USED OKUMA GENOS L400 – 2013

The Okuma GENOS L400 is a powerful CNC turning center designed for manufacturers that require heavy-duty turning capability, high precision, and long-term reliability. Built by Okuma, one of Japan’s most respected machine tool manufacturers, the GENOS L400 combines rigid machine construction, advanced spindle technology, and a user-friendly CNC control platform to deliver exceptional performance across a wide range of industries. The GENOS Series was developed to provide manufacturers with a cost-effective solution that maintains the quality, accuracy, and durability associated with the Okuma brand.

The GENOS L400 is designed for turning, facing, boring, threading, grooving, drilling, and production machining applications. Its slant-bed design improves rigidity and chip evacuation while providing excellent thermal stability during long machining cycles. The machine is capable of processing steel, stainless steel, aluminum, cast iron, titanium, brass, bronze, and various exotic alloys commonly found in aerospace, energy, and industrial manufacturing applications.

A typical 2013 Okuma GENOS L400 features a maximum turning diameter of approximately 16.5 inches and a maximum turning length of approximately 20 inches. Most machines are equipped with a 10-inch or 12-inch hydraulic chuck and a spindle capable of speeds up to 3,000 RPM. The machine commonly includes a 12-station servo turret and utilizes the highly regarded Okuma OSP control system. This combination provides exceptional machining flexibility while maintaining the accuracy required for demanding production environments.

Manufacturers in aerospace, automotive, energy, oil and gas, defense, hydraulic systems, industrial equipment, agricultural machinery, and contract machining regularly utilize the GENOS L400. Its ability to handle larger workpieces while maintaining tight tolerances makes it an excellent choice for both job shops and production facilities.

One of the key reasons the 2013 Okuma GENOS L400 remains highly sought after in the used CNC machine market is its reputation for reliability and low cost of ownership. Many machines continue operating productively for years after installation, providing excellent return on investment while maintaining strong resale value.

---

OKUMA GENOS L400 – AXIS

Specification	Value
Number of Axes	2 Axis
Simultaneous Axis Control	2 Axis
Positioning Type	CNC Controlled

---

OKUMA GENOS L400 – AXIS TRAVELS / WORK ENVELOPE

Specification	Value
X-Axis Travel	10.2″
Z-Axis Travel	22.0″
Maximum Turning Diameter	16.5″
Maximum Turning Length	20.0″

---

OKUMA GENOS L400 – CAPACITY

Specification	Value
Chuck Size	10″ – 12″
Swing Over Bed	22.8″
Maximum Turning Diameter	16.5″
Maximum Turning Length	20.0″
Bar Capacity	3.0″

---

OKUMA GENOS L400 – SPINDLE

Specification	Value
Spindle Speed	3,000 RPM
Spindle Bore	3.5″
Spindle Motor	30 HP
Spindle Nose	A2-8
Drive Type	Direct Drive

---

OKUMA GENOS L400 – TOOL CHANGER

Specification	Value
Turret Capacity	12 Stations
Turret Type	Servo Turret
Tool Selection	Bidirectional
Live Tooling	Optional
Index Time	Fast Servo Indexing

---

OKUMA GENOS L400 – CONTROL SYSTEM

Specification	Value
CNC Control	Okuma OSP-P200L
Programming Capability	G-Code
Conversational Programming	IGF Available
Ethernet Connectivity	Standard
USB Support	Standard

---

OKUMA GENOS L400 – COOLANT / DUST / WATER MANAGEMENT

Specification	Value
Coolant System	Flood Coolant
High Pressure Coolant	Optional
Chip Conveyor	Optional
Coolant Filtration	Standard
Enclosure	Full Enclosure

---

OKUMA GENOS L400 – POWER REQUIREMENTS

Specification	Value
Voltage	220V / 440V
Phase	3 Phase
Power Requirement	Approx. 35 KVA
Air Requirement	Shop Air Required

---

OKUMA GENOS L400 – DIMENSIONS

Specification	Value
Length	Approx. 130″
Width	Approx. 80″
Height	Approx. 85″
Weight	Approx. 12,500 lbs

---

OKUMA GENOS L400 – GENERAL INFORMATION

Specification	Value
Manufacturer	Okuma
Machine Type	CNC Turning Center
Year	2013
Construction	Slant Bed
Country of Origin	Japan

---

INDUSTRIES THAT USE OKUMA GENOS L400

The Okuma GENOS L400 is widely used in industries that require precision turning, high productivity, and dependable machine performance.

Industries commonly utilizing the GENOS L400 include:

• Aerospace Manufacturing
• Automotive Manufacturing
• Defense Manufacturing
• Oil and Gas Manufacturing
• Energy Industry Suppliers
• Hydraulic Component Manufacturing
• Agricultural Equipment Manufacturing
• Heavy Equipment Manufacturing
• Contract Machining
• Industrial Equipment Manufacturing
• Fluid Power Industry
• Robotics Manufacturing
• Precision Engineering Companies
• Tool Manufacturing
• General Machine Shops

Its large turning capacity and robust construction make it ideal for both medium-sized and larger workpiece applications.

---

TYPICAL PARTS OKUMA GENOS L400 CAN PRODUCE

The Okuma GENOS L400 is capable of producing a wide range of precision-machined turned components.

Typical parts include:

• Hydraulic Shafts
• Valve Bodies
• Bearing Housings
• Pump Components
• Flanges
• Couplings
• Aerospace Bushings
• Threaded Components
• Energy Industry Parts
• Gear Blanks
• Drive Components
• Agricultural Equipment Parts
• Heavy Equipment Components
• Fluid Power Components
• Pneumatic Components
• Robotics Parts
• Industrial Machine Components
• OEM Production Parts
• Repair Components
• Custom Turned Parts

The machine’s rigidity allows efficient roughing operations while maintaining the accuracy required for finishing applications.

---

WHY CHOOSE OKUMA GENOS L400

The Okuma GENOS L400 is highly regarded because it delivers the durability and precision associated with premium Japanese machine tools while maintaining excellent productivity. Manufacturers frequently choose the GENOS L400 because it provides dependable machining performance across a broad range of materials and applications.

One of the machine’s primary advantages is its rigid slant-bed construction. This design improves machining stability, reduces vibration, and enhances chip evacuation. The result is improved surface finish quality, longer tool life, and more consistent dimensional accuracy throughout production runs.

The machine’s spindle platform is another major strength. With substantial horsepower and torque, the GENOS L400 can efficiently handle heavy cutting operations while maintaining excellent performance during finishing operations. This versatility allows manufacturers to utilize the machine for a wide variety of part types.

The Okuma OSP control system further enhances machine performance. Known throughout the industry for reliability and user-friendly operation, the OSP platform provides advanced diagnostics, conversational programming capabilities, and strong long-term support.

Another important advantage is machine longevity. Okuma equipment is widely recognized for long service life and excellent resale value. Many GENOS L400 machines continue operating productively for decades when properly maintained.

For manufacturers seeking a reliable turning center capable of handling demanding production workloads, the Okuma GENOS L400 remains an excellent investment.

---

WHY BUY USED OKUMA GENOS L400

Purchasing a used 2013 Okuma GENOS L400 provides manufacturers with access to premium CNC turning technology at a significantly lower cost than purchasing a new machine. Because Okuma machines are known for durability and long-term reliability, many used GENOS L400 machines continue delivering outstanding production performance years after their original installation.

One of the biggest advantages is cost savings. A used GENOS L400 can often be purchased for a fraction of the cost of a comparable new CNC turning center while still providing excellent spindle performance, advanced controls, and robust construction. This allows manufacturers to expand capacity without making a major capital investment.

The machine’s proven reliability is another key benefit. Many shops actively seek used Okuma equipment because of its reputation for low maintenance costs and dependable operation. Properly maintained machines often continue producing precision components for many years with minimal downtime.

Many used machines are equipped with valuable options such as chip conveyors, parts catchers, tool presetters, high-pressure coolant systems, upgraded chucks, and tooling packages. Purchasing these options with a used machine can provide substantial value and reduce setup costs.

The versatility of the GENOS L400 further increases its appeal. Whether producing prototypes, small production batches, or high-volume runs, the machine can adapt to changing manufacturing requirements. This flexibility helps maximize machine utilization and improve overall productivity.

For manufacturers seeking strong return on investment, reliable performance, and premium Japanese machine quality, the used Okuma GENOS L400 remains one of the most attractive options available in today’s used CNC equipment market.

---

HOW MUCH DOES A USED OKUMA GENOS L400 COST?

A used 2013 Okuma GENOS L400 typically sells for between $45,000 and $95,000, depending on machine condition, spindle hours, maintenance history, tooling packages, and installed options.

Machines near the lower end of the price range generally have higher operating hours, basic configurations, or fewer accessories. Machines near the upper end often include upgraded workholding systems, chip conveyors, tooling packages, high-pressure coolant systems, parts catchers, and comprehensive maintenance documentation.

Machine condition remains the most important factor affecting market value. Buyers typically evaluate spindle performance, turret accuracy, machine geometry, lubrication systems, hydraulic systems, and overall operational condition. Machines with documented service histories and lower spindle hours generally command higher prices because they present lower ownership risk.

Tooling and accessories can significantly impact final pricing. Collet systems, chucks, tool holders, boring bars, spare tooling packages, and workholding equipment can add thousands of dollars to the total machine package value.

Regional manufacturing demand also influences pricing. Areas with strong aerospace, automotive, energy, and industrial manufacturing sectors often maintain higher demand for robust turning centers such as the GENOS L400.

Compared to purchasing a new CNC turning center, a used 2013 Okuma GENOS L400 offers substantial savings while still delivering exceptional machining capability, proven reliability, and strong long-term value. For manufacturers seeking a dependable production lathe capable of handling demanding turning applications, the GENOS L400 remains one of the strongest investments available in the used CNC equipment marketplace.
