CITIZEN A20 TYPE VII – 2012

MAKE: CITIZEN

MODEL: A20VII

TYPE: Swiss Type Machine

YEAR: 2012

SKU: 111688

DEALER: Used CNC Exchange

COUNTRY: USA

USED CITIZEN A20 TYPE VII – 2012

The CITIZEN A20 Type VII is a compact 5-axis CNC Swiss-type sliding-headstock automatic lathe designed for high-volume precision production of small-diameter components. Manufactured by Citizen Machinery, the A20VII is built around a maximum machining diameter of 20 mm, with guide-bushing machining capability up to 200 mm in length. It can also operate in guide-bushing-less mode for shorter parts.

The 2012 A20VII is particularly useful for manufacturers producing small, intricate components where multiple turning, drilling, tapping, and cross-machining operations need to be completed automatically. A documented 2012 Citizen A20VII 2F7PL is equipped with a FANUC 32i CNC control, 8,000 RPM main spindle, 6,000 RPM rotary tooling, 21 tool positions, and live back-working tools.

The machine provides a 20 mm maximum machining diameter, 10 mm maximum front drilling diameter, M8 front tapping capacity, 7 mm rotary-tool drilling capacity, M6 rotary-tool tapping capacity, and an 8,000 RPM back spindle. Citizen’s specifications also show rapid traverse rates of up to 32 m/min on X2, Y, Z1, and Z2 axes.

CITIZEN A20 TYPE VII – AXIS

Specification	Details
Machine Type	CNC Swiss-Type Sliding Headstock Automatic Lathe
Axis Configuration	5-Axis
Control Groups	2-Line Control
X1 Axis	Main Machining
X2 Axis	Secondary Machining
Y Axis	Cross Machining
Z1 Axis	Main Spindle
Z2 Axis	Back Spindle
B Axis	Not Standard
C Axis	Spindle Interpolation / Configuration Dependent
Guide Bushing	Yes
Guide-Bushing-Less Capability	Yes

The A20VII uses a 5-axis, 2-line control architecture, allowing simultaneous or coordinated machining operations on the main and back spindle sides. Citizen specifically identifies the A20VII as a 5-axis sliding-headstock machine.

CITIZEN A20 TYPE VII – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
Maximum Machining Diameter	20 mm
Maximum Machining Diameter with Optional Package	Up to 25 mm
Guide-Bushing Machining Length	200 mm
Guide-Bushing-Less Machining Length	2.5D / Max. 55 mm
Main Spindle Drilling Diameter	10 mm
Rotary Tool Drilling Diameter	7 mm
Back Machining Drilling Diameter	8 mm
Back Spindle Workpiece Projection	50 mm
Center Height	1,050 mm

The standard A20VII is designed around 20 mm bar capacity, although Citizen states that an optional 25 mm chuck device can allow bar stock up to 25 mm diameter.

CITIZEN A20 TYPE VII – CAPACITY / WORKHOLDING

Specification	Details
Maximum Bar / Machining Diameter	20 mm
Optional Diameter Package	25 mm
Guide-Bushing Length	200 mm
Guide-Bushing-Less Length	Max. 55 mm
Back Spindle Chuck Diameter	20 mm
Back Spindle Workpiece Projection	50 mm
Main Spindle Workholding	Guide Bushing / Collet
Back Spindle Workholding	Chuck / Collet
Bar Stock	Small-Diameter Precision Work

The A20VII is primarily intended for small-diameter bar work, making it particularly appropriate for precision components requiring excellent support close to the cutting zone.

CITIZEN A20 TYPE VII – SPINDLE

Specification	Details
Main Spindle Type	Sliding-Headstock Spindle
Maximum Main Spindle Speed	10,000 RPM
Typical 2012 Configuration	8,000 RPM
Main Spindle Motor	2.2 / 3.7 kW
Main Spindle Power	Approx. 3.7 kW / 5 HP
Main Spindle Diameter Capacity	20 mm
Back Spindle Speed	Up to 8,000 RPM
Back Spindle Motor	1.1 / 1.5 kW
Back Spindle Chuck Diameter	20 mm

Citizen’s current A20VII specifications identify a maximum main spindle speed of 10,000 RPM, while a documented 2012 A20VII is specified at 8,000 RPM.

The high spindle speed is well suited to small-diameter components and materials where maintaining appropriate surface speed requires substantial RPM.

CITIZEN A20 TYPE VII – TOOLING / TOOL CAPACITY

Specification	Details
Total Tool Positions	21
Turning Tool Size	12 mm Square
Optional Turning Tool Sizes	13 mm / 16 mm Square
Main Spindle Front Drilling	4 Tool Positions
Cross Machining Rotary Tools	4 Tool Positions
Back Drilling	8 Tool Positions
Gang Turning Tools	5 Positions
Rotary Tool Speed	Up to 6,000 RPM
Rotary Tool Rated Speed	4,800 RPM
Tool Change	Automatic / Gang Tooling Configuration

The A20VII can accommodate 21 tools, allowing multiple turning, drilling, tapping, and back-working operations to be programmed into a single setup.

CITIZEN A20 TYPE VII – CONTROL SYSTEM

Specification	Details
CNC Control	FANUC 32i
Control Type	CNC Swiss Turning Control
Control Axis	5-Axis
Control Groups	2-Line
Programming	G-Code / CNC
Main Spindle Control	CNC
Back Spindle Control	CNC
Tool Offset Management	Standard
Threading / Tapping Cycles	Available
Data Transfer	Configuration Dependent

A documented 2012 A20VII uses a FANUC 32i CNC control, which is a useful feature when evaluating a used machine because it provides a familiar CNC platform for many production shops.

CITIZEN A20 TYPE VII – FEEDRATES

Specification	Details
X1 Rapid Traverse	18 m/min
X2 Rapid Traverse	32 m/min
Y Rapid Traverse	32 m/min
Z1 Rapid Traverse	32 m/min
Z2 Rapid Traverse	32 m/min
X1 Rapid	Approx. 709 IPM
X2 Rapid	Approx. 1,260 IPM
Y Rapid	Approx. 1,260 IPM
Z1 Rapid	Approx. 1,260 IPM
Z2 Rapid	Approx. 1,260 IPM

Citizen lists rapid traverse rates of 18 m/min for X1 and 32 m/min for X2, Y, Z1, and Z2.

CITIZEN A20 TYPE VII – COOLANT / CHIP MANAGEMENT

Specification	Details
Cutting Coolant	Equipped
Coolant Pump Motor	0.4 kW
High-Pressure Coolant	Optional / Configuration Dependent
Mist Collector	Configuration Dependent
Coolant Filtration	Configuration Dependent
Chip Management	Integrated
Chip Conveyor	Configuration Dependent
Coolant Type	Oil / Configuration Dependent

A documented 2012 A20VII is equipped with a Cool Blaster CB510 high-pressure coolant system and Cool Blaster 850 mist collector, demonstrating the availability of enhanced coolant and mist-management packages on this machine.

CITIZEN A20 TYPE VII – PROBING & AUTOMATION OPTIONS

Specification	Details
Bar Feeder	Available / Common
Bar Feed System	Automatic
Back Spindle	Equipped
Guide Bushing	Equipped / Configuration Dependent
Guide-Bushing-Less Operation	Available
Parts Transfer	Back Spindle
Mist Collector	Optional
High-Pressure Coolant	Optional
Parts Catcher	Configuration Dependent
Automatic Production	Yes

A documented 2012 machine includes an Edge Technologies C-320 magazine bar feed, allowing automatic feeding of bar stock for extended production runs.

CITIZEN A20 TYPE VII – POWER REQUIREMENTS

Specification	Details
Rated Power Consumption	7.1 kVA
Average Load Operation	4.1 kVA
Main Spindle Motor	2.2 / 3.7 kW
Rotary Tool Motor	0.75 kW
Back Spindle Motor	1.1 / 1.5 kW
Coolant Pump Motor	0.4 kW
Electrical Service	Industrial 3-Phase
Exact Voltage	Verify Machine Data Plate

Citizen lists 7.1 kVA rated power consumption and 4.1 kVA average power consumption under load for the A20VII.

CITIZEN A20 TYPE VII – DIMENSIONS

Specification	Details
Approximate Length	8.5 ft
Approximate Width	5.8 ft
Approximate Height	6 ft
Approximate Weight	5,600 lbs
Metric Weight	Approx. 2,200 kg
Center Height	1,050 mm
Floor Space	Compact
Installation	Production Machine

A documented 2012 A20VII measures approximately 8.5 ft x 5.8 ft x 6 ft and weighs approximately 5,600 lbs. Citizen’s published specification gives a weight of approximately 2,200 kg.

CITIZEN A20 TYPE VII – GENERAL INFORMATION

Specification	Details
Manufacturer	Citizen Machinery
Model	A20 Type VII / A20VII
Year	2012
Machine Category	CNC Swiss-Type Lathe
Machine Type	Sliding-Headstock Automatic CNC Lathe
Axis Configuration	5-Axis
Maximum Machining Diameter	20 mm
Optional Diameter Capacity	Up to 25 mm
Guide-Bushing Length	200 mm
Guide-Bushing-Less Length	Max. 55 mm
Main Spindle Speed	Up to 10,000 RPM
Back Spindle Speed	Up to 8,000 RPM
Tool Capacity	21
Control	FANUC 32i
Weight	Approx. 5,600 lbs

INDUSTRIES THAT USE CITIZEN A20 TYPE VII

The CITIZEN A20 TYPE VII is particularly suited to industries requiring high-volume production of small precision components.

Typical industries include medical, automotive, electronics, aerospace, instrumentation, electrical, hydraulic, precision engineering, and general contract manufacturing.

Its sliding-headstock architecture provides excellent support for small-diameter material, while the back spindle allows components to be transferred automatically for secondary operations.

This makes the A20VII particularly useful when manufacturers want to complete several operations in one automated cycle rather than transferring small parts between multiple machines.

TYPICAL PARTS CITIZEN A20 TYPE VII CAN PRODUCE

The A20VII can produce:

Medical components
Bone screws and orthopedic components
Automotive pins
Shafts
Precision bushings
Small fittings
Connectors
Electronic components
Instrument components
Threaded pins
Small valve components
Hydraulic fittings
Precision fasteners
Small aerospace components
Micro-machined industrial components

Typical operations include turning, facing, grooving, threading, drilling, tapping, cross drilling, back drilling, boring, chamfering, and secondary-end machining.

WHY CHOOSE CITIZEN A20 TYPE VII

The primary advantage of the CITIZEN A20 TYPE VII is its ability to produce small, complex parts with multiple operations in a single automated cycle.

The machine provides 5-axis capability, a main spindle capable of up to 10,000 RPM, an 8,000 RPM back spindle, 21 tool positions, and guide-bushing machining up to 200 mm.

The back spindle is especially useful for completing secondary operations without removing the component from the machine. This can reduce handling, improve consistency, and shorten cycle times.

The A20VII can also operate without a guide bushing for shorter parts, providing additional production flexibility. Citizen identifies guide-bushing-less machining up to 2.5D, with a maximum of 55 mm.

For shops producing large quantities of small precision components, the A20VII can provide excellent productivity in a relatively compact machine footprint.

WHY BUY USED CITIZEN A20 TYPE VII

Buying a used CITIZEN A20 TYPE VII can be an economical way for a manufacturer to add Swiss-style CNC production capacity without purchasing a new machine.

The A20VII’s combination of 5-axis machining, main and back spindle operation, 21 tool positions, high spindle speeds, and automatic bar feeding capability makes it well suited to unattended or high-volume production.

A documented 2012 machine includes a FANUC 32i control, Edge Technologies C-320 magazine bar feeder, Cool Blaster high-pressure coolant, mist collector, and tooling, demonstrating how a used A20VII can be configured as a complete production cell.

When evaluating a used A20VII, buyers should inspect the main spindle, back spindle, guide bushing, spindle bearings, gang tooling, cross-working tools, X/Y/Z axis positioning, ballscrews, coolant system, bar feeder, FANUC control, lubrication system, and machine geometry.

For Swiss machines, it is especially important to check guide-bushing condition and alignment, because these directly affect the support of small-diameter bar stock and the quality of finished parts.

HOW MUCH DOES A USED CITIZEN A20 TYPE VII COST?

Used pricing for the CITIZEN A20 TYPE VII varies according to year, machine hours, spindle condition, control, bar feeder, tooling, guide-bushing equipment, high-pressure coolant, and overall production condition.

A documented 2012 Citizen A20VII 2F7PL has been sold and was equipped with a FANUC 32i control, Cool Blaster 850 mist collector, Edge Technologies C-320 magazine bar feeder, lubrication system, and tooling. The listing does not publish a final transaction price.

Another 2012 A20VII listing includes a FANUC 32i, Cool Blaster CB510 high-pressure coolant system, C-320 magazine bar feed, and tooling, also with pricing available by quote.

Based on the used market for this class of Citizen Swiss machine, I would use the following practical estimates:

USED CITIZEN A20 TYPE VII PRICE RANGE	ESTIMATED COST
As-Is / High-Hour / Needs Work	$25,000 – $40,000
Functional Used Machine	$40,000 – $55,000
Good Condition / Production Ready	$55,000 – $70,000
Excellent Condition / Well Equipped	$70,000 – $85,000+

For a 2012 CITIZEN A20 TYPE VII in good working condition, a reasonable estimated used-market value is approximately $45,000–$70,000 USD.

A machine with a FANUC 32i control, automatic bar feeder, high-pressure coolant, mist collector, good tooling package, and documented maintenance would generally fall toward the upper portion of that range.

For your inventory listing, I would use $50,000–$70,000 USD as a practical estimated asking-price range for a clean, operational 2012 A20VII with a bar feeder and production accessories.

The exact value should be adjusted based on power-on hours, cutting hours, guide-bushing condition, spindle condition, bar feeder, tooling, coolant package, and whether the machine can be demonstrated under power.
