USED MILLTRONICS ML-16 - 2007 - CNC Machine For Sale - USA
MILLTRONICS ML-16 – 2007

MILLTRONICS ML-16 – 2007

MAKE: MILLTRONICS
MODEL: ML-16
TYPE: Lathe
YEAR: 2007
SKU: 112051
DEALER: Trader Machinery, Inc.
COUNTRY: USA

USED MILLTRONICS ML-16 – 2007

The MILLTRONICS ML-16 – 2007 is a CNC flat-bed turning lathe designed for precision turning, facing, boring, threading, drilling, and general-purpose machining. Its large work envelope and long Z-axis travel make it particularly useful for job shops and manufacturers that need to machine longer cylindrical components.

The 2007 ML-16 provides approximately 11 inches of X-axis travel and 44.5 inches of Z-axis travel, with a maximum center distance of approximately 48 inches. The machine has a swing over the ways of approximately 17 inches, while documented 2007 configurations also show approximately 25.9 inches of swing over the gap.

The machine is equipped with a Centurion 7 CNC control, a spindle speed range of approximately 100 to 4,000 RPM, and a 10/12 HP spindle drive. A documented 2007 example includes an 8-inch 3-jaw chuck, tailstock, live center, steady rest, and a 6-station turret.

With approximately 40 inches of machining length, a 2.04-inch spindle through-hole/bar capacity, and a substantial flat-bed design, the ML-16 is well suited for producing shafts, bushings, spacers, pins, sleeves, tooling components, and other medium-to-long turned parts.

MILLTRONICS ML-16 – 2007 – AXIS

SpecificationValue
Machine TypeCNC Flat-Bed Turning Lathe
Number of Axes2
X-Axis Travel11″
Z-Axis Travel44.5″
CNC ControlCenturion 7
SpindleMain Turning Spindle
C-AxisNo
Y-AxisNo
Live ToolingNo
TailstockYes
Turret6 Station on documented machine

The ML-16 is primarily a 2-axis CNC turning machine. Its configuration emphasizes turning capacity, long travel, straightforward programming, and accessibility rather than multi-axis milling or live-tool machining.

MILLTRONICS ML-16 – 2007 – AXIS TRAVELS / WORK ENVELOPE

SpecificationValue
X-Axis Travel11″
Z-Axis Travel44.5″
Maximum Center Distance48″
Swing Over Ways17″
Swing Over BedApprox. 17.5″
Swing Over Cross Slide7.48″
Swing Over Gap25.9″
Gap Length12.75″
Machining LengthApprox. 40″
Rapid Traverse X/Z500 IPM

The long Z-axis travel is one of the ML-16’s key advantages. The machine can accommodate substantially longer workpieces than compact CNC lathes, while the gap-bed arrangement provides additional clearance for larger-diameter work.

MILLTRONICS ML-16 – 2007 – CAPACITY

SpecificationValue
Chuck Size8″
Bar Capacity2.04″
Maximum Center Distance48″
Swing Over Ways17″
Swing Over Gap25.9″
Gap Length12.75″
TailstockYes
Tailstock Quill Travel6″
Tailstock Quill TaperMT4
Workholding8″ 3-Jaw Chuck
Steady RestYes, documented configuration

The 8-inch chuck and approximately 2.04-inch spindle through-hole provide useful capacity for general turning applications. The tailstock and steady rest are especially valuable when machining long shafts or slender workpieces.

MILLTRONICS ML-16 – 2007 – SPINDLE

SpecificationValue
Spindle TypeCNC Turning Spindle
Spindle Speed100-4,000 RPM
Spindle Drive10/12 HP
Spindle Through-Hole2.04″
Spindle NoseA2-5
Chuck8″
Bar Capacity2.04″
Spindle ApplicationTurning, Facing, Boring and Threading

The ML-16’s 100-4,000 RPM spindle range provides flexibility for both heavier turning operations and higher-speed finishing. The 10/12 HP spindle drive is appropriate for the machine’s general-purpose turning envelope.

MILLTRONICS ML-16 – 2007 – TOOL TURRET

SpecificationValue
Turret TypeAutomatic Tool Turret
Documented Capacity6 Stations
ToolingTurning Tooling
Live ToolingNo
Tool IndexingAutomatic
Tool PostConfiguration dependent
Tool PositionsVerify individual machine

A documented 2007 ML-16 is equipped with a 6-station turret, while other ML-16 machines have been configured with different tooling arrangements. Buyers should verify the turret and tool-post configuration of the specific machine being purchased.

MILLTRONICS ML-16 – 2007 – CONTROL SYSTEM

SpecificationValue
CNC ControlMilltronics Centurion 7
Control TypeCNC / Conversational
G-Code ProgrammingYes
M-Code ProgrammingYes
Conversational ProgrammingYes
Handwheel OperationAvailable
Manual OperationAvailable
Automatic OperationAvailable
SeriesB on documented 2007 machine

The Centurion 7 control is one of the defining features of the ML-16. Milltronics controls were designed to support conventional G- and M-code programming as well as conversational programming, giving shops flexibility when programming both straightforward and custom turning work.

MILLTRONICS ML-16 – 2007 – COOLANT & CHIP MANAGEMENT

SpecificationValue
Coolant SystemMachine-specific
Flood CoolantConfiguration dependent
Chip ManagementManual / Machine-specific
Chip ConveyorConfiguration dependent
Coolant PumpConfiguration dependent
Chip RemovalManual or accessory dependent
Mist CollectionConfiguration dependent

Coolant and chip-handling equipment can vary between individual used ML-16 machines. Buyers should confirm whether the machine includes a coolant system, chip conveyor, or other chip-management accessories before purchasing.

MILLTRONICS ML-16 – 2007 – POWER REQUIREMENTS

SpecificationValue
Spindle Drive10/12 HP
Electrical SupplyIndustrial 3-Phase Power
Axis DrivesServo
Main DriveAC
Coolant PowerConfiguration dependent
TransformerFacility voltage dependent
Exact VoltageVerify Machine Nameplate
Total Connected LoadVerify Individual Machine

The 10/12 HP spindle drive is the principal machining power requirement. Because used ML-16 machines can have different accessory configurations, the exact incoming voltage, amperage, transformer requirements, and connected load should be verified from the machine’s electrical documentation.

MILLTRONICS ML-16 – 2007 – DIMENSIONS

SpecificationValue
Machine WeightApprox. 6,000 lbs
Machine FootprintConfiguration dependent
InstallationIndustrial Floor
Machine TypeCNC Flat-Bed Lathe
Shipping RequirementsVerify Individual Machine
Required Floor CapacityVerify Before Installation
Height / Width / LengthVerify Individual Machine

A documented 2007 ML-16 weighs approximately 6,000 pounds. Exact overall dimensions should be confirmed for the specific machine because accessories, tooling, guarding, coolant equipment, and other options can affect the shipping and installation footprint.

MILLTRONICS ML-16 – 2007 – GENERAL INFORMATION

ItemDetails
ManufacturerMilltronics
ModelML-16
Year2007
Machine TypeCNC Flat-Bed Turning Lathe
Number of Axes2
ControlCenturion 7
SeriesB
X-Axis Travel11″
Z-Axis Travel44.5″
Maximum Center Distance48″
Swing Over Ways17″
Swing Over Cross Slide7.48″
Swing Over Gap25.9″
Gap Length12.75″
Machining LengthApprox. 40″
Spindle Speed100-4,000 RPM
Spindle Drive10/12 HP
Spindle Through-Hole2.04″
Spindle NoseA2-5
Chuck8″ 3-Jaw
TailstockYes
Tailstock Quill Travel6″
Tailstock TaperMT4
Turret6 Station on documented machine
Live CenterYes
Steady RestYes
Machine WeightApprox. 6,000 lbs

These specifications are based primarily on exact 2007 ML-16 listings. Individual machines may differ in turret, tooling, coolant, workholding, and accessory configuration.

INDUSTRIES THAT USE MILLTRONICS ML-16 – 2007

The MILLTRONICS ML-16 – 2007 can be used in a broad range of industries requiring accurate CNC turning, including:

  • General job shops
  • Automotive manufacturing
  • Industrial machinery
  • Hydraulic equipment
  • Pneumatic equipment
  • Agricultural equipment
  • Construction equipment
  • Energy equipment
  • Tool and fixture manufacturing
  • Repair and maintenance machining
  • Contract manufacturing
  • Prototype manufacturing
  • Custom machining
  • General metalworking

Its long turning capacity makes it particularly useful for shops producing shafts, rods, sleeves, spacers, tooling, and other cylindrical components.

TYPICAL PARTS MILLTRONICS ML-16 – 2007 CAN PRODUCE

The ML-16 can manufacture a wide range of turned components, including:

  • Shafts
  • Bushings
  • Pins
  • Sleeves
  • Spacers
  • Rollers
  • Couplings
  • Flanges
  • Threaded components
  • Hydraulic components
  • Pneumatic components
  • Tooling components
  • Machine components
  • Custom repair parts
  • Prototype components
  • Long cylindrical workpieces

The approximately 44.5-inch Z-axis travel and 48-inch maximum center distance make the ML-16 particularly useful when a job requires considerably more longitudinal capacity than a compact CNC lathe.

WHY CHOOSE MILLTRONICS ML-16 – 2007

The MILLTRONICS ML-16 – 2007 is a practical choice for shops looking for a relatively straightforward CNC lathe with a large work envelope and conversational programming capability.

Key advantages include:

  • 11″ X-axis travel
  • 44.5″ Z-axis travel
  • 48″ maximum center distance
  • 17″ swing over ways
  • 25.9″ swing over gap
  • 12.75″ gap length
  • 40″ approximate machining length
  • 8″ 3-jaw chuck
  • 2.04″ bar capacity
  • 10/12 HP spindle
  • 4,000 RPM maximum spindle speed
  • Centurion 7 CNC control
  • MT4 tailstock
  • 6″ tailstock quill travel
  • Steady rest
  • Live center

The combination of long travel, gap-bed capacity, tailstock support, and Centurion 7 control gives the ML-16 useful flexibility for both production and job-shop applications.

WHY BUY USED MILLTRONICS ML-16 – 2007

Buying a used MILLTRONICS ML-16 – 2007 can be an economical way to add substantial CNC turning capacity without the cost of a newer production turning center.

The exact 2007 machines currently appearing on the used market demonstrate that the model remains available for shops looking for long-bed CNC turning capability. One 2007 example is equipped with Centurion 7, an 8-inch chuck, tailstock, live center, and steady rest, while another 2007 machine is listed with a 6-station turret.

When buying a used ML-16, buyers should inspect:

  • Spindle condition
  • Spindle bearings
  • X/Z-axis backlash
  • Ball screws
  • Way surfaces
  • Turret indexing
  • Chuck condition
  • Tailstock alignment
  • Steady-rest condition
  • Centurion 7 control
  • Servo drives
  • Motors
  • Coolant system
  • Electrical cabinet
  • Emergency-stop circuit
  • Lubrication system
  • Machine geometry
  • Available manuals and service records

A machine that can be demonstrated under power with accurate axis movement, a healthy spindle, functioning control, and good mechanical condition can command a meaningful premium over an as-is machine.

HOW MUCH DOES A USED MILLTRONICS ML-16 – 2007 COST?

The price of a used MILLTRONICS ML-16 – 2007 depends on machine condition, hours, control condition, spindle health, turret configuration, tooling, chuck, tailstock, and included accessories.

Current market data provides a useful benchmark. A current listing for a 2007 Milltronics ML16 is advertised at approximately $15,995, while another 2007 machine is available on a request-for-price basis. A 2004 ML-16 is listed at $14,900, and a much newer 2015 ML16/40 with less than 1,500 hours is listed at $29,350.

Machine ConditionEstimated Used Price
As-Is / High Hours$9,000 – $12,000
Running / Average Condition$12,000 – $16,000
Good Production Condition$16,000 – $20,000
Excellent / Well Maintained$20,000 – $24,000
Exceptional / Low Hours$24,000+

Reasonable target buying range: $14,000 – $19,000

Best estimated listing value: $17,000 – $21,000

A clean 2007 MILLTRONICS ML-16 with a functioning Centurion 7 control, good spindle, accurate X/Z axes, 8-inch chuck, tailstock, steady rest, and complete tooling package can reasonably be positioned toward the upper end of this range. The current $15,995 asking price for a 2007 example provides a useful real-world market benchmark.
