USED HAAS VF-4 – 2024

The HAAS VF-4 is a large-capacity 40-taper vertical machining center designed for manufacturers requiring a substantial work envelope, high spindle power, and flexible production capability. The 2024 HAAS VF-4 provides approximately 50″ x 20″ x 25″ of X, Y, and Z-axis travel, making it suitable for machining large components, fixtures, aerospace parts, automotive components, industrial equipment, molds, dies, and general precision-machined parts.

The 2024 VF-4 is equipped with an 8,100 RPM, 30 HP inline direct-drive spindle and a standard 20-pocket carousel tool changer. Its 40-taper spindle provides a good balance between cutting power, rigidity, and versatility for a wide range of materials and machining applications. The machine also offers a maximum table load of approximately 3,500 pounds, giving it strong capacity for large workpieces and heavy fixtures.

The machine features modern Haas control technology, including a widescreen monitor, Ethernet interface, Wi-Fi connectivity, 1 GB standard program memory, rigid tapping, advanced tool management, HaasDrop, and remote monitoring capability through HaasConnect. Depending on the individual machine configuration, options may include larger tool magazines, through-spindle coolant, probing, chip conveyors, programmable coolant, and automation equipment.

The 2024 HAAS VF-4 is well suited for job shops, aerospace suppliers, automotive manufacturers, industrial equipment manufacturers, mold and die companies, and production machining facilities requiring a large and versatile vertical machining center.

---

HAAS VF-4 – AXIS

Specification	Details
Machine Type	40-Taper Vertical Machining Center
Axis Configuration	3-Axis
X-Axis Travel	50″
Y-Axis Travel	20″
Z-Axis Travel	25″
4th-Axis Capability	Available
5th-Axis Capability	Available with Optional Rotary Equipment
CNC Interpolation	3-Axis Standard

---

HAAS VF-4 – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
X-Axis Travel	50″
Y-Axis Travel	20″
Z-Axis Travel	25″
Spindle Nose to Table	Approx. 4.2″ to 29.2″
Maximum Workpiece Size	Configuration Dependent
Maximum Table Load	3,500 lbs Evenly Distributed
Large-Part Machining Capability	Excellent

The 50″ x 20″ x 25″ travel envelope provides substantial capacity for large components while maintaining the flexibility of a standard vertical machining center.

---

HAAS VF-4 – CAPACITY / TABLE

Specification	Details
Table Type	Fixed T-Slot Table
Table Length	52″
Table Width	19.5″
Number of Standard T-Slots	5
T-Slot Center Distance	3.15″
Maximum Table Load	3,500 lbs
Workholding	Fixtures, Vises, and Custom Tooling

---

HAAS VF-4 – SPINDLE

Specification	Details
Spindle Speed	8,100 RPM
Spindle Motor Power	30 HP
Maximum Torque	90 ft-lb at 2,000 RPM
Spindle Taper	CT40 / BT40 / HSK-A63 Configuration Dependent
Drive System	Inline Direct-Drive
Spindle Cooling	Liquid Cooled
Bearing Lubrication	Air / Oil Injection
Rigid Tapping	Standard
Through-Spindle Coolant	Available as an Option

The standard 2024 VF-4 spindle is a 30 HP, 8,100 RPM inline direct-drive unit with approximately 90 ft-lb of maximum torque at 2,000 RPM.

---

HAAS VF-4 – TOOL CHANGER

Specification	Details
Tool Changer Type	Carousel Tool Changer
Standard Tool Capacity	20 Tools
Optional Tool Capacity	50+1 or 70+1 Configuration Available
Tool Selection	Random Access
Maximum Tool Diameter	Approx. 3.5″ Full
Maximum Tool Weight	12 lbs
Tool-to-Tool Change Time	Approx. 4.2 Seconds
Chip-to-Chip Time	Approx. 4.5 Seconds

The standard 2024 VF-4 is equipped with a 20-pocket carousel tool changer, while larger side-mount tool changer configurations are available as options.

---

HAAS VF-4 – CONTROL SYSTEM

Specification	Details
CNC Control	Haas CNC Control
Monitor	Widescreen Control Monitor
Program Memory	1 GB Standard
Programming Format	G-Code and Conversational Programming
Rigid Tapping	Standard
Advanced Tool Management	Standard
Ethernet Interface	Standard
Wi-Fi Connectivity	Standard
HaasDrop	Standard
HaasConnect	Remote Monitoring Capability
Safe Run	Standard

---

HAAS VF-4 – FEEDRATES

Specification	Details
Maximum Cutting Feedrate	650 IPM
X-Axis Rapid Traverse	1,000 IPM
Y-Axis Rapid Traverse	1,000 IPM
Z-Axis Rapid Traverse	1,000 IPM
Maximum X-Axis Thrust	2,550 lbf
Maximum Y-Axis Thrust	2,550 lbf
Maximum Z-Axis Thrust	4,200 lbf
Servo Drive System	Standard

The VF-4 provides rapid traverses of approximately 1,000 IPM on all three axes and a maximum cutting feedrate of approximately 650 IPM.

---

HAAS VF-4 – COOLANT / CHIP MANAGEMENT

Specification	Details
Flood Coolant System	Standard
Coolant Capacity	55 Gallons
Multi-Stage Coolant Pump	Standard
Window Air Blast	Standard
Chip Washdown Feature	Standard
Chip Auger	Available
Chip Conveyor	Optional
Through-Spindle Coolant	Available
High-Pressure Coolant	Optional

---

HAAS VF-4 – PROBING & AUTOMATION OPTIONS

Specification	Details
Work Probe	Available
Tool Setter	Available
Renishaw Probing	Configuration Dependent
4th-Axis Integration	Available
Rotary Table Integration	Available
Robotic Integration	Available
Pallet Pool Compatibility	Available with Appropriate Configuration
Lights-Out Manufacturing	Configuration Dependent

---

HAAS VF-4 – POWER REQUIREMENTS

Specification	Details
Standard Input Voltage	220 VAC
High-Voltage Option	440 VAC
Electrical Requirement	3 Phase
Full-Load Current at 220V	70 A
Full-Load Current at 440V	35 A
Air Requirement	4 SCFM at 100 PSI
Minimum Air Pressure	80 PSI

---

HAAS VF-4 – DIMENSIONS

Specification	Details
Machine Construction	Large-Capacity Vertical Machining Center
Standard Shipping Dimensions	Approx. 152″ x 99″ x 106″
Standard Shipping Weight	Approx. 11,720 lbs
Shipping Weight with Conveyor	Approx. 13,800 lbs
Installation Type	Industrial Installation Recommended
Machine Footprint	Large-Format Medium VMC

Actual dimensions and weight can vary depending on the selected tool changer, chip conveyor, and other options.

---

HAAS VF-4 – GENERAL INFORMATION

Specification	Details
Manufacturer	Haas Automation
Model	VF-4
Year	2024
Machine Category	Large-Capacity Vertical Machining Center
Spindle Taper	40-Taper
Country of Origin	United States
Primary Application	Large-Part Precision Machining
Production Environment	Job Shop to Production Manufacturing

---

INDUSTRIES THAT USE HAAS VF-4

The HAAS VF-4 is widely used in aerospace, automotive, defense, medical, industrial equipment, energy, mold and die, and general manufacturing. Aerospace manufacturers use the machine for structural components, brackets, housings, fixtures, and other large precision parts.

Automotive and transportation manufacturers use the VF-4 for production components, prototypes, tooling, fixtures, and specialized parts. Industrial equipment manufacturers benefit from the machine’s large work envelope and 3,500-pound table capacity when producing large housings, machine components, bases, and structural parts.

Mold and die manufacturers can use the VF-4 for large molds, dies, tooling plates, cores, and cavities. General job shops also benefit from the machine’s versatility because it can handle both one-off custom components and repeat production work.

---

TYPICAL PARTS HAAS VF-4 CAN PRODUCE

The HAAS VF-4 can produce aerospace brackets, industrial housings, automotive components, large fixtures, tooling plates, mold components, machine bases, hydraulic components, automation parts, and custom-engineered industrial products.

Its 50-inch X-axis travel is particularly useful for long components and large fixtures that may exceed the capacity of smaller vertical machining centers. The 30 HP spindle provides sufficient power for machining aluminum, steel, stainless steel, and other common engineering materials.

Typical applications include large aluminum components, steel fixtures, machine components, production brackets, industrial housings, prototype parts, mold inserts, and custom precision-machined components.

---

WHY CHOOSE HAAS VF-4

The primary advantage of the HAAS VF-4 is its combination of large work envelope, 30 HP spindle power, high table capacity, and modern CNC control technology. The 50″ x 20″ x 25″ travels allow manufacturers to handle large components while maintaining the flexibility of a conventional vertical machining center.

The 8,100 RPM inline direct-drive spindle provides a good balance between cutting performance and versatility. The 3,500-pound table capacity also allows manufacturers to use substantial fixtures and heavier workpieces.

The modern Haas control includes features such as Wi-Fi connectivity, Ethernet, 1 GB program memory, advanced tool management, HaasDrop, Safe Run, and HaasConnect remote monitoring. These features can help simplify programming, production monitoring, and shop-floor connectivity.

For manufacturers requiring a large and flexible vertical machining center, the VF-4 provides a strong combination of capacity, productivity, and modern machine-control technology.

---

WHY BUY USED HAAS VF-4

Purchasing a used 2024 HAAS VF-4 can provide manufacturers with an almost-new large-capacity vertical machining center while potentially reducing the capital investment compared with purchasing a brand-new machine.

Because a 2024 machine is relatively new, a used example may offer the benefits of modern Haas control technology, low accumulated operating hours, current-generation electronics, and reduced mechanical wear compared with older VF-4 models.

The machine’s 50″ x 20″ x 25″ travel envelope and 3,500-pound table capacity allow manufacturers to accept larger machining projects without moving directly to a significantly larger and more expensive machining center. Options such as probing, through-spindle coolant, chip conveyors, larger tool magazines, and fourth-axis equipment can further increase production capability.

Buyers should still verify spindle hours, maintenance records, machine condition, installed options, warranty status, and the reason for resale. A 2024 machine with low hours and documented maintenance can be especially attractive to manufacturers seeking modern capacity without the full cost of new equipment.

---

HOW MUCH DOES A USED HAAS VF-4 COST?

A used 2024 HAAS VF-4 typically sells for approximately $85,000 to $120,000, depending on the machine’s actual operating hours, installed options, condition, warranty status, tooling package, and seller location. A nearly new machine with very low spindle hours and valuable options may command a price close to new-equipment pricing.

The base machine includes a 30 HP, 8,100 RPM inline direct-drive spindle, 20-pocket carousel tool changer, 50″ x 20″ x 25″ travels, 3,500-pound table capacity, and modern Haas control features. Options such as a 50+1 or 70+1 tool changer, through-spindle coolant, probing, chip conveyor, high-pressure coolant, and fourth-axis equipment can significantly increase the value of a used example.

A machine with low operating hours, clean machine geometry, documented maintenance, and remaining factory warranty coverage may sell toward the upper end of the range. A machine with higher hours or missing production options may be priced lower.

For a 2024 model, buyers should pay particular attention to the difference between the used machine’s price and the cost of a comparable new machine configured with the same options. In many cases, the greatest value comes from acquiring a lightly used machine with expensive factory options already installed.

In addition to the purchase price, buyers should budget for transportation, rigging, installation, electrical connection, tooling, inspection, and any required accessories. For manufacturers seeking modern large-format machining capacity, a used 2024 HAAS VF-4 can offer an attractive alternative to purchasing a fully equipped new VMC.
