USED HURCO VMX50 – 2012

USED HURCO VMX50 – VMC (Vertical Machining Center) – WinMax Software, Chip Conveyor, Under Power

The HURCO VMX50 – 2012 is a large-capacity CNC vertical machining center designed for heavy-duty milling, drilling, tapping, boring, and precision contouring. With approximately 50″ of X-axis travel, 26″ of Y-axis travel, and 24″ of Z-axis travel, the VMX50 offers a substantial machining envelope for large plates, fixtures, housings, molds, tooling, and production components. Current VMX50 specifications confirm this basic 50″ × 26″ × 24″ travel platform, although individual 2012 machine configurations may vary.

The VMX50 is part of Hurco’s high-performance VMX machining-center series. It combines a rigid machine structure, CAT 40 spindle platform, large worktable, automatic tool changer, and Hurco conversational CNC programming. This makes it suitable for both production machining and job-shop work where setup flexibility and quick programming are important.

A typical VMX50 configuration uses a 59″ x 26″ table and can handle heavy workpieces. Spindle and tool-changer specifications can vary depending on the exact machine configuration and installed options. The individual machine should therefore be checked for its exact spindle speed, control version, tool capacity, probing, coolant, and chip-management equipment.

---

HURCO VMX50 – 2012 – AXIS

Specification	Details
HURCO VMX50 – 2012
Machine Type	CNC Vertical Machining Center
Axis Configuration	3-Axis
X-Axis Travel	50″ / 1,270 mm
Y-Axis Travel	26″ / 660 mm
Z-Axis Travel	24″ / 610 mm
X-Axis Rapid Traverse	Approx. 1,260 IPM / 32 m/min
Y-Axis Rapid Traverse	Approx. 1,260 IPM / 32 m/min
Z-Axis Rapid Traverse	Approx. 944 IPM / 24 m/min
4th Axis	Optional
5th Axis	Optional

---

HURCO VMX50 – 2012 – TABLE & WORK ENVELOPE

Specification	Details
HURCO VMX50 – 2012
Table Length	Approx. 59″ / 1,500 mm
Table Width	Approx. 26″ / 660 mm
T-Slots	6
T-Slot Width	Approx. 18 mm / 0.71″
Maximum Table Load	Up to 4,410 lbs / 2,000 kg
Spindle Nose to Table	Approx. 4″–28″
Workholding	Vise / Fixture / Rotary
4th-Axis Integration	Supported
Production Machining	Excellent
Large Part Machining	Supported

---

HURCO VMX50 – 2012 – SPINDLE

Specification	Details
HURCO VMX50 – 2012
Spindle Type	Vertical Machining Spindle
Spindle Taper	CAT 40
Maximum Spindle Speed	Configuration Dependent
Typical Spindle Speed	Up to 12,000 RPM
Spindle Motor	Approx. 24 HP
Spindle Torque	Approx. 176 ft-lbs
Spindle Cooling	Configuration Dependent
Spindle Orientation	Standard
Rigid Tapping	Supported
High-Speed Machining	Supported

The standard VMX50 platform uses a CAT 40 spindle and is specified with a 12,000 RPM maximum spindle speed on the current model. A 2012 machine may have different installed options, so the machine’s data plate or build sheet should be used to confirm the exact spindle configuration.

---

HURCO VMX50 – 2012 – TOOL CHANGER

Specification	Details
HURCO VMX50 – 2012
Tool Changer Type	Automatic
Tool Capacity	Approx. 30–40 Tools
Tool Holder	CAT 40
Tool Selection	Automatic
Maximum Tool Diameter	Approx. 3.15″ / 80 mm
Maximum Tool Length	Approx. 11.8″ / 300 mm
Maximum Tool Weight	Approx. 15.4 lbs / 7 kg
Tool-to-Tool Time	Approx. 2 Seconds
Tool-Life Management	Available
Automatic Tool Change	Standard

---

HURCO VMX50 – 2012 – CONTROL SYSTEM

Specification	Details
HURCO VMX50 – 2012
CNC Control	Hurco WinMax
Programming	Conversational / G-Code
Conversational Programming	Standard
NC Programming	Standard
Tool Offset Management	Standard
Work Offset Management	Standard
Graphics & Simulation	Standard
Rigid Tapping	Supported
Diagnostics	Standard
USB / Data Transfer	Configuration Dependent

One of the primary advantages of the VMX50 is the Hurco conversational control, which allows operators to create machining programs directly at the machine in addition to conventional NC programming.

---

HURCO VMX50 – 2012 – FEEDRATES

Specification	Details
HURCO VMX50 – 2012
X-Axis Rapid Traverse	Approx. 1,260 IPM / 32 m/min
Y-Axis Rapid Traverse	Approx. 1,260 IPM / 32 m/min
Z-Axis Rapid Traverse	Approx. 944 IPM / 24 m/min
Maximum Programmable Feedrate	Approx. 944 IPM / 24 m/min
Feedrate Override	Standard
Linear Interpolation	Yes
Circular Interpolation	Yes
Helical Interpolation	Supported
Rigid Tapping	Supported
High-Speed Contouring	Supported

---

HURCO VMX50 – 2012 – COOLANT & CHIP MANAGEMENT

Specification	Details
HURCO VMX50 – 2012
Flood Coolant	Standard
Coolant Tank	Standard
Coolant Pump	Standard
Through-Spindle Coolant	Optional / Configuration Dependent
High-Pressure Coolant	Optional
Chip Conveyor	Configuration Dependent
Chip Auger	Available
Coolant Filtration	Standard
Mist Collector	Optional
Automatic Lubrication	Standard

---

HURCO VMX50 – 2012 – PROBING & AUTOMATION

Specification	Details
HURCO VMX50 – 2012
Workpiece Probe	Optional
Tool Setting Probe	Optional
Automatic Tool Measurement	Available
4th Axis	Optional
5th Axis	Optional
Rotary Table Integration	Supported
Chip Conveyor	Configuration Dependent
Automated Production	Supported
Lights-Out Production	Configuration Dependent
Data Networking	Configuration Dependent

---

HURCO VMX50 – 2012 – POWER REQUIREMENTS

Specification	Details
HURCO VMX50 – 2012
Spindle Motor	Approx. 24 HP
Electrical Service	Three-Phase
Input Voltage	Configuration Dependent
Frequency	50 / 60 Hz
Shop Air	Required
Pneumatic System	Standard
Automatic Lubrication	Standard
Electrical Cabinet	Hurco
Installation	Industrial

---

HURCO VMX50 – 2012 – DIMENSIONS

Specification	Details
HURCO VMX50 – 2012
Operating Floor Space	Approx. 199″ x 153″
Machine Height	Approx. 127.5″
Machine Weight	Approx. 19,000–20,000 lbs
Rigging	Required
Installation	Industrial
Enclosure	Full Enclosure
Chip Conveyor	Adds Floor Space
Control Cabinet	Integrated

Dimensions and weight can vary between VMX50 generations and installed options. Current VMX50 specifications list machine weights in the approximate 19,000-lb range.

---

HURCO VMX50 – 2012 – GENERAL INFORMATION

Specification	Details
HURCO VMX50 – 2012
Manufacturer	Hurco
Model	VMX50
Year	2012
Machine Category	CNC Vertical Machining Center
Axis Configuration	3-Axis
X-Axis Travel	50″ / 1,270 mm
Y-Axis Travel	26″ / 660 mm
Z-Axis Travel	24″ / 610 mm
Table Size	Approx. 59″ x 26″
Maximum Table Load	Up to 4,410 lbs
Spindle Taper	CAT 40
Maximum Spindle Speed	Up to 12,000 RPM
Spindle Power	Approx. 24 HP
Tool Capacity	Approx. 30–40
CNC Control	Hurco WinMax

---

INDUSTRIES THAT USE HURCO VMX50

The HURCO VMX50 is well suited for:

• General Manufacturing
• Aerospace
• Automotive
• Mold & Die
• Tool & Die
• Defense
• Energy
• Industrial Equipment
• Heavy Machinery
• Job Shops
• Contract Machining
• Prototype Manufacturing

---

TYPICAL PARTS HURCO VMX50 CAN PRODUCE

Typical components include:

• Large machine plates
• Housings
• Fixtures
• Tooling plates
• Mold components
• Die components
• Aerospace structures
• Automotive components
• Industrial brackets
• Machine components
• Production fixtures
• Prototype parts

Typical operations include face milling, end milling, drilling, tapping, boring, pocketing, slotting, contouring, chamfering, engraving, and 3D profiling.

---

WHY CHOOSE HURCO VMX50

The major advantage of the HURCO VMX50 is its combination of a large machining envelope and user-friendly programming capability. With 50″ of X-axis travel and a 59″ x 26″ table, the machine can accommodate significantly larger parts and fixtures than smaller vertical machining centers.

The Hurco conversational control is particularly useful for job shops and manufacturers that frequently change setups or produce short runs. Operators can create programs directly at the control while still retaining conventional G-code capability.

The CAT 40 spindle platform, automatic tool changer, and high rapid traverse rates make the VMX50 suitable for both general production machining and more demanding tooling or mold applications.

---

WHY BUY USED HURCO VMX50 – 2012

A used 2012 HURCO VMX50 can provide substantial machining capacity at a significantly lower investment than a newer large-frame CNC machining center.

When evaluating a used machine, inspect the spindle, spindle bearings, ballscrews, linear guideways, tool changer, servo motors, CNC control, coolant system, lubrication system, and overall machine geometry.

Buyers should verify spindle hours, spindle runout, axis backlash, positioning accuracy, tool-change operation, table condition, coolant performance, and maintenance history.

Machines equipped with a 4th axis, probing, through-spindle coolant, chip conveyor, high-speed spindle, complete CAT 40 tooling, and documented maintenance records can command additional value.

---

HOW MUCH DOES A USED HURCO VMX50 – 2012 COST?

The market value of a used HURCO VMX50 – 2012 depends heavily on machine condition, spindle hours, control condition, installed options, tooling, probing, fourth-axis equipment, and maintenance history.

USED HURCO VMX50 – 2012 PRICE RANGE	ESTIMATED COST
High Hours / Basic Configuration	$25,000 – $35,000
Functional Production Machine	$35,000 – $45,000
Good Condition / Production Ready	$45,000 – $60,000
Excellent / Well Equipped	$60,000 – $75,000
Low Hours / Fully Equipped	$75,000 – $90,000+

For a 2012 HURCO VMX50 in good working condition, a reasonable estimated market range is approximately $40,000–$60,000 USD.

For an inventory listing, I would recommend an asking-price range of $50,000–$70,000 USD for a clean, production-ready machine with a 12,000 RPM CAT 40 spindle, 30–40 tool changer, Hurco WinMax control, chip management equipment, probing, and tooling.

Best estimated listing value: $50,000–$70,000 USD.
