USED DN SOLUTIONS PUMA 3100UL

The DN SOLUTIONS PUMA 3100UL is a heavy-duty long-bed CNC horizontal turning center designed for machining extremely long and large-diameter components with exceptional accuracy, rigidity, and reliability. As part of the advanced PUMA 2100/2600/3100 series from DN SOLUTIONS, formerly known as Doosan Machine Tools, the PUMA 3100UL extends the capabilities of the standard PUMA 3100 platform by offering an extended Z-axis travel and significantly longer turning length. This makes it an ideal solution for manufacturers producing oversized shafts, rollers, cylinders, and other elongated precision components. The PUMA 3100UL features a 12-inch chuck, approximately 21-inch maximum turning diameter, and an impressive 124-inch maximum turning length, making it one of the largest machines in the PUMA 3100 family.

The machine is engineered with a robust cast iron machine structure and heavy-duty box guideway design to provide outstanding vibration absorption and thermal stability during demanding machining applications. Its rigid construction enables aggressive metal removal while maintaining excellent dimensional accuracy and surface finish. The powerful main spindle delivers high torque, allowing the machine to efficiently process difficult materials including alloy steel, stainless steel, cast iron, titanium, aluminum, and other high-performance engineering materials.

Unlike smaller CNC turning centers that are limited by work envelope, the PUMA 3100UL is specifically designed to accommodate extra-long workpieces while maintaining the precision expected from modern CNC equipment. The extended bed design, long Z-axis travel, and large machining capacity allow manufacturers to complete long turning operations without repositioning the workpiece. This reduces setup time, improves concentricity, and ensures greater consistency across production runs.

The DN SOLUTIONS PUMA 3100UL is commonly equipped with a FANUC CNC control system that provides reliable programming, advanced turning cycles, tool management functions, and machine diagnostic capabilities. The machine utilizes a high-rigidity turret system capable of supporting various turning operations including facing, boring, threading, grooving, profiling, and precision finishing. Optional accessories such as programmable tailstocks, steady rests, automatic chip conveyors, high-pressure coolant systems, and automation solutions can further increase productivity and support demanding manufacturing requirements.

Industries including oil and gas, aerospace, power generation, marine, heavy equipment, construction machinery, agricultural equipment, and general precision manufacturing frequently utilize the PUMA 3100UL for large and long components. Typical applications include drive shafts, hydraulic cylinders, rollers, turbine shafts, pump shafts, large couplings, threaded shafts, and custom industrial parts.

The used CNC machine market continues to show strong demand for the DN SOLUTIONS PUMA 3100UL because it offers large-capacity machining, exceptional durability, and proven long-term reliability at a considerably lower investment compared with purchasing a new machine. Its combination of extended turning capacity, heavy-duty construction, and advanced CNC technology makes it an excellent choice for manufacturers looking to expand long-part machining capabilities.

---

DN SOLUTIONS PUMA 3100UL – AXIS

Specification	Details
Number of Controlled Axes	2 Axis
X-Axis	Cross Slide Turning Axis
Z-Axis	Longitudinal Turning Axis
Machine Configuration	Horizontal CNC Turning Center
Live Tool Capability	No

---

DN SOLUTIONS PUMA 3100UL – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
X-Axis Travel	12 in (293 mm)
Z-Axis Travel	126 in (3,190 mm)
X-Axis Rapid Traverse	1,181 IPM (30 m/min)
Z-Axis Rapid Traverse	1,024 IPM (26 m/min)
Maximum Turning Diameter	21 in (525 mm)
Maximum Turning Length	124 in (3,150 mm)

---

DN SOLUTIONS PUMA 3100UL – CAPACITY / TABLE

Specification	Details
Chuck Size	12 in Hydraulic Chuck
Maximum Workpiece Diameter	21 in (525 mm)
Maximum Workpiece Length	124 in (3,150 mm)
Maximum Bar Capacity	Approximately 4 in
Work Holding	Hydraulic Chuck, Soft Jaws, Hard Jaws, Faceplates, and Custom Fixtures

---

DN SOLUTIONS PUMA 3100UL – SPINDLE

Specification	Details
Maximum Spindle Speed	2,800 RPM
Spindle Power	35 HP (26 kW)
Maximum Spindle Torque	828 ft-lb (1,123 Nm)
Spindle Type	High-Torque Heavy-Duty Spindle
Spindle Nose	A2-11

---

DN SOLUTIONS PUMA 3100UL – TOOL CHANGER

Specification	Details
Turret Type	Heavy-Duty Servo Turret
Number of Tool Stations	10 Stations
Tool Type	External and Internal Turning Tools
Indexing System	Automatic Turret Indexing
Live Tooling	Not Available

---

DN SOLUTIONS PUMA 3100UL – CONTROL SYSTEM

Specification	Details
CNC Control	FANUC Series Control
Programming	Standard G-Code Programming
Operator Interface	Color LCD Display
Features	Turning Cycles, Tool Offsets, Diagnostics, and Production Monitoring

---

DN SOLUTIONS PUMA 3100UL – COOLANT / DUST / WATER MANAGEMENT

Specification	Details
Coolant System	Flood Coolant System
High-Pressure Coolant	Optional Depending on Configuration
Chip Removal	Automatic Chip Conveyor Available
Coolant Filtration	Multi-Stage Filtration System
Enclosure	Fully Enclosed Splash Guard

---

DN SOLUTIONS PUMA 3100UL – POWER REQUIREMENTS

Specification	Details
Electrical Requirement	220V / 380V / 440V Three Phase (Configuration Dependent)
Connected Load	Approximately 45–55 kVA
Pneumatic Requirement	Clean Dry Compressed Air

---

DN SOLUTIONS PUMA 3100UL – DIMENSIONS

Specification	Details
Machine Length	259 in (6,585 mm)
Machine Width	90 in (2,280 mm)
Machine Height	91 in (2,315 mm)
Machine Weight	Approximately 25,684 lbs (11,650 kg)

---

DN SOLUTIONS PUMA 3100UL – GENERAL INFORMATION

Specification	Details
Manufacturer	DN SOLUTIONS
Model	PUMA 3100UL
Machine Type	Long-Bed CNC Horizontal Turning Center
Machine Condition	Used
Typical Operations	Turning, Facing, Boring, Threading, Grooving, and Finishing
Automation Compatibility	Tailstocks, Steady Rests, Chip Conveyors, and Robotic Loading Systems

---

INDUSTRIES THAT USE DN SOLUTIONS PUMA 3100UL

The DN SOLUTIONS PUMA 3100UL is widely used by industries that require the machining of long, heavy, and high-precision components. The oil and gas industry relies on the machine for producing drilling equipment, long valve components, pump shafts, connectors, and pressure-control parts that require superior dimensional accuracy and material strength.

Aerospace manufacturers use the PUMA 3100UL for producing structural shafts, landing gear components, actuator shafts, and other elongated parts manufactured from high-strength alloys. The power generation industry utilizes the machine for turbine shafts, generator components, and rotating equipment requiring excellent surface finishes and tight tolerances.

Additional applications include marine propulsion components, construction equipment shafts, agricultural machinery, hydraulic cylinders, industrial rollers, and general contract machining. The machine’s extended 124-inch turning length allows manufacturers to produce large components in a single setup, reducing alignment errors and improving overall production efficiency.

---

TYPICAL PARTS DN SOLUTIONS PUMA 3100UL CAN PRODUCE

The DN SOLUTIONS PUMA 3100UL can manufacture a broad range of long and heavy components including drive shafts, hydraulic cylinder rods, turbine shafts, pump shafts, industrial rollers, threaded shafts, couplings, bushings, bearing housings, and custom engineered components.

Its large work envelope allows manufacturers to produce oversized parts that exceed the capabilities of standard CNC lathes. The machine is especially beneficial for components requiring extensive longitudinal turning, precision threading, and high-quality surface finishes over long distances.

The PUMA 3100UL is suitable for prototype work, repair applications, small production runs, and high-volume manufacturing. Its rigid structure, powerful spindle, and precise CNC control system ensure excellent repeatability and consistent machining quality even during heavy-duty cutting operations.

---

WHY CHOOSE DN SOLUTIONS PUMA 3100UL

The DN SOLUTIONS PUMA 3100UL is an ideal solution for manufacturers requiring exceptional long-part machining capability. With its 124-inch maximum turning length and rigid heavy-duty construction, it provides the capacity necessary to machine oversized components without sacrificing precision or productivity.

The machine’s robust box guideway construction and high-torque spindle allow aggressive material removal while maintaining excellent accuracy and surface finish. The 10-station servo turret provides dependable tool changes and supports a wide range of turning applications.

Another major advantage of the PUMA 3100UL is its compatibility with production-enhancing accessories including programmable tailstocks, steady rests, chip conveyors, and automated loading systems. These options allow manufacturers to improve spindle utilization and handle challenging long components with greater efficiency.

The PUMA series is known throughout the manufacturing industry for durability, reliability, and long service life. For companies requiring a powerful long-bed CNC turning solution, the PUMA 3100UL delivers outstanding capacity, precision, and long-term value.

---

WHY BUY USED DN SOLUTIONS PUMA 3100UL

Purchasing a used DN SOLUTIONS PUMA 3100UL provides manufacturers with access to a large-capacity CNC turning center at a significantly lower cost than purchasing a new machine. Large long-bed CNC lathes represent a major investment when purchased new, making the used market an attractive option for shops seeking increased capacity while controlling capital expenses.

One of the biggest advantages of purchasing a used PUMA 3100UL is the ability to machine extremely long parts in a single setup. This reduces the need for repositioning, minimizes alignment errors, and improves overall part accuracy. Companies manufacturing long shafts, cylinders, rollers, and industrial components benefit greatly from this capability.

The machine’s heavy cast iron construction, high-torque spindle, reliable turret system, and proven FANUC control are designed for demanding industrial environments. A properly maintained used machine can continue delivering excellent productivity and dependable performance for many years.

Used CNC equipment is generally available with shorter lead times compared with new machines, allowing manufacturers to increase production capacity quickly. The savings gained from purchasing a used machine can be invested into additional tooling, workholding systems, quality inspection equipment, and production improvements.

The strong reputation of DN SOLUTIONS machinery helps maintain excellent resale value, making the PUMA 3100UL a smart investment for manufacturers requiring heavy-duty long-part machining.

---

HOW MUCH DOES A USED DN SOLUTIONS PUMA 3100UL COST?

The price of a used DN SOLUTIONS PUMA 3100UL depends on factors including the machine’s age, operating hours, overall condition, maintenance records, CNC control version, included tooling, and optional equipment such as steady rests, tailstocks, chip conveyors, and high-pressure coolant systems.

A used DN SOLUTIONS PUMA 3100UL typically ranges between $90,000 and $250,000, depending on the machine’s configuration, condition, and included accessories. Newer machines with lower operating hours, extensive tooling packages, and documented maintenance histories generally sell toward the higher end of the market.

Before purchasing a used PUMA 3100UL, buyers should inspect spindle condition, axis movement, turret indexing accuracy, lubrication systems, hydraulic components, coolant systems, and CNC control functionality. A thorough inspection helps identify any potential service requirements and ensures the machine will provide reliable long-term operation.

Additional expenses such as transportation, rigging, installation, electrical connection, tooling, operator training, and preventive maintenance should be considered when calculating the total investment. Even after these costs, a used PUMA 3100UL remains a significantly more economical solution compared with purchasing a comparable new long-bed CNC turning center.

For manufacturers requiring exceptional turning length, heavy-duty construction, powerful spindle performance, and dependable CNC technology, the used DN SOLUTIONS PUMA 3100UL offers an outstanding combination of capacity, accuracy, and long-term manufacturing value.
