USED DN SOLUTIONS PUMA TT1800MS

The DN Solutions PUMA TT1800MS is a high-performance twin-spindle, twin-turret CNC turning center designed for manufacturers that require exceptional productivity, precision, and machining flexibility. As part of the advanced PUMA TT Series, the TT1800MS combines dual synchronized spindles, upper and lower live-tool turrets, automatic part transfer, and C-axis machining into one highly efficient production platform. Built specifically for high-volume manufacturing, the machine enables simultaneous machining on both spindles, dramatically reducing cycle times while maximizing spindle utilization. Its robust construction and advanced multi-tasking capabilities make it an excellent solution for automotive, aerospace, medical device, electronics, hydraulic, and precision contract manufacturing applications.

Unlike conventional CNC lathes that perform one operation at a time, the PUMA TT1800MS allows both turrets to machine independently and simultaneously. While one turret performs turning or live-tool machining on the main spindle, the second turret can machine the sub-spindle or complete secondary operations. This synchronized machining process significantly improves throughput while reducing labor requirements and work-in-process inventory.

The machine features an 8-inch chuck on both the main and sub-spindles, a maximum turning diameter of approximately 9 inches, and a maximum turning length of approximately 9 inches. These specifications make it ideal for manufacturing medium-sized precision components including valve bodies, hydraulic fittings, transmission components, bearing housings, shafts, couplings, and other complex machined parts. The integrated sub-spindle enables complete front and back machining within a single automated cycle, eliminating the need for secondary operations.

Constructed on a rigid cast iron slant-bed platform with precision roller linear guideways, the PUMA TT1800MS provides excellent vibration resistance, thermal stability, and machining accuracy. High-speed rapid traverse rates and powerful spindle motors allow manufacturers to maintain excellent productivity while achieving outstanding surface finishes.

The machine is equipped with FANUC CNC controls that coordinate simultaneous spindle and turret operation while simplifying programming for complex machining cycles. In the used CNC machinery market, the PUMA TT1800MS continues to be highly desirable because it combines advanced twin-spindle productivity, dependable reliability, and excellent machining performance at a substantially lower investment than purchasing new equipment.

---

DN SOLUTIONS PUMA TT1800MS – AXIS

Specification	Value
Number of Axes	6 Axis
X-Axis Travel	6 in
Z-Axis Travel	28 in
C-Axis	Main & Sub Spindle
X-Axis Rapid Traverse	787 IPM
Z-Axis Rapid Traverse	1,575 IPM

---

DN SOLUTIONS PUMA TT1800MS – AXIS TRAVELS / WORK ENVELOPE

Specification	Value
Maximum Turning Diameter	9 in
Maximum Turning Length	9 in
Bar Capacity	3.2 in
Machining Type	Twin-Spindle Multi-Tasking
Simultaneous Machining	Yes

---

DN SOLUTIONS PUMA TT1800MS – CAPACITY / TABLE

Specification	Value
Main Chuck Size	8 in
Sub Chuck Size	8 in
Maximum Workpiece Diameter	9 in
Maximum Workpiece Length	9 in
Automatic Part Transfer	Yes
Production Type	High-Volume Precision Manufacturing

---

DN SOLUTIONS PUMA TT1800MS – SPINDLE

Specification	Value
Main Spindle Speed	5,000 RPM
Sub Spindle Speed	5,000 RPM
Main Spindle Power	29 HP
Sub Spindle Power	29 HP
Main Spindle Torque	153 ft-lb
Drive Type	AC Digital Servo

---

DN SOLUTIONS PUMA TT1800MS – TOOL CHANGER

Specification	Value
Upper Turret Stations	12
Lower Turret Stations	12
Total Tool Positions	24
Live Tool Speed	6,000 RPM
Live Tool Capability	Yes
Tool Configuration	Twin Live Tool Turrets

---

DN SOLUTIONS PUMA TT1800MS – CONTROL SYSTEM

Specification	Value
CNC Control	FANUC CNC
Simultaneous Turret Control	Yes
Ethernet Connectivity	Yes
USB Interface	Yes
Network Capability	Supported
Conversational Programming	Supported

---

DN SOLUTIONS PUMA TT1800MS – COOLANT / DUST / WATER MANAGEMENT

Specification	Value
Coolant System	Flood Coolant
High-Pressure Coolant	Optional
Chip Conveyor	Automatic
Coolant Filtration	Multi-Stage
Coolant Tank	Large Capacity
Machine Enclosure	Fully Enclosed

---

DN SOLUTIONS PUMA TT1800MS – POWER REQUIREMENTS

Specification	Value
Electrical Supply	220V / 440V 3-Phase
Connected Load	Approx. 55 kVA
Main Disconnect	Included
Electrical Protection	Industrial Grade

---

DN SOLUTIONS PUMA TT1800MS – DIMENSIONS

Specification	Value
Machine Length	154 in
Machine Width	89 in
Machine Height	82 in
Machine Weight	19,400 lbs

---

DN SOLUTIONS PUMA TT1800MS – GENERAL INFORMATION

Specification	Value
Manufacturer	DN Solutions
Model	PUMA TT1800MS
Machine Type	Twin-Spindle Twin-Turret CNC Turning Center
Construction	Heavy-Duty Cast Iron
Primary Application	High-Volume Multi-Tasking Machining
Control System	FANUC
Industry Focus	Automotive, Aerospace, Medical, Electronics

---

WHY BUY USED DN SOLUTIONS PUMA TT1800MS

The DN Solutions PUMA TT1800MS is an outstanding investment for manufacturers seeking high productivity while controlling capital expenditures. Purchasing a used machine provides access to advanced twin-spindle machining technology at a substantially lower cost than purchasing a comparable new machine.

One of the machine’s greatest advantages is simultaneous machining. The upper and lower turrets operate independently, allowing multiple machining operations to occur at the same time. This dramatically shortens cycle times while maximizing spindle utilization and overall equipment efficiency.

The twin-spindle configuration also improves manufacturing workflow. Parts can be automatically transferred from the main spindle to the sub-spindle for complete back-side machining without manual intervention. This reduces handling, improves dimensional consistency, and minimizes setup errors.

Live tooling greatly expands machining capability by allowing milling, drilling, tapping, and threading operations to be completed directly on the machine. Manufacturers can complete complex components in one setup while eliminating secondary machining operations and reducing production lead times.

DN Solutions machines are recognized worldwide for exceptional durability. The rigid cast iron construction, roller linear guideways, high-speed spindle systems, and FANUC CNC controls deliver reliable long-term performance in demanding production environments.

Many used PUMA TT1800MS machines include valuable accessories such as automatic bar feeders, chip conveyors, parts catchers, tooling packages, high-pressure coolant systems, and robotic loading interfaces. These features further increase production efficiency while reducing implementation costs.

For manufacturers producing precision components in medium to high volumes, the used PUMA TT1800MS provides outstanding value through improved productivity, reduced labor costs, shorter cycle times, and proven long-term reliability.

---

HOW MUCH DOES A USED DN SOLUTIONS PUMA TT1800MS COST?

The price of a used DN Solutions PUMA TT1800MS depends on machine age, operating hours, maintenance history, tooling packages, automation equipment, and overall condition. Because the machine incorporates twin synchronized spindles, dual live-tool turrets, automatic part transfer, and simultaneous machining capability, it generally commands strong resale values within the used CNC marketplace.

Machine condition is one of the primary factors affecting value. Buyers commonly inspect spindle condition, turret synchronization, live tooling performance, guideway wear, hydraulic systems, and CNC functionality. Machines with documented maintenance histories and lower operating hours typically command premium prices.

Optional equipment also has a significant impact on resale value. Automatic bar feeders, robotic loading systems, parts catchers, chip conveyors, probing systems, high-pressure coolant packages, and complete tooling packages all increase machine productivity and frequently justify higher asking prices.

Demand from automotive, aerospace, medical device, electronics, hydraulic, and precision contract manufacturing industries helps maintain healthy resale values for the TT1800MS. These industries rely on highly productive multi-tasking turning centers capable of reducing cycle times while maintaining exceptional part quality.

Generally, a used DN Solutions PUMA TT1800MS can range from approximately $150,000 to over $375,000, depending on age, operating hours, condition, tooling, automation equipment, and included accessories. Machines equipped with complete automation packages and low operating hours typically command premium prices.

For manufacturers seeking maximum production efficiency, investing in a used PUMA TT1800MS delivers increased throughput, improved machining flexibility, lower operating costs, and an excellent long-term return on investment.

---

INDUSTRIES THAT USE DN SOLUTIONS PUMA TT1800MS

• Automotive Manufacturing
• Aerospace Manufacturing
• Medical Device Manufacturing
• Electronics Manufacturing
• Hydraulic Component Manufacturing
• Fluid Power Manufacturing
• Precision Contract Manufacturing
• Defense Manufacturing
• Industrial Machinery Manufacturing
• General Precision Engineering

---

TYPICAL PARTS DN SOLUTIONS PUMA TT1800MS CAN PRODUCE

• Hydraulic Valve Bodies
• Transmission Components
• Bearing Housings
• Precision Shafts
• Couplings
• Medical Components
• Aerospace Connectors
• Hydraulic Fittings
• Pneumatic Components
• Sensor Housings
• Precision Bushings
• Turned and Milled Precision Components

---

WHY CHOOSE DN SOLUTIONS PUMA TT1800MS

The DN Solutions PUMA TT1800MS combines twin synchronized spindles, dual live-tool turrets, automatic part transfer, and advanced CNC technology into one highly productive manufacturing platform. Its ability to perform simultaneous machining operations dramatically reduces cycle times while improving machining accuracy and production efficiency.

Manufacturers choose the PUMA TT1800MS because it maximizes spindle utilization, minimizes setup time, supports unattended production, and consistently delivers high-quality precision components. With its proven durability, advanced multi-tasking capabilities, and exceptional production performance, the PUMA TT1800MS remains one of the leading twin-spindle CNC turning centers available in the used machinery market.
