USED DOOSAN LYNX 220G

The Doosan Lynx 220G is a high-speed gang-tool CNC lathe, specifically designed for small-part production, bar work, and high-volume manufacturing. Unlike the standard turret-based Lynx 220 models, the “G” variant uses a gang tooling layout, which significantly reduces tool change time and increases cycle efficiency.

This machine is a 2-axis CNC turning center (X and Z), optimized for simple, fast, and repetitive operations. It typically comes with a 6-inch chuck and a bar capacity of around 44–45 mm, making it ideal for precision components produced from bar stock.

The Lynx 220G offers a maximum turning diameter of ~165–170 mm and a turning length of approximately 300–320 mm, making it more compact and production-focused compared to turret models.

One of its standout features is the high-speed spindle (up to 6,000 RPM) powered by a ~20 HP motor, allowing for fast material removal and excellent surface finishes.

Equipped with FANUC i-Series CNC controls, linear guideways, and a rigid slant-bed design, the Lynx 220G is built for speed, repeatability, and reliability in mass production environments.

DOOSAN LYNX 220G SPECIFICATIONS

WHY BUY USED DOOSAN LYNX 220G

Buying a used Doosan Lynx 220G is ideal for shops focused on high-volume, small-part production where cycle time is critical. The gang tooling system eliminates turret indexing time, allowing tools to be pre-mounted and ready for immediate use.

This results in faster cycle times and higher throughput, especially in applications like:

• Bar-fed components
• Automotive fittings
• Small shafts and connectors
• Precision turned parts

Another major advantage is simplicity and reliability. With fewer moving components compared to turret machines, the Lynx 220G often has lower maintenance requirements and improved uptime.

The machine is also highly compatible with automation systems, including:

• Bar feeders
• Parts catchers
• Chip conveyors

Many used units already come equipped with LNS bar feeders and chip conveyors, making them ready for production immediately.

Additionally, the FANUC control system ensures easy programming, operator familiarity, and strong global support—reducing training time and service challenges.

HOW MUCH DOES A USED DOOSAN LYNX 220G COST?

The price of a used Doosan Lynx 220G typically ranges between $15,000 and $40,000, depending on condition, year, and included automation equipment.

• Lower range ($15K–$22K): Older machines (2005–2010), basic configuration
• Mid range ($22K–$30K): Good condition, with chip conveyor or tooling
• Higher range ($30K–$40K): Newer machines or those with bar feeders, automation, and full setups

Machines equipped with LNS bar feeders, chip conveyors, and tooling packages command higher prices due to their production-ready capability.

Overall, the Lynx 220G offers excellent ROI for high-volume machining, especially where speed and simplicity matter more than multi-axis flexibility.
