The DOOSAN DMV 3016LD is a high-performance CNC vertical machining center designed for precision milling of medium-sized components. Manufactured by Doosan Machine Tools (now DN Solutions), the DMV 3016LD is known for its rigid construction, large work envelope, and dependable spindle performance. The 2007 model remains highly desirable in the used CNC market because it offers industrial-grade machining capability at a competitive price.
The 2007 DOOSAN DMV 3016LD typically features 30 inches of X-axis travel, 16 inches of Y-axis travel, and 18 inches of Z-axis travel. The machine is equipped with a CAT 40 spindle with speeds up to 8,000 RPM and a spindle motor rated at approximately 20 hp. A 20-tool or 24-tool automatic tool changer provides flexibility for complex machining operations. The machine is well suited for machining steel, stainless steel, aluminum, cast iron, and engineering plastics.
The DMV 3016LD is widely used in aerospace, automotive, tooling, mold making, and general manufacturing. Typical applications include brackets, housings, fixture plates, molds, and precision machined components.
The 2007 DOOSAN DMV 3016LD remains an excellent investment because it combines proven reliability, strong cutting capability, and relatively low acquisition cost.
DOOSAN DMV 3016LD SPECIFICATIONS
DOOSAN DMV 3016LD – AXIS
Number of Axes
3-Axis CNC Vertical Machining Center
Axis Configuration
X, Y, Z
Optional 4th Axis
Yes
Positioning Accuracy
High Precision
Repeatability
Excellent
Machine Type
Vertical Machining Center
DOOSAN DMV 3016LD – AXIS TRAVELS
X-Axis Travel
30 in (760 mm)
Y-Axis Travel
16 in (410 mm)
Z-Axis Travel
18 in (460 mm)
Rapid Traverse Rate
1,181 ipm (30 m/min)
Spindle Nose to Table
Approx. 6 – 24 in
Guideway Type
Linear Guides
DOOSAN DMV 3016LD – CAPACITY
Table Size
36 x 16 in (920 x 410 mm)
Maximum Table Load
1,100 lb (500 kg)
Maximum Workpiece Size
Medium Components
Maximum Tool Weight
Approx. 17.6 lb (8 kg)
Maximum Tool Length
Approx. 11.8 in (300 mm)
Industrial Usage
Precision Milling
DOOSAN DMV 3016LD – SPINDLE
Spindle Taper
CAT 40
Maximum Spindle Speed
8,000 RPM
Spindle Motor Power
20 hp (15 kW)
Drive System
Belt Drive
Cooling System
Oil Cooled
Rigid Tapping
Standard
DOOSAN DMV 3016LD – TABLE
Table Length
36 in (920 mm)
Table Width
16 in (410 mm)
Number of T-Slots
3
T-Slot Size
0.63 in (16 mm)
Workholding Compatibility
Vises, Fixtures, Rotary Tables
Table Construction
Precision Ground Cast Iron
DOOSAN DMV 3016LD – TOOL TURRET
Tool Changer Capacity
20 – 24 Tools
Tool Changer Type
Automatic Carousel
Tool-to-Tool Time
Fast Automatic Change
Tool Taper
CAT 40
Tool Selection
Random Access
Maximum Tool Diameter
Standard CAT 40 Capacity
DOOSAN DMV 3016LD – FEEDRATES
Maximum Cutting Feed Rate
Programmable
Rapid Traverse Rate
1,181 ipm
Servo System
Digital AC Servo
Contouring Performance
Excellent
Surface Finish Capability
Excellent
High-Speed Machining
Good
DOOSAN DMV 3016LD – COOLANT & CHIP MANAGEMENT
Flood Coolant System
Standard
Chip Conveyor
Optional
Coolant Tank
Integrated
Coolant Filtration
Standard
Washdown Hose
Standard
Chip Auger
Optional
DOOSAN DMV 3016LD – CONTROL SYSTEM
CNC Control Brand
FANUC Control
Common Control Models
FANUC 18i-MB / 21i-MB
Programming Method
Standard G-Code
Memory Capacity
Depends on Control
DNC Capability
Yes
User Interface
Industry Standard
DOOSAN DMV 3016LD – POWER & AIR REQUIREMENTS
Power Requirement
3-Phase
Voltage
220V / 440V
Air Pressure Requirement
80 – 100 psi
Air Consumption
4 scfm
Frequency
50 / 60 Hz
Connected Load
Standard Industrial Power
DOOSAN DMV 3016LD – DIMENSIONS
Machine Weight
Approx. 9,000 lb (4,080 kg)
Machine Length
Approx. 98 in (2,489 mm)
Machine Width
Approx. 90 in (2,286 mm)
Machine Height
Approx. 105 in (2,667 mm)
Floor Space Requirement
Compact to Medium Footprint
Installation Type
Standard Shop Floor
DOOSAN DMV 3016LD – GENERAL INFORMATION
Machine Type
CNC Vertical Machining Center
Manufacturer
Doosan Machine Tools
Country of Origin
South Korea
Model Year
2007
Primary Application
Precision Milling
Automation Ready
Yes
INDUSTRIES THAT USE DOOSAN DMV 3016LD
Automotive
Brackets and Housings
Aerospace
Precision Components
Tooling
Fixture Plates
Mold Making
Mold Components
Medical
Precision Machined Parts
General Manufacturing
Custom Components
TYPICAL PARTS DOOSAN DMV 3016LD CAN PRODUCE
Brackets
Yes
Housings
Yes
Fixture Plates
Yes
Mold Components
Yes
Precision Blocks
Yes
Custom Aluminum Parts
Yes
WHY CHOOSE DOOSAN DMV 3016LD
Proven Reliability
Excellent
FANUC Control
Outstanding
Compact Footprint
Excellent
Strong Cutting Performance
Excellent
Easy Maintenance
Excellent
Resale Value
Good
WHY BUY USED DOOSAN DMV 3016LD
Purchasing a used 2007 DOOSAN DMV 3016LD is an excellent way to acquire a dependable CNC vertical machining center at a fraction of the cost of a new machine. Its rigid construction and proven FANUC control make it a strong choice for both prototype and production machining.
Many used machines include chip conveyors, rotary tables, tooling packages, and probing systems. These options can significantly increase productivity and reduce setup times. Because Doosan machines are known for durability, properly maintained units can continue delivering accurate performance for many years.
Buyers should inspect spindle condition, axis backlash, lubrication systems, and control operation. Machines with documented maintenance records and lower spindle hours generally command higher prices but offer greater reliability.
For shops seeking a cost-effective and versatile machining center, the 2007 DOOSAN DMV 3016LD offers excellent value and dependable long-term performance.
HOW MUCH DOES A USED DOOSAN DMV 3016LD COST?
MACHINE AGE / CONDITION
ESTIMATED PRICE RANGE (USD)
2005 – 2008 Models
$12,000 – $28,000
2009 – 2013 Models
$20,000 – $40,000
Low Spindle Hours
Premium Pricing
Machines with Chip Conveyor
Added Value
Machines with 4th Axis
Significant Premium
Refurbished Machines
15% – 30% Higher
Included Tooling and Holders
Added Value
Well-Maintained Machines
Higher Market Value
Excellent Mechanical Condition
Premium Pricing
Fully Operational Under Power
Higher Buyer Confidence
The cost of a used 2007 DOOSAN DMV 3016LD depends on spindle condition, machine accuracy, maintenance history, and included accessories. Most machines sell between $12,000 and $28,000, while exceptionally clean machines with low hours, tooling, and a 4th axis command higher prices.
Machines equipped with chip conveyors, rotary tables, and probing systems offer additional value and improved productivity. Buyers should also factor in rigging, transportation, and installation costs.
For manufacturers seeking a reliable and affordable CNC vertical machining center, the DOOSAN DMV 3016LD remains one of the best values in the used CNC market.
