The Mazak HQR-250MSY is a high-capacity, multi-tasking CNC turning center designed for heavy-duty, high-volume production. As part of Mazak’s Hyper Quadrex (HQR) series, it features a twin-spindle, twin-turret configuration that allows simultaneous machining, significantly reducing cycle times and improving productivity. The machine is equipped with full milling capability and Y-axis functionality on both turrets, enabling complex part machining in a single setup. This “DONE-IN-ONE” capability eliminates secondary operations and improves accuracy.
The HQR-250MSY is built for larger components, featuring a 10-inch chuck size, a maximum machining diameter of approximately 344 mm, and machining lengths up to 1325 mm depending on configuration. It also offers large spindle bores and high bar capacity, making it suitable for processing larger bar stock efficiently. The machine supports high-speed turning and milling with precise C-axis indexing, ensuring excellent surface finishes and tight tolerances.
Mazatrol conversational control simplifies programming while still supporting G-code, making it adaptable for various operators. With automation options such as bar feeders and robotic loaders, the HQR-250MSY is widely used in automotive, oil & gas, aerospace, and heavy engineering industries where high throughput and precision are essential.
MAZAK HQR-250MSYSPECIFICATIONS
MAZAK HQR-250MSY – AXIS
Number of Axes: 6 (X1, Z1, Y1, X2, Z2, Y2 + C-axis on both spindles)
Twin spindle, twin turret configuration
Full Y-axis capability on both turrets
Simultaneous multi-axis machining
W-axis for sub-spindle movement and part transfer
MAZAK HQR-250MSY – AXIS TRAVELS
X-Axis Travel: Approx. 207 mm
Y-Axis Travel: Approx. ±100 mm
Z-Axis Travel: Approx. 760 mm (short bed) / 1225 mm (long bed)
MAZAK HQR-250MSY – CAPACITY
Maximum Turning Diameter: Approx. 344 mm
Maximum Turning Length: Approx. 860 mm / 1325 mm
Maximum Swing: Approx. 370 mm
Bar Capacity: Approx. 80 mm
Chuck Size: 10 inch
MAZAK HQR-250MSY – SPINDLE
Number of Spindles: 2
Main Spindle Speed: Up to 4,000 RPM
Sub Spindle Speed: Up to 5,000 RPM
Spindle Motor Power: Approx. 26 kW (main), 22 kW (sub)
High-precision C-axis indexing on both spindles
MAZAK HQR-250MSY – TABLE
No traditional table (turning center design)
Twin chuck workholding system
Automatic part transfer between spindles
Compatible with bar feeders and automation systems
Rapid Traverse (Y-axis): High-performance movement
Programmable cutting feedrates
Optimized for simultaneous and balanced cutting
Reduced idle time due to dual turret operation
MAZAK HQR-250MSY – COOLANT & CHIP MANAGEMENT
Flood coolant system standard
Optional high-pressure coolant system
Integrated chip conveyor
Efficient chip evacuation system
Designed for long unattended machining cycles
MAZAK HQR-250MSY – CONTROL SYSTEM
Mazatrol SmoothG CNC Control
Conversational programming capability
EIA/ISO (G-code) compatibility
Advanced synchronization for twin turrets
Simplified programming for balanced cutting
MAZAK HQR-250MSY – POWER & AIR REQUIREMENTS
Power Requirement: Approx. 45–60 kVA
Voltage: 3-phase industrial supply
Air Requirement: Clean, dry compressed air
Air Pressure: Approx. 5–7 bar
MAZAK HQR-250MSY – DIMENSIONS
Machine Length: Approx. 3,500–4,000 mm
Machine Width: Approx. 2,500–3,000 mm
Machine Height: Approx. 2,500 mm
Machine Weight: Approx. 11,000–13,000 kg
MAZAK HQR-250MSY – GENERAL INFORMATION
Machine Type: Multi-tasking CNC turning center
Twin spindle, twin turret with full Y-axis
Designed for high-volume and large complex parts
Enables complete machining in a single setup
Supports automation and lights-out manufacturing
High productivity with simultaneous operations
INDUSTRIES THAT USE MAZAK HQR-250MSY
Automotive manufacturing
Aerospace components
Oil & gas components
Heavy equipment manufacturing
Precision engineering
TYPICAL PARTS MAZAK HQR-250MSY CAN PRODUCE
Large shafts and axles
Valve bodies and hydraulic components
Automotive drivetrain parts
Heavy-duty bushings and housings
Complex multi-operation turned and milled parts
WHY CHOOSE MAZAK HQR-250MSY
Larger capacity with 10-inch chuck for bigger parts
Twin spindle and twin turret maximize productivity
Full Y-axis enables advanced milling operations
Reduced cycle time with simultaneous machining
DONE-IN-ONE machining improves efficiency
High rigidity and power for demanding applications
WHY BUY USED MAZAK HQR-250MSY
Buying a used Mazak HQR-250MSY is a strategic investment for manufacturers seeking high-end multi-tasking capabilities at a reduced cost. One of the biggest advantages is the significant savings compared to purchasing a new machine, while still benefiting from Mazak’s proven reliability and robust construction. These machines are designed for continuous, high-volume production and can maintain strong performance over many years if properly maintained.
The HQR-250MSY’s twin-turret, twin-spindle design allows simultaneous machining, which can reduce cycle times by up to 25% through balanced cutting and synchronized operations. This directly improves productivity and return on investment. Additionally, used machines are typically available for immediate delivery, eliminating long lead times associated with new equipment purchases.
Many pre-owned units come equipped with premium features such as Y-axis, live tooling, automation interfaces, and high-capacity bar systems, which would significantly increase the cost if purchased new. Cutting time is one of the most important evaluation factors; machines with lower spindle hours often provide better long-term value regardless of age. Overall, buying used allows businesses to expand production capacity, improve efficiency, and stay competitive without large capital expenditure.
HOW MUCH DOES A USED MAZAK HQR-250MSYCOST?
The cost of a used Mazak HQR-250MSY varies depending on manufacturing year, configuration, condition, and especially cutting time. Machines built before 2000 are generally not applicable to this model, as the HQR series is a more modern platform. However, older multi-turret Mazak machines with similar capabilities may range from $50,000 to $100,000, typically with high cutting hours and outdated control systems.
Machines produced between 2000 and 2010 typically fall within the $100,000 to $200,000 range. These machines offer a solid balance between cost and performance, particularly if they have moderate cutting hours and have been well maintained. They may include earlier Mazatrol control systems but still provide strong multi-tasking capability.
More recent models from 2010 to 2025 typically range from $200,000 to $450,000 or more, depending on features such as automation integration, tooling packages, and overall condition. Machines with low cutting time command premium pricing due to longer remaining service life and higher productivity potential. Ultimately, cutting hours play a decisive role in valuation; a newer machine with heavy usage may be less desirable than an older machine with low cutting time, making usage history just as important as age when determining true market value.
