USED DOOSAN PUMA 800LM – 2015

The DOOSAN PUMA 800LM – 2015 is a heavy-duty CNC turn-mill center engineered for manufacturers that require exceptional machining capacity, high torque performance, and advanced multitasking capabilities for large and complex workpieces. As one of the largest and most capable machines in the Doosan Puma series, the 800LM is designed to handle demanding machining applications in industries such as oil and gas, power generation, mining, aerospace, shipbuilding, heavy equipment manufacturing, and industrial machinery production.

Built around a massive cast iron machine structure, the Puma 800LM delivers outstanding rigidity and vibration dampening during aggressive cutting operations. The machine is specifically designed for machining large-diameter and long-length components while maintaining excellent dimensional accuracy and surface finish quality. Its heavy-duty construction allows manufacturers to perform high-volume material removal operations while preserving precision throughout extended production runs.

One of the most significant advantages of the Puma 800LM is its integrated milling capability. Equipped with Y-axis functionality, C-axis spindle positioning, and live tooling, the machine can perform turning, drilling, milling, tapping, boring, and contouring operations in a single setup. This multitasking capability helps manufacturers reduce cycle times, eliminate secondary operations, and improve overall production efficiency.

The machine is commonly equipped with a high-torque geared spindle, programmable hydraulic tailstock, heavy-duty turret, and advanced FANUC CNC controls. These features allow the Puma 800LM to machine a wide range of materials including carbon steel, alloy steel, stainless steel, cast iron, titanium, Inconel, nickel alloys, and other difficult-to-machine materials frequently used in heavy industrial applications.

Industries utilizing the Puma 800LM include energy production, offshore equipment manufacturing, mining equipment production, marine engineering, aerospace component manufacturing, heavy machinery production, steel processing equipment manufacturing, and industrial contract machining. Typical applications include turbine shafts, hydraulic cylinders, marine propulsion shafts, compressor rotors, pump components, industrial rollers, large couplings, and heavy equipment components.

The 2015 DOOSAN PUMA 800LM remains highly desirable in the used CNC machinery market because it combines large-part machining capability, advanced turn-mill functionality, proven reliability, and excellent long-term value.

---

DOOSAN PUMA 800LM – AXIS

Specification	Value
Number of Axes	4 Axis
Axis Configuration	X, Y, Z, C
Machine Type	CNC Turn-Mill Center
Y-Axis Capability	Standard
C-Axis Capability	Standard
Live Tooling Capability	Standard

---

DOOSAN PUMA 800LM – AXIS TRAVELS / WORK ENVELOPE

Specification	Value
X-Axis Travel	22 in
Y-Axis Travel	±5 in
Z-Axis Travel	126 in
Maximum Turning Diameter	41 in
Maximum Turning Length	120 in
Swing Over Bed	47 in

---

DOOSAN PUMA 800LM – CAPACITY / TABLE

Specification	Value
Chuck Size	24 in
Maximum Workpiece Diameter	41 in
Maximum Workpiece Length	120 in
Maximum Workpiece Weight	8,800 lbs
Tailstock Type	Programmable Hydraulic
Workholding	Hydraulic Chuck

---

DOOSAN PUMA 800LM – SPINDLE

Specification	Value
Maximum Spindle Speed	1,200 RPM
Main Spindle Power	75 HP
Maximum Torque	3,200 ft-lb
Spindle Bore	8 in
Spindle Nose	A2-15
Spindle Type	Heavy-Duty Geared Spindle

---

DOOSAN PUMA 800LM – TOOL CHANGER

Specification	Value
Turret Stations	12
Live Tool Positions	12
Live Tool Speed	4,000 RPM
Tool Selection	Automatic
Tooling Style	BMT Heavy-Duty Tooling

---

DOOSAN PUMA 800LM – CONTROL SYSTEM

Specification	Value
CNC Control	FANUC 31i
Conversational Programming	Available
Network Connectivity	Standard
USB Data Transfer	Supported
Production Monitoring	Available

---

DOOSAN PUMA 800LM – COOLANT / DUST / WATER MANAGEMENT

Specification	Value
Flood Coolant System	Standard
High Pressure Coolant	Optional
Coolant Filtration	Integrated
Chip Conveyor	Standard
Coolant Tank Capacity	Large Capacity
Automatic Chip Removal	Standard

---

DOOSAN PUMA 800LM – POWER REQUIREMENTS

Specification	Value
Electrical Supply	400V – 480V
Phase	3 Phase
Frequency	50/60 Hz
Connected Load	Approx. 90 kVA

---

DOOSAN PUMA 800LM – DIMENSIONS

Specification	Value
Machine Length	Approx. 340 in
Machine Width	Approx. 120 in
Machine Height	Approx. 115 in
Machine Weight	Approx. 52,000 lbs

---

DOOSAN PUMA 800LM – GENERAL INFORMATION

Specification	Value
Manufacturer	Doosan Machine Tools
Model	Puma 800LM
Year	2015
Machine Category	CNC Turn-Mill Center
Control System	FANUC
Construction	Heavy-Duty Cast Iron Structure
Typical Materials	Steel, Stainless Steel, Titanium, Inconel
Production Type	Large-Part Precision Machining

---

INDUSTRIES THAT USE DOOSAN PUMA 800LM

• Oil & Gas Equipment Manufacturing
• Power Generation
• Mining Equipment Manufacturing
• Marine Engineering
• Aerospace Manufacturing
• Heavy Equipment Production
• Industrial Machinery Manufacturing
• Defense Manufacturing
• Steel Processing Equipment Manufacturing
• Contract Machining

---

TYPICAL PARTS DOOSAN PUMA 800LM CAN PRODUCE

• Turbine Shafts
• Compressor Rotors
• Hydraulic Cylinders
• Pump Housings
• Marine Propulsion Shafts
• Industrial Rollers
• Couplings
• Valve Bodies
• Energy Industry Components
• Mining Equipment Parts
• Heavy Machine Components
• Large Precision Shafts

---

WHY CHOOSE DOOSAN PUMA 800LM

The DOOSAN PUMA 800LM is designed for manufacturers that require maximum machining capacity combined with advanced multitasking functionality. Its ability to perform both turning and milling operations on large workpieces makes it an extremely productive solution for heavy industrial manufacturing environments.

One of the machine’s greatest strengths is its massive structural rigidity. The heavily reinforced cast iron construction absorbs vibration and provides outstanding stability during demanding cutting operations. This allows manufacturers to perform aggressive roughing operations while maintaining high levels of accuracy and surface finish quality.

The integrated Y-axis and live tooling system significantly increase production flexibility. Complex parts requiring drilling, milling, tapping, and contouring operations can be completed in a single setup, reducing handling time and improving overall machining efficiency. This capability is particularly valuable when working with large components that are difficult to move between machines.

The machine’s high-torque geared spindle delivers the power needed for heavy-duty machining applications. Whether processing large steel forgings, castings, or difficult alloys, the Puma 800LM provides the cutting performance required to maintain productivity.

The FANUC control system contributes to reliability and ease of operation. Operators benefit from a familiar programming environment, advanced diagnostics, and excellent support availability throughout the industry.

For manufacturers involved in large-part production, the Puma 800LM offers an outstanding combination of power, versatility, durability, and productivity. Its ability to handle oversized workpieces while performing multiple machining operations makes it a valuable asset for demanding manufacturing environments.

---

WHY BUY USED DOOSAN PUMA 800LM

Purchasing a used DOOSAN PUMA 800LM allows manufacturers to acquire a large-capacity turn-mill machine at a substantially lower cost than purchasing a new machine. Because heavy-duty multitasking machines require significant capital investment when purchased new, the used machinery market provides an attractive alternative for many companies.

One of the primary advantages of buying used is cost efficiency. A properly maintained Puma 800LM can provide years of productive service while costing significantly less than a comparable new machine. These savings allow manufacturers to invest in tooling, automation, facility upgrades, or additional production equipment.

The machine’s robust construction further enhances its value. Doosan heavy-duty machines are engineered for long service life and are capable of operating in demanding production environments for many years. This durability makes used machines particularly attractive for manufacturers seeking dependable long-term performance.

Availability is another important advantage. New large-capacity turn-mill machines often involve lengthy lead times due to production schedules and machine customization requirements. Used machines are frequently available for immediate purchase and installation, allowing companies to expand capacity quickly.

Many used Puma 800LM machines include valuable options such as high-pressure coolant systems, advanced tooling packages, steady rests, chip management systems, probing equipment, and additional software capabilities. These features can significantly improve productivity while reducing future capital expenditures.

The machine’s ability to perform multiple machining operations in a single setup further contributes to its value. Reduced setup time, improved throughput, and increased machining flexibility often result in substantial productivity gains.

For manufacturers producing large industrial components, a used Puma 800LM represents an excellent investment that combines capability, reliability, and long-term value.

---

HOW MUCH DOES A USED DOOSAN PUMA 800LM COST?

The value of a used DOOSAN PUMA 800LM depends on factors such as machine condition, spindle hours, maintenance history, installed options, tooling packages, and current market demand. Because these machines are designed for specialized large-part machining applications, pricing can vary significantly depending on configuration and overall condition.

Machine condition is typically the most important factor affecting resale value. Machines with documented maintenance histories, lower operating hours, and excellent mechanical condition generally command premium pricing. Buyers often seek machines that have been properly maintained because they reduce the risk of downtime and unexpected repair expenses.

Installed options can substantially influence value. Features such as Y-axis capability, live tooling, high-pressure coolant systems, steady rests, probing systems, upgraded software, automation interfaces, and tooling packages often increase market prices because they improve machine versatility and productivity.

Market demand also plays a major role. Industries such as oil and gas, mining, power generation, marine engineering, and heavy equipment manufacturing continue to require large-capacity machining equipment capable of handling oversized components. This demand helps support strong resale values for machines like the Puma 800LM.

Additional ownership expenses should also be considered. Transportation, rigging, installation, foundation preparation, tooling, and operator training can represent significant investments depending on machine location and facility requirements.

In today’s used CNC machinery market, a 2015 DOOSAN PUMA 800LM typically sells within a range of approximately $140,000 to $350,000, depending on machine condition, spindle hours, tooling packages, installed options, and overall configuration. Machines equipped with Y-axis functionality, live tooling, high-pressure coolant systems, advanced workholding solutions, and documented maintenance histories generally command values toward the upper end of the range.

When evaluating value, manufacturers should consider the machine’s ability to increase production capacity, reduce setup requirements, improve machining flexibility, and support demanding large-part manufacturing applications. These benefits continue to make the DOOSAN PUMA 800LM one of the most desirable heavy-duty turn-mill machines available in the used CNC marketplace.
