The Mazak FJV 5 Face-35/120 is a compact double-column (gantry-style) vertical machining center designed for high-precision machining of medium to large workpieces. As part of Mazak’s FJV 5 Face series, it is engineered for efficient 5-sided machining using an automatic angle head, allowing multiple surfaces of a component to be machined in a single setup, significantly reducing handling and setup time.
This model features a BT50 spindle with a standard speed of 10,000 RPM, offering a balance of high torque and cutting stability for materials such as steel, cast iron, and aluminum. The machine provides X/Y/Z travels of approximately 3,000 × 800 × 660 mm and a table size of around 3,240 × 750 mm, making it ideal for long components, plates, and structural parts.
A key advantage is its rigid double-column construction, which improves machining accuracy and minimizes deflection during heavy cutting operations. The integrated angle head enables efficient side-face machining without repositioning the workpiece. Additionally, the MAZATROL Smooth CNC control simplifies programming for multi-surface operations and enhances productivity. Overall, the FJV 5 Face-35/120 is designed to deliver consistent precision, reduced cycle times, and efficient machining for complex medium-to-large components.
MAZAK FJV 5 FACE-35/120SPECIFICATIONS
MAZAK FJV 5 FACE-35/120 – AXIS
Number of Axes: 3 + 5-face machining capability
Axis Configuration: Double Column (Gantry Type) Vertical Machining Center
Additional Capability: 5-face machining using automatic angle head
Axis Movement Type: X, Y, Z linear axes with multi-surface machining
MAZAK FJV 5 FACE-35/120 – AXIS TRAVELS
X-Axis Travel: 3,000 mm (118.11 in)
Y-Axis Travel: 800 mm (31.50 in)
Z-Axis Travel: 660 mm (25.98 in)
MAZAK FJV 5 FACE-35/120 – CAPACITY
Table Size: 3,240 mm x 750 mm
Workpiece Capability: Medium to large components
Machining Type: Full 5-face machining in a single setup
Distance Between Columns: Approx. 860 mm class
MAZAK FJV 5 FACE-35/120 – SPINDLE
Spindle Speed: Up to 10,000 RPM
Spindle Taper: BT50 / CAT 50
Spindle Type: High-rigidity built-in spindle
Spindle Capability: Designed for precision and efficient cutting
MAZAK FJV 5 FACE-35/120 – TABLE
Table Size: 3,240 mm x 750 mm
Table Type: Fixed worktable
Table Design: Long table for extended workpieces
Load Capacity: Suitable for medium to large parts
MAZAK FJV 5 FACE-35/120 – TOOL TURRET
Tool Magazine Capacity: 30–60 tools
Tool Holder Type: BT50 / CAT 50
Tool Change System: Automatic Tool Changer (ATC)
Angle Head: Automatic attachment for 5-face machining
MAZAK FJV 5 FACE-35/120 – POWER & AIR REQUIREMENTS
Power Supply: 3 Phase industrial power
Power Consumption: Suitable for mid-to-large machine operations
Air Requirement: Clean dry compressed air
Air Pressure: Standard industrial air supply
MAZAK FJV 5 FACE-35/120 – DIMENSIONS
Machine Type: Double column gantry structure
Machine Length: Approx. 9,200 mm
Machine Width: Approx. 3,250 mm
Structure: High rigidity construction
MAZAK FJV 5 FACE-35/120 – GENERAL INFORMATION
Machine Type: 5-face double column machining center
Key Feature: Machines multiple faces in one setup
Design Benefit: Reduces setup time and increases productivity
Build: High precision and rigidity for consistent machining
INDUSTRIES THAT USE MAZAK FJV 5 FACE-35/120
Aerospace
Automotive
Industrial Machinery
Tool & Die
General Engineering
TYPICAL PARTS MAZAK FJV 5 FACE-35/120 CAN PRODUCE
Medium-sized structural components
Machine housings
Automotive parts
Tooling and fixtures
Precision fabricated components
WHY CHOOSE MAZAK FJV 5 FACE-35/120
5-face machining reduces multiple setups
Compact double column design for stability
High precision over long machining cycles
Efficient for long and medium-sized parts
Advanced Mazatrol control simplifies programming
WHY BUY USED MAZAK FJV 5 FACE-35/120
Buying a used Mazak FJV 5 Face-35/120 is a practical solution for manufacturers who need 5-face machining capability without investing in a large, high-cost gantry system. Compared to bigger FJV models, the 35/120 offers a more compact footprint while still delivering strong rigidity and multi-surface machining efficiency, making it ideal for shops handling medium-sized parts.
One of the biggest benefits is process efficiency. The ability to machine multiple faces in a single setup reduces manual handling, improves dimensional accuracy, and shortens overall production time. Even older machines retain this core advantage, making them highly competitive in modern production environments.
From a cost perspective, used units can be acquired at 40–70% lower cost than new machines, while still delivering high torque cutting and reliable performance. Machines with moderate cutting hours (8,000–18,000 hours) typically provide the best balance between cost and remaining lifespan.
Cutting time is especially important for this model because it is often used for continuous production work. Machines with high hours (20,000+) may show wear in spindle bearings and guideways, particularly if used in heavy steel applications. However, a well-maintained machine with lower cutting hours can still deliver near-new performance. For shops needing efficient 5-face machining in a smaller gantry platform, a used FJV 5 Face-35/120 offers excellent value.
HOW MUCH DOES A USED MAZAK FJV 5 FACE-35/120COST?
The cost of a used Mazak FJV 5 Face-35/120 depends on factors such as age, condition, configuration, and most importantly, cutting hours. As a smaller double-column machine compared to larger FJV models, it generally falls into a more accessible price range while still offering advanced capabilities.
Machines manufactured before 2000 or early-generation equivalents typically range from $20,000 to $50,000. These machines often have high cutting hours (20,000–35,000+) and may require refurbishment, particularly in the spindle and axis components.
Models from 2000–2010 generally fall within the $50,000 to $110,000 range. This category offers the best value, especially for machines with 10,000–20,000 cutting hours and good maintenance history. Machines equipped with automatic angle heads and larger tool magazines tend to command higher prices.
Newer machines from 2010–2025 typically range from $110,000 to $250,000+, depending on condition, features, and usage. Low-hour machines (under 10,000 cutting hours), particularly those used for lighter materials like aluminum, can achieve premium pricing.
Ultimately, cutting time is more important than age. A heavily used newer machine may be less valuable than an older, well-maintained one. Buyers should prioritize spindle condition, axis accuracy, and service records to determine the true value of the machine.
