USED HAAS VF-5SS – 2018

The HAAS VF-5SS is a high-performance Super-Speed vertical machining center designed for manufacturers requiring fast spindle speeds, rapid axis movement, quick tool changes, and a large machining envelope. The 2018 HAAS VF-5SS combines a 12,000 RPM inline direct-drive spindle, 30 HP spindle motor, 50″ x 26″ x 25″ axis travels, and high-speed production features to support demanding machining applications.

The machine is designed for high-volume production and reduced cycle times. Its Super-Speed configuration includes a high-speed side-mount tool changer, rapid traverse rates of up to 1,200 IPM, and fast tool-to-tool and chip-to-chip changes. These features make the VF-5SS particularly effective for manufacturers producing repeated components where cycle time and spindle utilization are important.

With 50 inches of X-axis travel, 26 inches of Y-axis travel, and 25 inches of Z-axis travel, the VF-5SS provides a substantial work envelope for aerospace components, automotive parts, molds, dies, fixtures, and general industrial components. The 40-taper, 12,000 RPM spindle offers a strong balance of cutting power and high-speed machining capability.

A used 2018 HAAS VF-5SS may be equipped with valuable options including through-spindle coolant, probing, programmable coolant, expanded tool capacity, high-speed machining, and chip conveyor systems. One 2018 machine currently listed on the used market includes through-spindle coolant, probes, programmable coolant, a 40-tool magazine, and a multi-auger chip conveyor.

---

HAAS VF-5SS – AXIS

Specification	Details
Machine Type	Super-Speed Vertical Machining Center
Axis Configuration	3-Axis
X-Axis Travel	50″
Y-Axis Travel	26″
Z-Axis Travel	25″
4th-Axis Capability	Available
5th-Axis Capability	Available with Optional Rotary Equipment
CNC Interpolation	3-Axis Standard

---

HAAS VF-5SS – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
X-Axis Travel	50″
Y-Axis Travel	26″
Z-Axis Travel	25″
Spindle Nose to Table	Approx. 4.2″ to 29.2″
Maximum Workpiece Size	Configuration Dependent
Maximum Table Load	1,750 lbs Evenly Distributed
Large-Part Machining Capability	Excellent

---

HAAS VF-5SS – CAPACITY / TABLE

Specification	Details
Table Type	Fixed T-Slot Table
Table Length	54″
Table Width	24″
Number of Standard T-Slots	7
T-Slot Center Distance	3.15″
Maximum Table Load	1,750 lbs
Workholding	Fixtures, Vises, and Custom Tooling

---

HAAS VF-5SS – SPINDLE

Specification	Details
Spindle Speed	12,000 RPM
Spindle Motor Power	30 HP
Maximum Torque	90 ft-lb at 2,000 RPM
Spindle Taper	CT40 / BT40 / HSK-A63 Configuration Dependent
Drive System	Inline Direct-Drive
Spindle Cooling	Liquid Cooled
Rigid Tapping	Standard
Through-Spindle Coolant	Available

---

HAAS VF-5SS – TOOL CHANGER

Specification	Details
Tool Changer Type	High-Speed Side-Mount Tool Changer
Standard Tool Capacity	30+1 Tools
Optional Tool Capacity	40 Tools and Other Configurations Available
Tool Selection	Random Access
Maximum Tool Diameter	2.5″ Full
Large Tool Diameter	5″ with Adjacent Pocket Empty
Maximum Tool Length	16″
Maximum Tool Weight	12 lbs
Tool-to-Tool Change Time	Approx. 1.8 Seconds
Chip-to-Chip Time	Approx. 2.4 Seconds

---

HAAS VF-5SS – CONTROL SYSTEM

Specification	Details
CNC Control	Haas CNC Control
Programming Format	G-Code and Conversational Programming
Standard Program Memory	1 GB
Rigid Tapping	Standard
Advanced Tool Management	Standard
Ethernet Interface	Standard
Wi-Fi Connectivity	Available
Remote Monitoring	HaasConnect Capability
High-Speed Machining	Available

---

HAAS VF-5SS – FEEDRATES

Specification	Details
Maximum Cutting Feedrate	833 IPM
X-Axis Rapid Traverse	1,200 IPM
Y-Axis Rapid Traverse	1,200 IPM
Z-Axis Rapid Traverse	1,200 IPM
Maximum X-Axis Thrust	3,350 lbf
Maximum Y-Axis Thrust	3,350 lbf
Maximum Z-Axis Thrust	3,350 lbf

---

HAAS VF-5SS – COOLANT / CHIP MANAGEMENT

Specification	Details
Flood Coolant System	Standard
Coolant Capacity	95 Gallons
Chip Washdown Feature	Standard
Multi-Stage Coolant Pump	Standard
Chip Auger	Available
Chip Conveyor	Optional
Through-Spindle Coolant	Available
High-Pressure Coolant	Optional
Through-Tool Air Blast	Available

---

HAAS VF-5SS – PROBING & AUTOMATION OPTIONS

Specification	Details
Work Probe	Available
Tool Measurement System	Available
Renishaw Probing	Configuration Dependent
4th-Axis Integration	Available
Rotary Table Integration	Available
Robotic Integration	Available
Automated Production Capability	Configuration Dependent
Lights-Out Manufacturing	Available with Proper Configuration

---

HAAS VF-5SS – POWER REQUIREMENTS

Specification	Details
Standard Input Voltage	220 VAC
High-Voltage Option	440 VAC
Electrical Requirement	3 Phase
Full-Load Current at 220V	Approx. 70 A
Full-Load Current at 440V	Approx. 35 A
Air Requirement	4 SCFM at 100 PSI
Minimum Air Pressure	80 PSI

---

HAAS VF-5SS – DIMENSIONS

Specification	Details
Machine Construction	Heavy-Duty Vertical Machining Center
Shipping Weight	Approx. 12,700 lbs
Shipping Footprint	Approx. 168″ x 101.5″ x 109″
Installation Type	Industrial Foundation Recommended
Production Class	High-Speed Production VMC

---

HAAS VF-5SS – GENERAL INFORMATION

Specification	Details
Manufacturer	Haas Automation
Model	VF-5SS
Year	2018
Machine Category	Super-Speed Vertical Machining Center
Spindle Taper	40-Taper
Country of Origin	United States
Primary Application	High-Speed Precision Production
Production Environment	Job Shop to High-Volume Manufacturing

---

INDUSTRIES THAT USE HAAS VF-5SS

The HAAS VF-5SS is widely used in aerospace, automotive, medical, defense, mold and die, electronics, robotics, and general contract manufacturing. Aerospace manufacturers use the machine for brackets, housings, structural components, fixtures, and other precision parts requiring high accuracy and efficient material removal.

Automotive and motorsport manufacturers benefit from the machine’s high spindle speed and rapid tool changes when producing repeated components, prototypes, engine components, brackets, and specialized production parts.

The mold and die industry uses the VF-5SS for cavities, cores, electrodes, tooling, and complex contoured components. Medical manufacturers can use the machine for surgical instruments, orthopedic components, and precision medical equipment parts.

The machine is also well suited for general job shops because its large work envelope and high-speed capabilities allow it to handle a broad range of production work.

---

TYPICAL PARTS HAAS VF-5SS CAN PRODUCE

The HAAS VF-5SS can produce a wide variety of precision-machined components, including aerospace brackets, automotive components, mold and die components, fixtures, housings, medical parts, tooling, and industrial components.

Its 50-inch X-axis travel provides substantial capacity for larger workpieces, while the 12,000 RPM spindle supports efficient machining of aluminum and other materials requiring higher cutting speeds. The machine can also perform aggressive cutting operations when equipped with appropriate tooling and cutting parameters.

Typical applications include prototype components, production parts, complex aluminum components, steel fixtures, industrial housings, automation components, and custom-engineered parts.

---

WHY CHOOSE HAAS VF-5SS

The main advantage of the HAAS VF-5SS is its combination of a large machining envelope and high-speed production performance. The 12,000 RPM inline direct-drive spindle, rapid 1,200 IPM axis movements, and fast tool-changing system are designed to reduce cycle times and increase machine productivity.

The 30 HP spindle provides sufficient power for a broad range of machining applications, while the 40-taper configuration provides the rigidity required for general production machining. The machine’s 50″ x 26″ x 25″ travels allow manufacturers to handle larger workpieces than many standard-size vertical machining centers.

The VF-5SS is also highly configurable. Options such as probing, through-spindle coolant, programmable coolant, chip conveyors, expanded tool magazines, and fourth-axis equipment can significantly increase production efficiency.

For manufacturers seeking high-speed machining capability with a large work envelope, the VF-5SS remains a strong and versatile CNC platform.

---

WHY BUY USED HAAS VF-5SS

Purchasing a used 2018 HAAS VF-5SS allows manufacturers to acquire a relatively modern Super-Speed vertical machining center at a lower cost than purchasing new equipment with comparable capabilities.

A used 2018 machine may already include valuable options such as through-spindle coolant, probing systems, programmable coolant, expanded tool capacity, high-speed machining software, and chip conveyor systems. One current 2018 listing includes a 40-tool magazine, through-spindle coolant, probes, through-tool air blast, high-speed machining, programmable coolant, and a multi-auger chip conveyor.

The VF-5SS is also attractive because of its combination of speed and capacity. Manufacturers can use one machine for both high-volume production and larger individual components.

A properly maintained 2018 model can provide years of productive service while avoiding the significantly higher capital cost of a new high-speed vertical machining center.

---

HOW MUCH DOES A USED HAAS VF-5SS COST?

A used 2018 HAAS VF-5SS typically sells for approximately $65,000 to $90,000, depending on the machine’s condition, spindle hours, installed options, maintenance history, tooling package, and seller location. A current 2018 HAAS VF-5SS listing is priced at $79,750, providing a useful market reference for a well-equipped example.

A well-maintained machine equipped with a 12,000 RPM, 30 HP inline direct-drive spindle, 30+1 or expanded tool capacity, through-spindle coolant, probing, programmable coolant, high-speed machining, and chip conveyor will generally command a higher price. Machines with low spindle hours, documented maintenance, and a clean production history may approach or exceed the upper end of the typical range.

Machines with heavy use, high spindle hours, damaged way covers, worn ballscrews, spindle problems, or outdated control components may sell for less. Buyers should carefully inspect the spindle, axis geometry, linear guides, ballscrews, tool changer, control electronics, and coolant system before purchase.

In addition to the purchase price, buyers should budget for transportation, rigging, installation, electrical connection, tooling, inspection, and possible preventive maintenance. For manufacturers seeking a fast, modern, and versatile vertical machining center, a used 2018 HAAS VF-5SS can provide excellent value compared with purchasing a new high-speed production VMC.
