USED HAAS VF-5/50XT – 2019

The HAAS VF-5/50XT is a high-performance CNC vertical machining center designed for heavy-duty cutting, large-part machining, and extended-axis applications. Manufactured by Haas Automation, the VF-5/50XT combines the large work envelope of the VF-5 platform with a CAT 50 spindle and extra-long X-axis travel. This configuration is ideal for machining oversized components that require aggressive material removal and superior rigidity.

The HAAS VF-5/50XT typically features X-axis travel of approximately 120 inches, Y-axis travel of 26 inches, and Z-axis travel of 25 inches. The machine is equipped with a 30 to 50 hp CAT 50 spindle, depending on configuration, with spindle speeds commonly ranging from 7,500 to 10,000 RPM. A 30+1 side-mount tool changer provides fast tool changes and supports complex multi-operation machining. The rigid cast-iron construction and powerful spindle make the machine well suited for machining steel, stainless steel, cast iron, aluminum, and high-temperature alloys.

The VF-5/50XT is widely used in aerospace, oil and gas, mold manufacturing, defense, and general fabrication. It is commonly used to machine structural components, large plates, tooling fixtures, molds, and precision machined weldments.

The HAAS VF-5/50XT remains highly desirable in the used CNC market because it offers massive travel, CAT 50 spindle performance, and the reliability and support associated with Haas Automation.

HAAS VF-5/50XT SPECIFICATIONS

WHY BUY USED HAAS VF-5/50XT

Purchasing a used HAAS VF-5/50XT is an excellent way to obtain a large-format machining center with CAT 50 spindle performance at a fraction of the cost of a new machine. The extended X-axis travel allows shops to machine long structural parts, large tooling plates, and heavy weldments in a single setup.

Many used machines include valuable options such as through-spindle coolant, chip conveyors, rotary tables, probing systems, and high-capacity tool changers. These accessories can significantly improve productivity and reduce setup times.

Because Haas machines are widely supported, replacement parts, technical service, and operator familiarity are readily available. Buyers should inspect spindle condition, axis backlash, tool changer function, and control operation before purchase.

For manufacturers needing large-part machining capability and aggressive metal removal performance, the HAAS VF-5/50XT offers exceptional versatility and long-term value.

HOW MUCH DOES A USED HAAS VF-5/50XT COST?

The cost of a used HAAS VF-5/50XT depends on spindle configuration, machine age, hours, maintenance records, and installed options. Most machines sell between $60,000 and $200,000, with newer low-hour machines equipped with CAT 50 gearboxes, probing, and through-spindle coolant commanding the highest prices.

For shops that need a large-capacity vertical machining center capable of heavy cutting and long-part machining, the HAAS VF-5/50XT delivers outstanding performance and excellent return on investment.
