Used HAAS VF4SS 2016 - CNC Machine For Sale - Michigan - USA
HAAS VF4SS 2016

HAAS VF4SS 2016

MAKE: HAAS
MODEL: VF4SS
TYPE: Vertical Machine
YEAR: 2016
SKU: 111525
DEALER: Toolquip, Inc
COUNTRY: USA
STATE: Michigan

USED HAAS VF4SS 2016

The 2016 Haas VF4SS is a high-speed Super Speed CNC Vertical Machining Center designed for manufacturers requiring fast cycle times, high productivity, and precision machining capability. Built with a rigid cast-iron structure, 40-taper inline direct-drive spindle, and high-speed axis movements, the VF4SS is ideal for aerospace components, automotive parts, mold making, medical components, fixtures, and production machining applications.

The machine features 50 in (1,270 mm) of X-axis travel, 20 in (508 mm) of Y-axis travel, and 25 in (635 mm) of Z-axis travel. Equipped with a 12,000 RPM spindle, 30 HP motor, and 30+1 high-speed side-mount tool changer, the VF4SS 2016 provides excellent performance for shops requiring rapid tool changes, fast rapids, and efficient machining operations.

HAAS VF4SS 2016 – AXIS

SpecificationDetails
X-Axis Travel50 in (1,270 mm)
Y-Axis Travel20 in (508 mm)
Z-Axis Travel25 in (635 mm)
Axis Configuration3-Axis Vertical Machining Center
Rapid Traverse (X/Y/Z)1,400 IPM (35.6 m/min)
Maximum Cutting Feed833 IPM (21.2 m/min)
Guideway TypeLinear Guideways

HAAS VF4SS 2016 – TABLE

SpecificationDetails
Table Size52 × 19.5 in (1,321 × 495 mm)
Maximum Table Load1,750 lbs (794 kg)
T-Slots5
T-Slot Width0.626 in (15.9 mm)

HAAS VF4SS 2016 – SPINDLE

SpecificationDetails
Maximum Spindle Speed12,000 RPM
Spindle Power30 HP (22.4 kW)
Maximum Torque90 ft-lb @ 2,000 RPM
Spindle TaperCT40 / BT40
Drive TypeInline Direct Drive
Cooling SystemLiquid Cooled
Bearing LubricationAir/Oil Injection

HAAS VF4SS 2016 – TOOL CHANGER

SpecificationDetails
Tool Capacity30 + 1 Tools
Tool Changer TypeHigh-Speed Side-Mount Tool Changer
Tool-to-Tool Time1.8 sec
Chip-to-Chip Time2.4 sec
Maximum Tool Weight12 lbs (5.4 kg)
Maximum Tool Diameter2.5 in (64 mm)
Maximum Tool Diameter (Adjacent Empty)5 in (127 mm)

HAAS VF4SS 2016 – CONTROL SYSTEM

SpecificationDetails
CNC ControlHaas CNC Control
ProgrammingISO G-Code
EthernetStandard
USB PortStandard
Rigid TappingStandard
High-Speed MachiningOptional
Program MemoryConfiguration Dependent

HAAS VF4SS 2016 – COOLANT SYSTEM

SpecificationDetails
Flood CoolantStandard
Coolant Tank Capacity55 gal (208 L)
Multi-Stage Coolant PumpStandard
Chip WashdownStandard
Window Air BlastStandard
Through-Spindle CoolantOptional
Chip ConveyorOptional

HAAS VF4SS 2016 – POWER REQUIREMENTS

SpecificationDetails
Electrical Supply220V / 440V, 3-Phase
Full Load Current70A @ 220V
High Voltage Current35A @ 440V
Air Requirement4 SCFM @ 100 PSI

HAAS VF4SS 2016 – DIMENSIONS

SpecificationDetails
Machine LengthApprox. 152 in
Machine WidthApprox. 99 in
Machine HeightApprox. 106 in
Machine WeightApprox. 11,720 lbs

HAAS VF4SS 2016 – GENERAL INFORMATION

SpecificationDetails
ManufacturerHaas Automation
ModelVF4SS
Year2016
Machine TypeSuper Speed CNC Vertical Machining Center
ConditionUsed
Country of OriginUSA

WHY BUY USED HAAS VF4SS 2016

Purchasing a used Haas VF4SS 2016 provides manufacturers with a high-speed machining solution at a lower investment compared to purchasing new. Its 12,000 RPM spindle, fast rapids, and high-speed tool changer make it an excellent choice for production environments where reducing cycle times and improving efficiency are important.

The VF4SS 2016 is especially suitable for shops machining aluminum, steel, plastics, and composite materials. Options such as probing systems, through-spindle coolant, chip conveyors, and rotary axis capability can further expand its machining flexibility.

HOW MUCH DOES A USED HAAS VF4SS 2016 COST?

The price of a used Haas VF4SS 2016 depends on spindle hours, machine condition, installed options, tooling package, and maintenance history.

Most used Haas VF4SS 2016 machines typically sell between:

$75,000 – $130,000

Machines equipped with:

  • Renishaw probing
  • Through-spindle coolant
  • Chip conveyor
  • 4th-axis rotary preparation
  • High-speed machining options
  • Low spindle hours

generally command higher resale values.

Before purchasing, buyers should inspect:

  • Spindle condition and runout
  • Ballscrews and guideways
  • Tool changer operation
  • Coolant system
  • Machine geometry
  • CNC control performance

INDUSTRIES THAT USE HAAS VF4SS 2016

  • Aerospace Manufacturing
  • Automotive Manufacturing
  • Medical Device Manufacturing
  • Mold & Die Manufacturing
  • Defense Manufacturing
  • Precision Engineering
  • Prototype Manufacturing
  • Electronics Manufacturing
  • General CNC Machine Shops
  • Production Manufacturing

TYPICAL PARTS HAAS VF4SS 2016 CAN PRODUCE

  • Aerospace Components
  • Automotive Parts
  • Medical Components
  • Mold Inserts
  • Precision Fixtures
  • Aluminum Components
  • Tooling Plates
  • Prototype Parts
  • Production Components
  • Complex Machined Parts

WHY CHOOSE HAAS VF4SS 2016

The Haas VF4SS 2016 combines high-speed machining capability, reliable Haas engineering, and a large work envelope into a versatile production CNC platform. Its 50-inch X-axis travel, 12,000 RPM spindle, and 30+1 tool capacity make it an excellent choice for manufacturers needing speed, accuracy, and flexibility.

For companies looking for a dependable used Super Speed vertical machining center, the Haas VF4SS 2016 delivers excellent productivity, precision, and long-term value.
