USED DOOSAN MYNX 6500/50II – 2022

The DOOSAN MYNX 6500/50II – 2022 is a heavy-duty CNC vertical machining center designed for demanding milling, drilling, boring, and tapping applications. The MYNX series is built around a rigid machine structure, large worktable, and powerful 50-taper spindle, making it suitable for machining larger and heavier components than many standard 40-taper vertical machining centers.

The MYNX 6500/50II provides 50″ of X-axis travel, 26.4″ of Y-axis travel, and 24.6″ of Z-axis travel, giving it a substantial machining envelope for large fixtures, castings, housings, plates, and production components. The machine features a 1,400 x 670 mm table with a maximum table load of approximately 1,300 kg / 2,866 lbs.

Its ISO 50 spindle configuration is designed for heavy-duty cutting, with a standard spindle speed of 6,000 RPM. Depending on the machine’s original configuration, spindle motor power and torque can vary. The MYNX 6500/50II platform was offered with multiple spindle configurations, so the exact equipment on an individual 2022 machine should always be verified.

The DOOSAN MYNX 6500/50II – 2022 is well suited for manufacturers in aerospace, automotive, energy, oil and gas, heavy equipment, mold and die, industrial machinery, and general contract machining.

---

DOOSAN MYNX 6500/50II – 2022 – AXIS TRAVELS

Specification	Details
DOOSAN MYNX 6500/50II – 2022
Machine Type	CNC Vertical Machining Center
Axis Configuration	3-Axis
X-Axis Travel	50″ / 1,270 mm
Y-Axis Travel	26.4″ / 670 mm
Z-Axis Travel	24.6″ / 625 mm
Spindle Nose to Table	7.9″–32.5″ / 200–825 mm
Guideway Type	Heavy-Duty Linear Guide System
4th-Axis Capability	Optional
5th-Axis Capability	Optional Rotary Configuration

The MYNX 6500/50II offers a large machining envelope while maintaining a relatively compact footprint for its class.

---

DOOSAN MYNX 6500/50II – 2022 – TABLE

Specification	Details
DOOSAN MYNX 6500/50II – 2022
Table Length	55.1″ / 1,400 mm
Table Width	26.4″ / 670 mm
Maximum Table Load	2,866 lbs / 1,300 kg
Table Type	Fixed T-Slot Table
Workholding	Vises / Fixtures / Rotary Tables
Large Part Machining	Supported
Heavy Component Capacity	High
4th-Axis Installation	Optional
Multi-Part Fixturing	Supported

---

DOOSAN MYNX 6500/50II – 2022 – SPINDLE

Specification	Details
DOOSAN MYNX 6500/50II – 2022
Spindle Taper	ISO 50 / CAT50 Configuration
Maximum Spindle Speed	6,000 RPM Standard
Spindle Type	Heavy-Duty Configuration
Standard Spindle Power	Approx. 20 HP / 15 kW
Optional Spindle Power	Up to Approx. 40 HP / 30 kW
Standard Maximum Torque	Approx. 211 ft-lb / 286.5 Nm
Optional High-Torque Configuration	Up to Approx. 455 ft-lb / 617.4 Nm
Spindle Orientation	CNC Controlled
Rigid Tapping	Supported
Heavy-Duty Milling	Supported

Spindle power and torque vary according to the spindle option installed on the individual machine.

---

DOOSAN MYNX 6500/50II – 2022 – TOOL CHANGER

Specification	Details
DOOSAN MYNX 6500/50II – 2022
Tool Changer Type	Automatic Tool Changer
Standard Tool Capacity	24 Tools
Optional Tool Capacity	30 / Higher Configuration Dependent
Tool Shank	CAT50 / ISO50
Tool Selection	Automatic
Tool Management	CNC Controlled
Heavy Tooling	Supported
Large Milling Tools	Supported
Tool Offset Management	Standard
Automatic Tool Change	Standard

The tool magazine capacity can vary based on the original machine configuration.

---

DOOSAN MYNX 6500/50II – 2022 – FEEDRATES

Specification	Details
DOOSAN MYNX 6500/50II – 2022
X-Axis Rapid Traverse	1,181 IPM / 30 m/min
Y-Axis Rapid Traverse	1,181 IPM / 30 m/min
Z-Axis Rapid Traverse	945 IPM / 24 m/min
Cutting Feedrate	CNC Programmable
Feedrate Override	Standard
Linear Interpolation	Supported
Circular Interpolation	Supported
Helical Interpolation	Supported
High-Speed Positioning	Supported

---

DOOSAN MYNX 6500/50II – 2022 – COOLANT & CHIP MANAGEMENT

Specification	Details
DOOSAN MYNX 6500/50II – 2022
Flood Coolant	Standard
Through-Spindle Coolant	Optional / Configuration Dependent
High-Pressure Coolant	Configuration Dependent
Chip Auger	Optional
Chip Conveyor	Optional / Configuration Dependent
Coolant Filtration	Configuration Dependent
Automatic Lubrication	Standard
Full Splash Enclosure	Standard
Way Protection	Standard
Air Blast	Configuration Dependent

---

DOOSAN MYNX 6500/50II – 2022 – CONTROL SYSTEM

Specification	Details
DOOSAN MYNX 6500/50II – 2022
CNC Control	FANUC-Based Configuration
Alternative Controls	Configuration Dependent
Programming	G-Code / ISO
Axis Control	X / Y / Z
4th-Axis Control	Optional
5th-Axis Control	Optional
Tool Offset Management	Standard
Work Offset Management	Standard
Macro Programming	Supported
Rigid Tapping	Supported
Diagnostics	Integrated

The MYNX II series was available with different CNC control configurations depending on region and machine specification.

---

DOOSAN MYNX 6500/50II – 2022 – POWER REQUIREMENTS

Specification	Details
DOOSAN MYNX 6500/50II – 2022
Electrical Service	Three-Phase
Input Voltage	Configuration Dependent
Frequency	50 / 60 Hz
Standard Spindle Motor	Approx. 15 kW / 20 HP
Optional Spindle Motor	Up to Approx. 30 kW / 40 HP
Shop Air	Required
Pneumatic System	Standard
Automatic Lubrication	Standard
Hydraulic System	Configuration Dependent
Installation	Industrial

---

DOOSAN MYNX 6500/50II – 2022 – DIMENSIONS

Specification	Details
DOOSAN MYNX 6500/50II – 2022
Machine Length	Approx. 119″ / 3,016 mm
Machine Width	Approx. 132″ / 3,350 mm
Machine Weight	Approx. 20,944 lbs / 9,500 kg
Machine Footprint	Heavy-Duty Vertical Machining Center
Rigging	Required
Foundation	Industrial Shop Floor
Chip Conveyor	Adds to Overall Footprint
Installation	Industrial

---

DOOSAN MYNX 6500/50II – 2022 – GENERAL INFORMATION

Specification	Details
DOOSAN MYNX 6500/50II – 2022
Manufacturer	Doosan
Model	MYNX 6500/50II
Year	2022
Machine Category	Heavy-Duty CNC Vertical Machining Center
Number of Axes	3 Standard
X-Axis Travel	50″ / 1,270 mm
Y-Axis Travel	26.4″ / 670 mm
Z-Axis Travel	24.6″ / 625 mm
Table Size	55.1″ x 26.4″
Maximum Table Load	2,866 lbs / 1,300 kg
Maximum Spindle Speed	6,000 RPM
Spindle Taper	ISO 50
Rapid Traverse	Up to 1,181 IPM
Tool Changer	24 Tools Standard Configuration

---

INDUSTRIES THAT USE DOOSAN MYNX 6500/50II

The DOOSAN MYNX 6500/50II is suitable for:

• Aerospace
• Automotive
• Oil & Gas
• Energy
• Heavy Equipment
• Construction Equipment
• Mold & Die
• Industrial Machinery
• Defense
• Power Generation
• Contract Manufacturing
• General Precision Machining

---

TYPICAL PARTS DOOSAN MYNX 6500/50II CAN PRODUCE

Typical components include:

• Large precision housings
• Gearbox components
• Hydraulic manifolds
• Pump bodies
• Valve components
• Heavy equipment parts
• Machine components
• Fixture plates
• Mold components
• Aerospace structural parts
• Energy-industry components
• Large production components

Typical operations include face milling, heavy-duty roughing, contour milling, pocketing, drilling, boring, tapping, rigid tapping, reaming, thread milling, and 4th-axis machining when equipped with a rotary table.

---

WHY CHOOSE DOOSAN MYNX 6500/50II

The DOOSAN MYNX 6500/50II is designed for manufacturers that need the rigidity and tooling capacity of a 50-taper vertical machining center. Its 50″ X-axis travel, 26.4″ Y-axis travel, and 24.6″ Z-axis travel provide a substantial machining envelope, while the 1,300 kg table capacity allows larger and heavier workpieces to be machined efficiently.

The 50-taper spindle system provides a more robust platform for heavy milling, large-diameter tooling, deep cuts, and demanding materials. Depending on the spindle configuration, buyers may also find machines equipped with higher-power and higher-torque spindle options.

For shops producing large components or requiring aggressive metal removal, the MYNX 6500/50II can offer a useful combination of machining capacity, spindle rigidity, and production flexibility.

---

WHY BUY USED DOOSAN MYNX 6500/50II – 2022

A used 2022 DOOSAN MYNX 6500/50II can provide relatively modern heavy-duty machining capability at a lower investment than purchasing a comparable new 50-taper machining center.

When evaluating a used machine, inspect the spindle, spindle bearings, X/Y/Z-axis ballscrews, guideways, servo motors, automatic tool changer, coolant system, lubrication system, CNC control, electrical cabinet, and machine enclosure.

Buyers should verify spindle runout, spindle noise, axis positioning accuracy, backlash, rapid traverse operation, tool-change reliability, coolant performance, and overall machine geometry.

Because MYNX machines can be supplied with different spindle, control, coolant, tool magazine, and automation configurations, the individual machine’s option list should be reviewed carefully. A machine equipped with high-torque spindle options, through-spindle coolant, chip conveyor, probing, additional tool capacity, or rotary tables may command a higher resale value.

---

HOW MUCH DOES A USED DOOSAN MYNX 6500/50II – 2022 COST?

The value of a used DOOSAN MYNX 6500/50II – 2022 depends on machine hours, spindle configuration, spindle condition, installed options, CNC control, tooling package, maintenance history, and overall cosmetic and mechanical condition.

USED DOOSAN MYNX 6500/50II – 2022 PRICE RANGE	ESTIMATED COST
High Hours / Basic Configuration	$75,000 – $100,000
Functional Production Machine	$100,000 – $130,000
Good Condition / Production Ready	$130,000 – $165,000
Excellent / Well Equipped	$165,000 – $210,000
Low Hours / Fully Equipped	$210,000+

For a 2022 DOOSAN MYNX 6500/50II in good working condition, a reasonable estimated market value is approximately $120,000–$185,000 USD, depending heavily on spindle configuration, machine hours, and installed equipment.

For an inventory listing, I would recommend an asking-price range of $150,000–$195,000 USD for a clean, production-ready machine equipped with desirable options such as a high-torque spindle, through-spindle coolant, chip conveyor, probing, and rotary capability.

Best estimated listing value: $150,000–$195,000 USD.
