USED DOOSAN DNM 5700 – 2019

The DOOSAN DNM 5700 2019 is a heavy-duty 3-Axis CNC Vertical Machining Center (VMC) designed for precision milling, drilling, tapping, boring, and general production machining. The DNM 5700 is part of Doosan’s widely used DNM Series, which was later continued under the DN Solutions brand. The series is known for its combination of rigidity, machining capability, precision, and reliability.

The 2019 DOOSAN DNM 5700 provides approximately 41.3″ of X-axis travel, 22.4″ of Y-axis travel, and 20.1″ of Z-axis travel, giving it a substantial machining envelope for medium and large components. Its approximately 51.2″ × 22.4″ table provides ample space for fixtures and workpieces, with a maximum table load of approximately 2,205 lb.

The machine uses an ISO 40 spindle with approximately 8,000 RPM maximum spindle speed, 25 HP spindle power, and approximately 87 ft-lb of torque. The standard DNM 5700 platform provides rapid traverse rates of approximately 1,417 IPM in X and Y and 1,181 IPM in Z.

Depending on the specific 2019 configuration, the machine may include a 30-tool or 40-tool automatic tool changer, chip conveyor, through-spindle coolant, probing, fourth-axis rotary table, high-pressure coolant, and additional tooling.

The DNM 5700 is particularly well suited for job shops, automotive, aerospace, defense, industrial equipment, hydraulic components, tooling, and general precision manufacturing.

DOOSAN DNM 5700 2019 – AXIS

DOOSAN DNM 5700 2019 – AXIS TRAVELS / WORK ENVELOPE

The published DNM 5700 specifications list 1,050 × 570 × 510 mm X/Y/Z travels and a 1,300 × 570 mm table with a maximum workpiece weight of approximately 1,000 kg.

DOOSAN DNM 5700 2019 – CAPACITY

DOOSAN DNM 5700 2019 – SPINDLE

The standard DNM 5700 specification lists an 8,000 RPM, 25 HP spindle with approximately 87 ft-lb of torque and an ISO #40 taper.

DOOSAN DNM 5700 2019 – TOOL CHANGER

DOOSAN DNM 5700 2019 – CONTROL SYSTEM

The exact CNC control should be verified from the individual machine’s serial number and control cabinet, as control configurations and options can vary between machines.

DOOSAN DNM 5700 2019 – FEEDRATES

The published DNM 5700 specifications list 36 m/min X and Y rapid traverse and 30 m/min Z rapid traverse.

DOOSAN DNM 5700 2019 – COOLANT / CHIP MANAGEMENT

DOOSAN DNM 5700 2019 – POWER REQUIREMENTS

DOOSAN DNM 5700 2019 – DIMENSIONS

The current published DNM 5700 specifications list dimensions of approximately 2,413 × 3,110 × 2,985 mm and a machine weight of approximately 6,500 kg (14,330 lb). Actual shipping dimensions can vary with options such as chip conveyors and coolant equipment.

DOOSAN DNM 5700 2019 – GENERAL INFORMATION

INDUSTRIES THAT USE DOOSAN DNM 5700 2019

The DOOSAN DNM 5700 2019 is suitable for a wide range of industries requiring reliable and productive CNC milling, including:

• Aerospace
• Automotive
• Defense
• Medical
• Oil and gas
• Hydraulics
• Industrial equipment
• Tool and die
• General manufacturing
• Precision engineering

Its combination of large X/Y travel, substantial table capacity, and 25 HP spindle makes it particularly useful for medium and larger components.

TYPICAL PARTS DOOSAN DNM 5700 2019 CAN PRODUCE

The DOOSAN DNM 5700 2019 can manufacture:

• Machine components
• Fixtures
• Tooling plates
• Mold components
• Die components
• Aerospace components
• Automotive components
• Hydraulic manifolds
• Pump components
• Industrial equipment parts
• Precision brackets
• Large housings

The machine can perform milling, drilling, tapping, boring, reaming, pocketing, contouring, face milling, and other 3-axis machining operations.

WHY CHOOSE DOOSAN DNM 5700 2019

The DOOSAN DNM 5700 2019 offers an excellent balance between machining capacity, rigidity, spindle power, and floor-space efficiency. Its 41.3″ X-axis travel provides substantial room for larger components, while the 22.4″ Y-axis travel and 20.1″ Z-axis travel provide a useful work envelope for a wide variety of machining applications.

The 25 HP spindle and approximately 87 ft-lb of torque allow the machine to handle demanding milling operations, while the ISO #40 spindle taper provides access to a widely used tooling standard.

The machine can also be equipped with a fourth-axis rotary table, allowing manufacturers to machine multiple faces of a component with fewer setups.

WHY BUY USED DOOSAN DNM 5700 2019

Purchasing a used DOOSAN DNM 5700 2019 allows manufacturers to obtain a relatively modern, large-capacity VMC while reducing the capital investment compared with purchasing new equipment.

Depending on configuration, a used machine may include:

• FANUC CNC control
• 25 HP spindle
• 8,000 RPM spindle
• ISO #40 tooling
• Automatic tool changer
• Chip conveyor
• Through-spindle coolant
• High-pressure coolant
• Renishaw probing
• Tool setter
• Fourth-axis rotary table
• Additional tooling packages

Before purchasing, buyers should inspect spindle condition and runout, ballscrews, linear guideways, machine geometry, tool changer operation, coolant system, lubrication system, CNC control, and fourth-axis equipment if installed. Spindle hours and maintenance records should also be reviewed.

HOW MUCH DOES A USED DOOSAN DNM 5700 2019 COST?

The value of a used DOOSAN DNM 5700 2019 depends on machine condition, spindle hours, CNC control, tool changer capacity, spindle configuration, installed options, tooling, and maintenance history.

Machines equipped with chip conveyors, through-spindle coolant, probing, tool setters, fourth-axis rotary tables, high-pressure coolant, and extensive tooling packages generally command higher resale values.

Depending on condition and configuration, a used DOOSAN DNM 5700 2019 typically sells within an estimated price range of $50,000 to $80,000 USD. Exceptionally clean, low-hour machines with substantial options may command higher prices, while machines requiring spindle, mechanical, or control repairs may sell for less.

A properly maintained DOOSAN DNM 5700 2019 remains a strong choice for manufacturers looking for a full-size 3-axis CNC vertical machining center with 41″ X-axis travel, 25 HP spindle power, and substantial workholding capacity.
