USED HAAS UMC 500 – 2022

The HAAS UMC 500 – 2022 is a modern 5-axis CNC universal machining center designed for complex multi-sided machining, simultaneous 5-axis contouring, and high-accuracy production. The UMC 500 is one of Haas’ more compact universal machining centers, providing a useful combination of 5-axis capability, relatively small footprint, and a 24 x 16 x 16-inch machining envelope.

The UMC 500 provides 24 inches of X-axis travel, 16 inches of Y-axis travel, and 16 inches of Z-axis travel. Its integrated trunnion table provides 120° to -35° B-axis tilt and 360° C-axis rotation, allowing manufacturers to machine multiple surfaces and complex geometries without repeatedly repositioning the workpiece. The standard machine is equipped with a 40-taper, 8,100 RPM inline direct-drive spindle rated at 30 HP, while individual 2022 machines may have been ordered with higher-speed spindle options.

A 2022 used example has been documented with a 10,000 RPM spindle, CAT 40 taper, 30-tool automatic tool changer, Haas CNC control, chip conveyor, 5-axis trunnion table, probes, and high-speed machining. Another 2022 example includes through-spindle coolant, programmable coolant nozzles, auxiliary coolant filtration, tool and part probes, WiFi camera, rigid tapping, and high-speed machining.

---

HAAS UMC 500 – 2022 – AXIS

Specification	Details
Machine Type	5-Axis Universal Machining Center
Axis Configuration	X, Y, Z, B & C
X-Axis Travel	24″ / 610 mm
Y-Axis Travel	16″ / 406 mm
Z-Axis Travel	16″ / 406 mm
B-Axis	+120° to -35°
C-Axis	360°
Simultaneous 5-Axis	Yes
3+2 Machining	Yes
Rotary Table	Integrated Trunnion

The UMC 500 is designed for both 3+2 positioning and simultaneous 5-axis machining, making it suitable for complex components that require access to multiple surfaces.

---

HAAS UMC 500 – 2022 – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
X-Axis Travel	24″ / 610 mm
Y-Axis Travel	16″ / 406 mm
Z-Axis Travel	16″ / 406 mm
Spindle Nose to Platter Maximum	Approx. 20″ / 508 mm
Spindle Nose to Platter Minimum	Approx. 4″ / 102 mm
Maximum Part Swing	Approx. 18″ / 457 mm
Platter Diameter	15.7″ / 400 mm
Maximum Part Capacity	Configuration Dependent
5-Axis Work Envelope	Compact / Medium

The 24 x 16 x 16-inch travel envelope is particularly appropriate for smaller complex components and production parts requiring multiple machining orientations.

---

HAAS UMC 500 – 2022 – TABLE / CAPACITY

Specification	Details
Table Type	Integrated Trunnion Rotary Table
Platter Diameter	15.7″ / 400 mm
Maximum Platter Load	500 lbs / 226.8 kg
T-Slots	5
T-Slot Width	Approx. 0.626–0.630″
T-Slot Center Distance	2.48″ / 63 mm
B-Axis Tilt	+120° to -35°
C-Axis Rotation	360°
Maximum Part Swing	18″ / 457 mm
Workholding	Fixture / Vise / Chuck

Haas specifies a 15.7-inch platter and 500-pound maximum platter load for the UMC 500.

---

HAAS UMC 500 – 2022 – SPINDLE

Specification	Details
Spindle Type	Inline Direct Drive
Spindle Taper	CT40 / BT40 / HSK-A63 Options
Standard Maximum Speed	8,100 RPM
Documented 2022 Configuration	Up to 10,000 RPM
Spindle Power	30 HP / 22.4 kW
Maximum Torque	Approx. 90 ft-lb @ 2,000 RPM
Spindle Cooling	Liquid Cooled
Bearing Lubrication	Air / Oil Injection
Spindle Orientation	Yes
Through-Spindle Coolant	Optional / Configuration Dependent

Haas lists the standard UMC 500 spindle at 8,100 RPM and 30 HP, while documented 2022 used machines show 10,000 RPM configurations. This means the actual spindle specification should be verified for the individual 2022 machine.

---

HAAS UMC 500 – 2022 – TOOL CHANGER

Specification	Details
Tool Changer Type	Side-Mount Automatic Tool Changer
Standard Capacity	30+1 Tools
Documented Used Configuration	30 Tools
Optional Capacity	70+1 / 120+1
Tool Taper	CT40 / BT40
Tool Management	CNC Controlled
Tool Change	Automatic
Tool Presetter	Optional
Tool Life Management	Yes
High-Capacity ATC	Available

The current UMC 500 uses a 30+1 side-mount tool changer, with larger 70+1 and 120+1 configurations available. A documented 2022 machine has a 30-tool magazine.

---

HAAS UMC 500 – 2022 – CONTROL SYSTEM

Specification	Details
CNC Control	Haas Next Generation Control
Control Type	Haas NGC
5-Axis Control	Yes
Simultaneous 5-Axis	Yes
Dynamic Work Offsets	Yes
Tool Center Point Control	Yes
Rigid Tapping	Yes
Program Memory	1 GB Standard
Ethernet	Yes
WiFi	Yes
USB	Yes
Remote Jog Handle	Touchscreen Display
HaasConnect	Yes
Safe Run	Yes

The UMC 500 uses Haas’ Next Generation Control, with features including Dynamic Work Offsets, Tool Center Point Control, rigid tapping, Ethernet, WiFi, HaasConnect, and 1 GB standard program memory.

---

HAAS UMC 500 – 2022 – FEEDRATES

Specification	Details
X-Axis Rapid Traverse	Approx. 900 IPM / 22.9 m/min
Y-Axis Rapid Traverse	Configuration Dependent
Z-Axis Rapid Traverse	Configuration Dependent
Maximum Cutting Feedrate	650 IPM / 16.5 m/min
B-Axis Maximum Speed	50°/sec
C-Axis Maximum Speed	50°/sec
Feedrate Override	Standard
Linear Interpolation	Yes
Circular Interpolation	Yes
5-Axis Interpolation	Yes

Haas specifies 650 IPM maximum cutting feedrate, with X-axis rapid traverse of approximately 900 IPM and B/C-axis maximum speeds of 50° per second.

---

HAAS UMC 500 – 2022 – COOLANT & CHIP MANAGEMENT

Specification	Details
Flood Coolant	Standard
Standard Coolant Tank	55 Gallons
Multi-Stage Coolant Pump	Yes
Through-Spindle Coolant	Optional
Chip Auger	Available
Chip Conveyor	Available
Programmable Coolant Nozzles	Available
Auxiliary Coolant Filter	Available
Mist Collector	Optional
Coolant Filtration	Configuration Dependent

The standard UMC 500 includes a 55-gallon coolant tank and multi-stage coolant pump. Documented 2022 machines are available with chip conveyors, through-spindle coolant, programmable coolant nozzles, and auxiliary coolant filtration.

---

HAAS UMC 500 – 2022 – 5-AXIS ROTARY SYSTEM

Specification	Details
B-Axis	+120° to -35°
C-Axis	360°
B-Axis Maximum Speed	50°/sec
C-Axis Maximum Speed	50°/sec
Continuous C-Axis	Yes
B-Axis Continuous Torque	Approx. 1,854 ft-lb
C-Axis Continuous Torque	Approx. 1,854 ft-lb
B-Axis Brake Torque	Approx. 900 ft-lb
C-Axis Brake Torque	Approx. 900 ft-lb
5-Axis Machining	Yes

The trunnion system is a major feature of the UMC 500, providing substantial angular positioning capability for complex components.

---

HAAS UMC 500 – 2022 – AUTOMATION / PROBING

Specification	Details
Wireless Intuitive Probing System	Standard
Work Probe	Yes
Tool Probe	Yes
WiFi Camera	Available
High-Speed Machining	Available
Hydraulic Vise Ready	Available
Automatic Part Loading	Configuration Dependent
Robot Integration	Available
Pallet Pool	Available
Rotary Scales	Optional

The UMC 500 is designed for automation and process monitoring, with Wireless Intuitive Probing System included as a standard feature on the current specification and various probing, camera, hydraulic workholding, and automation options available.

---

HAAS UMC 500 – 2022 – POWER REQUIREMENTS

Specification	Details
Spindle Power	30 HP / 22.4 kW
Low Voltage Input	220 VAC
Low Voltage Full Load	Approx. 70 A
High Voltage Input	440 VAC
High Voltage Full Load	Approx. 35 A
Electrical Service	3-Phase
Shop Air	Required
Electrical Cabinet	Integrated
Transformer	Configuration Dependent
Total Connected Load	Configuration Dependent

Haas specifies 220 VAC or 440 VAC 3-phase input, with approximately 70 A full-load current at 220 V or 35 A at 440 V for the standard configuration.

---

HAAS UMC 500 – 2022 – DIMENSIONS

Specification	Details
Approximate Shipping Width	128″
Approximate Shipping Depth	98″
Approximate Shipping Height	110″
Approximate Shipping Weight	11,900 lbs
Metric Weight	Approx. 5,400 kg
Weight with Conveyor / 70+1 SMTC	Approx. 13,320 lbs
Weight with Conveyor / 120+1 SMTC	Approx. 13,960 lbs
Installation	Industrial
Rigging	Required

Haas lists a standard shipping weight of approximately 11,900 pounds, with heavier configurations exceeding 13,000 pounds.

---

HAAS UMC 500 – 2022 – GENERAL INFORMATION

Specification	Details
Manufacturer	Haas
Model	UMC 500
Year	2022
Machine Category	Universal Machining Center
Machine Type	5-Axis CNC Vertical Machining Center
Axis Configuration	5-Axis
X-Axis Travel	24″
Y-Axis Travel	16″
Z-Axis Travel	16″
B-Axis	+120° to -35°
C-Axis	360°
Platter Diameter	15.7″
Maximum Platter Load	500 lbs
Spindle Speed	8,100 RPM Standard / 10,000 RPM Documented
Spindle Power	30 HP
Spindle Taper	CAT 40
Tool Capacity	30+1 Standard
CNC Control	Haas NGC
Maximum Cutting Feedrate	650 IPM
Coolant Capacity	55 Gallons Standard
Machine Weight	Approx. 11,900 lbs

---

INDUSTRIES THAT USE HAAS UMC 500

The HAAS UMC 500 is particularly well suited to industries where components have multiple machined surfaces or complex 3D geometry.

Typical industries include:

• Aerospace
• Automotive
• Defense
• Medical equipment
• Energy
• Robotics
• Industrial machinery
• Mold and die
• Precision engineering
• Contract manufacturing
• Oil and gas
• General job shops

Its 5-axis configuration is particularly valuable for manufacturers that want to reduce the number of setups required to produce complex parts.

---

TYPICAL PARTS HAAS UMC 500 CAN PRODUCE

The UMC 500 can produce:

• Aerospace components
• Impellers
• Turbine components
• Valve bodies
• Pump housings
• Automotive components
• Medical components
• Complex brackets
• Fixtures
• Housings
• Mold components
• Die components
• Hydraulic components
• Precision multi-sided parts

Typical operations include 5-axis contouring, face milling, pocketing, drilling, boring, tapping, reaming, angled-hole machining, profiling, and simultaneous multi-axis machining.

---

WHY CHOOSE HAAS UMC 500

The biggest advantage of the HAAS UMC 500 is its ability to combine a compact footprint with full 5-axis machining. Haas specifically positions the UMC 500 for 3+2 and simultaneous 5-axis machining of smaller parts, helping reduce setups and improve machining accuracy.

Its 24 x 16 x 16-inch travels, 15.7-inch trunnion platter, 500-pound table capacity, 30 HP spindle, and 40-taper tooling provide a strong combination for general production work.

The machine is also attractive for manufacturers transitioning from 3-axis machining into 5-axis production. Dynamic Work Offsets and Tool Center Point Control simplify programming and allow the machine to maintain tool-center positioning during complex rotary-axis movements.

For job shops, the UMC 500 can potentially replace several setups with one machine, reducing fixture changes, operator handling, and the opportunity for cumulative setup errors.

---

WHY BUY USED HAAS UMC 500 – 2022

A used 2022 HAAS UMC 500 can be particularly attractive because the machine is relatively recent while offering capabilities that would otherwise require a substantial investment in a new 5-axis machining center.

The used market already has documented 2022 examples equipped with 5-axis trunnion tables, CAT 40 spindles, 30-tool ATCs, chip conveyors, probes, high-speed machining, and through-spindle coolant.

The machine can be an excellent fit for manufacturers that need to machine multiple surfaces without removing the component from the fixture. This can improve repeatability while reducing setup and handling time.

Before purchasing a used 2022 UMC 500, buyers should inspect the spindle, B/C rotary axes, rotary scales, trunnion bearings, ballscrews, linear guides, tool changer, drawbar, probing system, coolant system, chip conveyor, and CNC control.

For a machine of this age, buyers should also request power-on hours, cutting hours, spindle hours, maintenance records, alarm history, crash history, and a test-cut demonstration.

---

HOW MUCH DOES A USED HAAS UMC 500 – 2022 COST?

The HAAS UMC 500 – 2022 is a relatively high-value used 5-axis machining center because it is still a modern machine and provides full 5-axis functionality.

There is useful historical pricing evidence from Haas itself. An August 2022 Haas factory quote for a UMC 500 showed a $133,895 base machine price and a $273,199 total quoted price after options, including control options, spindle options, tool changer options, through-spindle coolant, and other equipment. This demonstrates how substantially configuration can affect the value of a UMC 500.

Current used listings confirm that 2022 UMC 500 machines are actively traded, although dealers often use “Activate Pricing” rather than publicly displaying their selling price.

For inventory valuation, I would use the following practical estimates:

USED HAAS UMC 500 – 2022 PRICE RANGE	ESTIMATED COST
High Hours / Basic Configuration	$75,000 – $90,000
Functional Used Machine	$90,000 – $105,000
Good Condition / Production Ready	$105,000 – $120,000
Excellent / Well Equipped	$120,000 – $140,000
Low Hours / Premium Configuration	$140,000+

For a 2022 HAAS UMC 500 in good working condition, I would estimate approximately $95,000–$125,000 USD.

For your inventory listing, I would recommend using $105,000–$125,000 USD as a practical estimated used-market range for a clean, operational 2022 machine.

A machine with low spindle hours, 10,000 RPM or higher spindle, through-spindle coolant, chip conveyor, probing, high-speed machining, programmable coolant, additional tooling, and excellent B/C-axis accuracy could reasonably be valued toward $125,000–$140,000+.

A basic or high-hour machine without through-spindle coolant or with significant wear could fall toward $75,000–$95,000.

Best estimated listing value: $105,000–$125,000 USD.

The actual selling price should ultimately be based on spindle hours, power-on hours, machine condition, spindle specification, B/C-axis accuracy, installed options, tooling, and whether the machine is being sold with automation or a pallet system. The exact 2022 configuration should also be verified because documented machines vary between 8,100 RPM and 10,000 RPM spindles and different coolant/tooling packages.
