USED DN SOLUTIONS PUMA 3100SY

The DN SOLUTIONS PUMA 3100SY is a high-performance CNC turning center designed with a sub-spindle, Y-axis capability, and live tooling technology to provide complete multi-tasking machining in a single setup. As part of the advanced PUMA 2100/2600/3100 series from DN SOLUTIONS, formerly known as Doosan Machine Tools, the PUMA 3100SY combines the strength of a heavy-duty CNC lathe with the flexibility of milling, drilling, tapping, and secondary spindle operations. This advanced machine is engineered to maximize productivity, reduce cycle times, and produce highly complex components with exceptional accuracy.

Unlike traditional CNC lathes that require multiple machines and setups to complete a component, the PUMA 3100SY integrates a main spindle, sub-spindle, C-axis positioning, Y-axis movement, and a live tooling turret. This configuration enables complete machining of both the front and back sides of a component in a single cycle. Parts can be transferred automatically from the main spindle to the sub-spindle, eliminating manual handling, improving concentricity, and reducing overall manufacturing time.

The machine is built with a rigid cast iron structure and heavy-duty box guideway construction designed to maintain stability during aggressive roughing and precision finishing operations. Its powerful spindle systems provide excellent torque and cutting performance across a wide range of materials including stainless steel, alloy steel, titanium, aluminum, brass, cast iron, and exotic alloys. The robust construction and precision engineering make the PUMA 3100SY suitable for continuous production environments requiring consistent accuracy and reliability.

Most DN SOLUTIONS PUMA 3100SY machines are equipped with advanced FANUC CNC controls that provide powerful programming functions, synchronized spindle operations, turning and milling cycles, tool management, and machine diagnostics. The rigid BMT live tooling turret provides excellent milling performance, while the Y-axis enables off-center machining such as cross holes, slots, pockets, and complex contours. Optional equipment such as high-pressure coolant systems, automatic chip conveyors, bar feeders, parts catchers, and robotic automation further increase productivity.

The DN SOLUTIONS PUMA 3100SY is widely used in aerospace, automotive, medical, defense, oil and gas, electronics, hydraulic systems, and general precision manufacturing. Typical components include valve bodies, aerospace fittings, hydraulic manifolds, shafts, connectors, couplings, medical implants, pump components, and other complex parts requiring complete machining from multiple sides.

The popularity of the used DN SOLUTIONS PUMA 3100SY remains strong because it provides advanced multi-tasking capabilities at a significantly lower investment than purchasing a new machine. With its combination of dual spindle technology, Y-axis flexibility, live tooling, and proven PUMA-series durability, the machine offers excellent value for manufacturers seeking increased efficiency and reduced production costs.

---

DN SOLUTIONS PUMA 3100SY – AXIS

Specification	Details
Number of Controlled Axes	5 Axis (X, Z, Y, C1, C2)
X-Axis	Cross Slide Turning Axis
Z-Axis	Longitudinal Turning Axis
Y-Axis	Off-Center Milling and Complex Machining Axis
C-Axis	Main and Sub-Spindle Positioning
Live Tool Capability	Yes

---

DN SOLUTIONS PUMA 3100SY – AXIS TRAVELS / WORK ENVELOPE

Specification	Details
X-Axis Travel	Approximately 12 in (300 mm)
Y-Axis Travel	Approximately ±4 in (105 mm)
Z-Axis Travel	Approximately 33 in (830 mm)
Rapid Traverse Rate	Approximately 1,181 IPM (30 m/min)
Maximum Turning Diameter	Approximately 17 in (420 mm)
Maximum Turning Length	Approximately 30 in (765 mm)

---

DN SOLUTIONS PUMA 3100SY – CAPACITY / TABLE

Specification	Details
Main Chuck Size	12 in Hydraulic Chuck
Sub-Spindle Chuck Size	8 in Hydraulic Chuck
Maximum Turning Diameter	Approximately 17 in (420 mm)
Maximum Turning Length	Approximately 30 in (765 mm)
Maximum Bar Capacity	Approximately 4 in
Work Holding	Hydraulic Chucks, Collets, Soft Jaws, Hard Jaws, and Custom Fixtures

---

DN SOLUTIONS PUMA 3100SY – SPINDLE

Specification	Main Spindle	Sub-Spindle
Maximum Speed	2,800 RPM	4,500 RPM
Spindle Power	35 HP (26 kW)	20 HP (15 kW)
Spindle Torque	828 ft-lb (1,123 Nm)	Approximately 150 ft-lb
Spindle Nose	A2-11	A2-6
Spindle Type	Heavy-Duty Built-In Spindle	High-Speed Secondary Spindle

---

DN SOLUTIONS PUMA 3100SY – TOOL CHANGER

Specification	Details
Turret Type	BMT Servo-Driven Live Tool Turret
Number of Tool Stations	12 Stations
Live Tool Speed	Approximately 5,000 RPM
Tool Configuration	Static and Rotary Tool Holders
Tool Indexing	Automatic Servo Turret Indexing

---

DN SOLUTIONS PUMA 3100SY – CONTROL SYSTEM

Specification	Details
CNC Control	FANUC Series Control
Programming	Standard G-Code, Turning, and Milling Cycles
Operator Interface	Color LCD Display
Features	Dual-Spindle Synchronization, Tool Management, Diagnostics, and Production Monitoring

---

DN SOLUTIONS PUMA 3100SY – COOLANT / DUST / WATER MANAGEMENT

Specification	Details
Coolant System	Flood Coolant System
High-Pressure Coolant	Available Depending on Configuration
Chip Removal	Automatic Chip Conveyor Available
Coolant Filtration	Multi-Stage Filtration System
Enclosure	Fully Enclosed Machining Area

---

DN SOLUTIONS PUMA 3100SY – POWER REQUIREMENTS

Specification	Details
Electrical Requirement	220V / 380V / 440V Three Phase (Configuration Dependent)
Connected Load	Approximately 55–70 kVA
Pneumatic Requirement	Clean, Dry Compressed Air

---

DN SOLUTIONS PUMA 3100SY – DIMENSIONS

Specification	Details
Machine Length	Approximately 160 in (4,060 mm)
Machine Width	Approximately 85 in (2,160 mm)
Machine Height	Approximately 90 in (2,285 mm)
Machine Weight	Approximately 18,500 lbs (8,400 kg)

---

DN SOLUTIONS PUMA 3100SY – GENERAL INFORMATION

Specification	Details
Manufacturer	DN SOLUTIONS
Model	PUMA 3100SY
Machine Type	CNC Turning Center with Y-Axis, Live Tooling, and Sub-Spindle
Machine Condition	Used
Typical Operations	Turning, Milling, Drilling, Tapping, Boring, Threading, Back-Side Machining, and Complex Multi-Axis Operations
Automation Compatibility	Bar Feeders, Parts Catchers, Chip Conveyors, Gantry Systems, and Robotic Loading Systems

---

INDUSTRIES THAT USE DN SOLUTIONS PUMA 3100SY

The DN SOLUTIONS PUMA 3100SY serves industries requiring highly complex and complete part machining. Aerospace manufacturers use the machine to produce precision fittings, connectors, actuator components, and structural parts requiring tight tolerances and multiple machining operations. The automotive industry relies on the PUMA 3100SY for manufacturing transmission components, drive systems, electric vehicle parts, and high-volume precision components.

Oil and gas manufacturers use the machine for valves, connectors, couplings, hydraulic components, and pressure-control parts manufactured from difficult materials. Medical manufacturers benefit from the machine’s ability to produce implants, surgical components, and precision instruments requiring superior accuracy and surface finishes.

Additional applications include defense, electronics, hydraulic equipment, energy production, and general contract machining. The combination of a sub-spindle, Y-axis, and live tooling makes the PUMA 3100SY ideal for reducing production steps while maintaining consistent quality and repeatability.

---

TYPICAL PARTS DN SOLUTIONS PUMA 3100SY CAN PRODUCE

The DN SOLUTIONS PUMA 3100SY can produce a wide range of complex components including valve bodies, hydraulic manifolds, aerospace fittings, connectors, couplings, shafts, bushings, medical components, pump parts, threaded fittings, and custom precision components.

The machine’s ability to transfer parts between the main spindle and sub-spindle allows complete front and back machining within one cycle. Combined with Y-axis milling and live tooling, the machine can create cross holes, milled flats, slots, pockets, keyways, threads, and intricate geometric features without requiring additional setups.

The PUMA 3100SY is suitable for prototype development, low-volume custom manufacturing, and high-volume production. Its robust construction, advanced CNC capabilities, and multi-tasking design enable manufacturers to achieve excellent productivity, repeatability, and part quality.

---

WHY CHOOSE DN SOLUTIONS PUMA 3100SY

The DN SOLUTIONS PUMA 3100SY is an excellent choice for manufacturers looking for a complete machining solution capable of handling complex components in one setup. The combination of a powerful main spindle, high-speed sub-spindle, Y-axis movement, and live tooling eliminates multiple secondary operations and significantly reduces production time.

Its heavy-duty box guideway construction provides excellent stability during demanding cutting operations, while the BMT live tooling system delivers superior milling rigidity and accuracy. The ability to perform turning, milling, drilling, tapping, and back-side machining on a single machine increases efficiency and improves part consistency.

The PUMA 3100SY is also compatible with automation technologies such as bar feeders, parts catchers, and robotic loading systems, making it suitable for high-volume and unattended production environments.

The proven reliability and durability of the PUMA series, combined with advanced multi-tasking capabilities, make the PUMA 3100SY a valuable machine for manufacturers seeking greater productivity, flexibility, and long-term manufacturing performance.

---

WHY BUY USED DN SOLUTIONS PUMA 3100SY

Purchasing a used DN SOLUTIONS PUMA 3100SY provides access to an advanced dual-spindle, Y-axis CNC turning center at a substantially lower investment compared with buying new equipment. The machine combines multiple manufacturing processes into one platform, reducing the need for secondary machining operations, minimizing labor costs, and improving workflow efficiency.

One of the biggest advantages of a used PUMA 3100SY is the ability to complete both primary and secondary spindle operations in a single cycle. This reduces workpiece handling, improves accuracy, and shortens production times. Manufacturers producing complex components with multiple features greatly benefit from this capability.

The machine’s rigid cast iron construction, powerful spindle systems, precision BMT turret, and reliable FANUC control are engineered for continuous production and long-term durability. A properly maintained used machine can provide many years of dependable service and excellent return on investment.

Used machines generally offer faster availability than new equipment, allowing manufacturers to expand capacity quickly. The savings achieved can be invested into tooling, automation systems, quality inspection equipment, and additional manufacturing resources.

Because of the strong reputation and demand for DN SOLUTIONS equipment, the PUMA 3100SY maintains excellent resale value, making it a practical and cost-effective solution for companies requiring advanced multi-tasking CNC machining.

---

HOW MUCH DOES A USED DN SOLUTIONS PUMA 3100SY COST?

The price of a used DN SOLUTIONS PUMA 3100SY depends on factors such as the machine’s age, spindle hours, condition, CNC control version, maintenance history, included tooling, and optional features. Machines equipped with high-pressure coolant, additional live tooling, bar feeders, automation systems, and extensive tooling packages generally command higher prices.

A used DN SOLUTIONS PUMA 3100SY typically ranges between $150,000 and $350,000, depending on its configuration, age, and overall condition. Newer machines with low operating hours, advanced options, and documented maintenance records generally sell at premium prices.

Before purchasing a used PUMA 3100SY, buyers should evaluate spindle condition, spindle synchronization accuracy, Y-axis performance, live tooling capability, turret indexing, hydraulic systems, lubrication systems, and CNC control operation. A complete inspection helps ensure the machine will deliver reliable long-term performance.

Additional costs including transportation, rigging, installation, electrical setup, tooling, operator training, and scheduled maintenance should also be considered when calculating the total investment. Even after these expenses, a used PUMA 3100SY remains significantly more affordable than a new comparable multi-tasking turning center.

For manufacturers seeking a powerful CNC machine capable of complete front-and-back machining, Y-axis milling, live tooling, and high-production efficiency, the used DN SOLUTIONS PUMA 3100SY provides an exceptional combination of versatility, precision, and long-term value.
