Used MORI SEIKI NL1500/500 - 2005 - CNC Machine For Sale - USA
MORI SEIKI NL1500/500 – 2005

MORI SEIKI NL1500/500 – 2005

MAKE: MORI SEIKI
MODEL: NL1500/500
TYPE: Lathe
YEAR: 2005
SKU: 111905
COUNTRY: USA

USED MORI SEIKI NL1500/500 – 2005

The MORI SEIKI NL1500/500 – 2005 is a CNC horizontal turning center designed for precision turning, facing, boring, threading, grooving, and other production machining operations. The NL1500 platform is part of Mori Seiki’s widely used NL series, developed to provide rigid construction, reliable spindle performance, and accurate CNC turning for a broad range of industrial applications.

The /500 designation identifies the approximate 500 mm class turning length configuration, making this machine suitable for small- to medium-sized components. Its compact footprint and capable work envelope make it useful for both production environments and job shops that require flexibility.

The NL1500/500 is typically equipped with a hydraulic chuck, automatic turret, CNC control, programmable tailstock, coolant system, and automatic lubrication. Depending on the individual machine, options can include a chip conveyor, bar feeder, parts catcher, tooling package, and high-pressure coolant.

A 2005 NL1500/500 remains useful for manufacturers producing shafts, bushings, flanges, fittings, hydraulic components, valve components, automotive parts, and general industrial components. The machine can perform conventional turning operations as well as threading, grooving, boring, drilling, and other secondary operations depending on configuration.

For buyers looking for an affordable used CNC lathe, the MORI SEIKI NL1500/500 – 2005 offers a combination of compact size, rigid construction, proven CNC technology, and practical production capability.

MORI SEIKI NL1500/500 – 2005 – AXIS

SpecificationDetails
Machine TypeCNC Horizontal Turning Center
Axis Configuration2-Axis
X-Axis TravelApprox. 260 mm / 10.2″
Z-Axis TravelApprox. 500 mm / 19.7″
X-Axis Rapid TraverseApprox. 20 m/min
Z-Axis Rapid TraverseApprox. 24 m/min
C-AxisConfiguration Dependent
TailstockProgrammable
Linear GuidesHeavy-Duty
Automatic OperationStandard

MORI SEIKI NL1500/500 – 2005 – WORK ENVELOPE

SpecificationDetails
Swing Over BedApprox. 650 mm / 25.6″
Maximum Turning DiameterApprox. 366 mm / 14.4″
Maximum Turning LengthApprox. 500 mm / 19.7″
Chuck SizeApprox. 8″
Spindle BoreApprox. 2.6″
Bar CapacityApprox. 2.1″
TailstockProgrammable
Steady RestOptional
Workpiece SupportChuck / Tailstock
Production TurningSupported

MORI SEIKI NL1500/500 – 2005 – SPINDLE

SpecificationDetails
Spindle TypeCNC Horizontal Turning Spindle
Spindle MotorApprox. 15 HP
Maximum Spindle SpeedApprox. 5,000 RPM
Spindle BoreApprox. 2.6″
Spindle NoseA2-6 / Configuration Dependent
ChuckHydraulic
C-AxisConfiguration Dependent
Constant Surface SpeedStandard
Spindle OrientationStandard
Bar WorkSupported

The spindle is designed to provide a balance of speed and torque for general-purpose production turning.

MORI SEIKI NL1500/500 – 2005 – CHUCK & WORKHOLDING

SpecificationDetails
Chuck TypeHydraulic 3-Jaw
Chuck SizeApprox. 8″
Hydraulic ClampingStandard
Soft JawsSupported
Hard JawsSupported
Collet SystemOptional
Steady RestOptional
TailstockProgrammable
QuillHydraulic
Bar WorkSupported

MORI SEIKI NL1500/500 – 2005 – TURRET

SpecificationDetails
Turret TypeAutomatic Disc Turret
Tool StationsApprox. 10–12
Turning ToolsSupported
Boring BarsSupported
Driven ToolsConfiguration Dependent
Tool IndexingAutomatic
Hydraulic ClampingStandard
Tool Offset ManagementCNC Controlled
Tool-Life ManagementAvailable
Tool MonitoringAvailable

MORI SEIKI NL1500/500 – 2005 – CONTROL SYSTEM

SpecificationDetails
CNC ControlMORI SEIKI MSX / FANUC Configuration
DisplayColor LCD
ProgrammingG-Code / ISO
Tool Offset ManagementStandard
Work Offset ManagementStandard
Constant Surface SpeedStandard
Custom MacrosAvailable
DiagnosticsStandard
Tool-Life ManagementAvailable
Data TransferConfiguration Dependent

The exact control configuration should be verified on the individual machine because control options varied depending on the original factory specification.

MORI SEIKI NL1500/500 – 2005 – FEEDRATES

SpecificationDetails
X-Axis Rapid TraverseApprox. 20 m/min
Z-Axis Rapid TraverseApprox. 24 m/min
Cutting FeedrateProgrammable
Feedrate OverrideStandard
Linear InterpolationYes
Circular InterpolationYes
Threading FeedProgrammable
Servo DrivesAC Servo
High-Speed PositioningStandard
Automatic CompensationAvailable

MORI SEIKI NL1500/500 – 2005 – COOLANT & CHIP MANAGEMENT

SpecificationDetails
Flood CoolantStandard
Coolant TankStandard
Coolant PumpStandard
High-Pressure CoolantOptional
Chip ConveyorAvailable
Chip AugerConfiguration Dependent
Coolant FiltrationStandard
Mist CollectorOptional
Oil SkimmerOptional
Automatic LubricationStandard

MORI SEIKI NL1500/500 – 2005 – AUTOMATION

SpecificationDetails
Automatic Tool ChangerTurret
Hydraulic ChuckStandard
Programmable TailstockAvailable
Parts CatcherOptional
Bar FeederAvailable
Steady RestOptional
Tool PresetterOptional
Chip ConveyorAvailable
Automatic LubricationStandard
Lights-Out ProductionSupported

MORI SEIKI NL1500/500 – 2005 – POWER REQUIREMENTS

SpecificationDetails
Spindle MotorApprox. 15 HP
Electrical ServiceThree-Phase
Input VoltageConfiguration Dependent
Frequency50 / 60 Hz
Shop AirRequired
Hydraulic SystemStandard
Lubrication SystemAutomatic
Electrical CabinetMori Seiki
InstallationIndustrial

MORI SEIKI NL1500/500 – 2005 – DIMENSIONS

SpecificationDetails
Machine WidthApprox. 105–115″
Machine DepthApprox. 75–85″
Machine HeightApprox. 75–80″
Machine WeightApprox. 9,000–11,000 lbs
Floor SpaceMedium
Chip ConveyorAdds Overall Length
Bar FeederAdds Overall Length
RiggingRequired
InstallationIndustrial

MORI SEIKI NL1500/500 – 2005 – GENERAL INFORMATION

SpecificationDetails
ManufacturerMori Seiki
ModelNL1500/500
Year2005
Machine CategoryCNC Horizontal Turning Center
Axis Configuration2-Axis
Maximum Turning DiameterApprox. 366 mm
Maximum Turning LengthApprox. 500 mm
Swing Over BedApprox. 650 mm
Chuck SizeApprox. 8″
Spindle BoreApprox. 2.6″
Maximum Spindle SpeedApprox. 5,000 RPM
Spindle PowerApprox. 15 HP
TurretAutomatic
TailstockProgrammable
CNC ControlMORI SEIKI / FANUC Configuration

INDUSTRIES THAT USE MORI SEIKI NL1500/500

The MORI SEIKI NL1500/500 is well suited for:

  • Automotive
  • Aerospace
  • Medical
  • Oil & Gas
  • Hydraulics
  • Industrial Machinery
  • General Manufacturing
  • Precision Engineering
  • Electrical Equipment
  • Contract Machining
  • Job Shops
  • Component Manufacturing

TYPICAL PARTS MORI SEIKI NL1500/500 CAN PRODUCE

Typical components include:

  • Shafts
  • Bushings
  • Flanges
  • Hydraulic fittings
  • Valve components
  • Pump components
  • Couplings
  • Pins
  • Spacers
  • Automotive components
  • Precision machine components
  • Industrial fittings

Typical operations include turning, facing, boring, threading, grooving, drilling, chamfering, taper turning, and contour turning.

WHY CHOOSE MORI SEIKI NL1500/500

The primary advantage of the MORI SEIKI NL1500/500 is its combination of compact size, rigid construction, accurate axis movement, and practical turning capacity.

The 500 mm-class machining length is appropriate for a large range of common production components without requiring the floor space or power consumption of a larger heavy-duty turning center. Its automatic turret allows multiple tools to be used during a single machining cycle, reducing setup and operator intervention.

Mori Seiki machines are also known for their robust mechanical construction and suitability for continuous industrial production. For job shops, the NL1500/500 provides a useful balance between workpiece capacity and machine size.

WHY BUY USED MORI SEIKI NL1500/500 – 2005

A used 2005 MORI SEIKI NL1500/500 can be an economical way to add CNC turning capacity without purchasing a new machine.

When evaluating a used NL1500/500, inspect the spindle bearings, chuck, turret, ballscrews, linear guideways, tailstock, hydraulic system, coolant system, and CNC control.

Buyers should verify spindle runout, spindle hours, chuck clamping pressure, turret indexing accuracy, axis backlash, tailstock alignment, machine geometry, and maintenance history.

Machines equipped with a chip conveyor, bar feeder, parts catcher, high-pressure coolant, tooling package, and complete workholding can provide additional production value.

HOW MUCH DOES A USED MORI SEIKI NL1500/500 – 2005 COST?

The market value of a used MORI SEIKI NL1500/500 – 2005 depends on machine condition, spindle hours, control configuration, tooling, automation equipment, and maintenance history.

USED MORI SEIKI NL1500/500 – 2005 PRICE RANGEESTIMATED COST
High Hours / Basic Configuration$20,000 – $28,000
Functional Production Machine$28,000 – $35,000
Good Condition / Production Ready$35,000 – $45,000
Excellent / Well Equipped$45,000 – $55,000
Low Hours / Fully Equipped$55,000 – $65,000+

For a 2005 MORI SEIKI NL1500/500 in good working condition, a realistic market value is approximately $30,000–$45,000 USD.

For your inventory listing, a recommended asking-price range is $38,000–$50,000 USD for a clean machine equipped with hydraulic chuck, programmable tailstock, chip conveyor, bar feeder, tooling, and documented maintenance history.

Best estimated listing value: $38,000–$50,000 USD.
