The Haas UMC-750 is a compact and highly capable 5-axis universal machining center designed for complex multi-axis machining in a single setup. Engineered for precision and flexibility, this machine is ideal for aerospace components, medical parts, automotive prototypes, and high-value production parts that require tight tolerances and complex geometries.
With full 5-axis simultaneous machining capability, the UMC-750 helps reduce multiple setups, improve part accuracy, and increase overall shop efficiency. The intuitive Haas control system makes advanced multi-axis machining accessible to a wide range of operators, from experienced 5-axis users to shops upgrading from 3-axis platforms.
This machine is located in California, offering buyers on the West Coast and across North America a convenient opportunity for faster inspection, quicker delivery, and lower logistics costs. Haas machines are widely supported in the U.S., with strong service networks and readily available parts, making the UMC-750 a dependable choice for long-term production use.
HAAS UMC750SPECIFICATIONS
TRAVEL & CAPACITY
X-Axis: 762 mm (30 in)
Y-Axis: 508 mm (20 in)
Z-Axis: 508 mm (20 in)
B-Axis (Tilt): +120° to -35°
C-Axis (Rotation): 360° continuous
SPINDLE
Taper: 40-taper (CAT or BT)
Max Speed: 8,100 rpm (standard); 10,000 rpm optional
Power: 22.4 kW (30 hp) vector drive
Max Torque: ~122 Nm
Cooling: Liquid-cooled inline motor
TRUNNION TABLE
Type: 30+1 side-mount tool changer (SMTC)
Max Tool Diameter: 76 mm (adjacent), 127 mm (non-adjacent)
Max Tool Length: 330 mm
Max Tool Weight: 5.4 kg
Tool Change Time: ~2.8 sec chip-to-chip
FEEDRATES
Rapid Traverse (X/Y/Z): 25.4 m/min (1,000 ipm)
Cutting Feedrate: Up to 12.7 m/min (500 ipm)
COOLANT & CHIP MANAGEMENT
Flood Coolant: Standard
Through-Spindle Coolant (TSC): Optional (300 psi)
Programmable Coolant Nozzle: Optional
Chip Auger or Conveyor: Optional
CONTROL SYSTEM
CNC: Haas Next-Gen Control
Display: 15” LCD Touchscreen
USB, Ethernet, and Wi-Fi connectivity
DWO/TCPC (Dynamic Work Offsets / Tool Center Point Control)
Probing and macros support (optional)
POWER & AIR REQUIREMENTS
Electrical Power: ~30 – 35 kVA
Air Pressure: ~0.55 MPa (80 psi)
HAAS UMC750 – GENERAL INFORMATION
Model: Haas UMC‑750
Machine Type: 5-Axis Vertical Machining Center
Spindle Taper: 40-taper (CAT 40 or BT 40)
Table Style: Dual-axis trunnion (B and C axes)
Control: Haas Next-Gen Control (NGC)
Drive System: Inline direct-drive spindle
HAAS UMC750 – KEY CAPABILITIES
Simultaneous 5-axis contouring and full 3+2 positioning
Tilting trunnion table for complex angle and undercut features
Large work envelope in a compact footprint
Reduced setups and high part accuracy
Ideal for complex geometries and tight tolerances
Built-in support for rotary file formats and probing
Medical (implants, surgical guides, prosthetic tooling)
Automotive (gear housings, steering components)
Energy (turbine blades, oilfield components)
Mold & Die (cores, cavities, high-precision inserts)
High-precision and multi-surface job shops
TYPICAL PARTS HAAS UMC750 CAN PRODUCE
Orthopedic implants (hip, knee, spine)
Aerospace brackets and frames
Impellers and blisks
Engine components with angled features
Mold cores and 3D cavity inserts
WHY CHOOSE THE HAAS UMC750
Affordable entry into full 5-axis CNC machining
Compact footprint with large travel capacity
Robust construction and proven spindle performance
Intuitive 5-axis control interface with built-in post-processors
Broad support for automation and probing systems
Trusted Haas reliability and U.S.-based service network
Summary Table
Parameter
Value
Travels (X/Y/Z)
762 / 508 / 508 mm
B-Axis Tilt
+120° to -35°
C-Axis Rotation
360° continuous
Spindle Type
40-taper, inline direct-drive
Max Spindle Speed
8,100 – 10,000 rpm
Tool Changer
30+1 side-mount (SMTC)
Table Size
Ø 630 mm
Max Table Load
300 kg (660 lbs)
Control System
Haas Next-Gen Control
Rotary Axis Resolution
0.001° B & C
How much does used HAAS UMC750 cost? Used Machine Price Range (Approximate)
Configuration
Estimated Price (USD)
Standard (8,100 rpm, 30+1 tools)
$80,000 – $100,000
Mid-Spec (10k spindle, probing, TSC)
$100,000 – $120,000
High-End (rotary upgrades, automation ready)
$130,000 – $150,000+
Prices vary depending on build year, spindle hours, tool count, and installed options.
WHY BUY USED HAAS UMC-750
Purchasing a used Haas UMC-750 in California allows manufacturers to add 5-axis machining capability at a significantly lower cost than buying new. Local availability simplifies inspection and installation while accelerating time-to-production. A pre-owned UMC-750 delivers proven performance, strong resale value, and immediate productivity gains, making it an excellent investment for shops expanding into advanced multi-axis machining or increasing complex part production capacity.
