uses a 7.5 HP, 6,000 RPM, 40-taper belt-drive spindle. This configuration provides a practical combination of rigidity and versatility for general milling applications.

HAAS TM2P 2016 – TOOL CHANGER

The standard TM2P specification uses a 10-station carousel, although documented 2016 machines are also available with 20-tool automatic tool changers. Buyers should verify the exact ATC configuration of the individual machine.

HAAS TM2P 2016 – FEEDRATES

The 400 IPM rapid traverse rate allows the machine to move efficiently between cutting positions while maintaining the practical operating characteristics of the TM-series toolroom platform.

HAAS TM2P 2016 – CONTROL SYSTEM

Documented 2016 machines are available with features including Haas CNC control, 1 GB memory, Ethernet, HaasConnect, probing, and rigid tapping, depending on the machine’s installed options.

HAAS TM2P 2016 – COOLANT AND CHIP MANAGEMENT

Documented 2016 examples have been equipped with chip augers, chip conveyors, programmable coolant nozzles, and standard coolant systems. The actual equipment should be confirmed before purchasing a used machine.

HAAS TM2P 2016 – 4TH AXIS

Some documented 2016 TM2P machines include a 4th-axis drive and wiring, allowing the machine to operate with compatible Haas rotary tables. This can expand the machine’s capabilities for indexing, cylindrical machining, and multi-sided components.

HAAS TM2P 2016 – MACHINE DIMENSIONS

Dimensions can vary depending on enclosure, coolant, chip handling, and other installed options. One documented 2016 TM2P lists 100″ × 64″ × 86″ and approximately 4,000 pounds, while another machine listing gives shipping dimensions of approximately 3,260 × 2,240 × 2,490 mm.

HAAS TM2P 2016 – GENERAL INFORMATION

These represent the TM2P platform and documented 2016 configurations. Individual machines should be verified by serial number before listing or purchase.

INDUSTRIES THAT USE HAAS TM2P 2016

The HAAS TM2P is suitable for:

• General manufacturing
• Tool and die
• Aerospace
• Automotive
• Industrial machinery
• Maintenance and repair
• Mold making
• Fabrication
• CNC job shops
• Prototyping
• Educational facilities
• Small-batch production

Its long X-axis travel makes it especially useful for shops working with long plates, tooling, fixtures, and machine components.

TYPICAL PARTS HAAS TM2P 2016 CAN PRODUCE

The machine can produce:

• Tooling plates
• Fixtures
• Jigs
• Brackets
• Mounting plates
• Molds
• Dies
• Machine components
• Prototype parts
• Automotive components
• Aerospace components
• Industrial components
• Repair components

Typical operations include face milling, pocketing, drilling, tapping, boring, profiling, contouring, slotting, reaming, chamfering, and 3D surface machining.

WHY CHOOSE HAAS TM2P 2016

The main advantage of the HAAS TM2P 2016 is its combination of 40″ X-axis travel, CAT40 tooling, automatic tool changing, and CNC control in a relatively compact toolroom-style platform.

The 40″ × 16″ × 16″ travel envelope gives the TM2P substantial capacity for long workpieces, while the 57.75″ table provides ample room for fixtures and workholding.

The 7.5 HP, 6,000 RPM spindle is well suited to general-purpose milling, while CAT40 tooling is widely available and supported by a broad range of standard holders and cutting tools.

The TM2P can also be configured with valuable features such as 4th-axis drive, rigid tapping, probing, programmable coolant, chip auger, and HaasConnect, making a well-equipped used example considerably more versatile than a basic configuration.

WHY BUY USED HAAS TM2P 2016

Buying a used HAAS TM2P 2016 can provide a manufacturer or job shop with a capable CNC milling platform at a lower investment than purchasing new equipment.

The machine is particularly attractive to shops that need long X-axis travel but do not require the larger footprint or production-oriented architecture of a full-size VMC. Its 40″ X-axis capacity makes it useful for long tooling plates, fixtures, molds, dies, and industrial components.

A well-equipped 2016 machine can include 4th-axis drive, rigid tapping, probing, programmable coolant, chip auger or conveyor, and Haas CNC connectivity, providing additional value for shops handling diverse machining work.

When evaluating a used TM2P, buyers should inspect the spindle bearings, spindle taper, drawbar, belt-drive system, X/Y/Z ballscrews, linear guides, axis backlash, tool changer, CNC control, lubrication system, coolant system, chip-management equipment, and overall machine geometry.

A test cut should be performed whenever possible to evaluate positioning accuracy, repeatability, spindle vibration, surface finish, tool-changing operation, and axis movement.

HOW MUCH DOES A USED HAAS TM2P 2016 COST?

The price of a used HAAS TM2P 2016 depends on spindle hours, cutting hours, machine condition, installed options, tool changer configuration, fourth-axis equipment, probing, coolant and chip-management systems, tooling, and maintenance history.

Current and recent listings demonstrate that 2016 TM2P machines can have substantially different configurations. One documented example includes 4th-axis drive, rigid tapping, programmable coolant, and a 10-station tool changer, while another has a 20-tool ATC and chip auger.

For used-equipment listing purposes, a reasonable broad estimate for a used HAAS TM2P 2016 is approximately $20,000 to $35,000 USD, depending heavily on condition, hours, options, tooling, and location.

A low-hour machine with a healthy 6,000 RPM spindle, good Haas control, automatic tool changer, 4th-axis capability, probing, rigid tapping, programmable coolant, and good machine geometry can command a premium. Machines requiring spindle repairs, ballscrew service, tool-changer repairs, or control work can be worth considerably less.

Before establishing a final selling price, buyers should verify spindle hours, cutting hours, spindle condition, X/Y/Z-axis accuracy, ballscrew backlash, linear-guide condition, tool changer operation, drawbar condition, control functionality, fourth-axis operation, probing system, coolant and chip-management equipment, and overall machine geometry.
