The DN Solutions HM 1000 is a large-capacity CNC horizontal machining center engineered for manufacturers that require exceptional rigidity, high torque, and superior machining performance on oversized workpieces. Built with a heavy-duty box guideway construction and a rigid one-piece cast iron machine structure, the HM 1000 is designed to deliver outstanding stability during heavy roughing and precision finishing operations. A high-torque gearbox-driven spindle, shuttle-type automatic pallet changer (APC), servo-driven automatic tool changer (ATC), and advanced spindle cooling system ensure maximum productivity, excellent machining accuracy, and long-term reliability. The HM 1000 is ideal for machining large steel fabrications, castings, heavy equipment components, wind energy parts, aerospace structures, oil & gas equipment, and industrial machinery.
The machine provides 83 inches (2,100 mm) of X-axis travel, 49 inches (1,250 mm) of Y-axis travel, and 49 inches (1,250 mm) of Z-axis travel, offering a massive machining envelope for large workpieces. It features a 39 × 39 inch (1,000 × 1,000 mm) twin-pallet system capable of supporting workpieces weighing up to 6,614 lbs (3,000 kg). The standard 6,000 RPM ISO 50 gearbox-driven spindle delivers 35 HP (26 kW) with an optional 8,000 RPM spindle producing 50 HP (37 kW). Maximum spindle torque reaches 1,467 ft-lb (1,989 Nm), while the optional spindle delivers an impressive 2,719 ft-lb (3,687 Nm) for extremely demanding heavy-duty machining applications. Rapid traverse rates of 945 IPM (24 m/min) provide efficient positioning, while the standard 60-tool automatic tool changer can be expanded with larger magazine options for highly automated production systems. The HM 1000 is widely used throughout the aerospace, mining, heavy equipment, energy, defense, oil & gas, and industrial machinery industries where large workpieces require maximum cutting performance and rigidity.
DN SOLUTIONS HM 1000 – AXIS
Specification
Details
X-Axis Travel
83 in (2,100 mm)
Y-Axis Travel
49 in (1,250 mm)
Z-Axis Travel
49 in (1,250 mm)
Axis Configuration
4-Axis Horizontal Machining Center
Rapid Traverse (X/Y/Z)
945 IPM (24 m/min)
Guideway Type
Heavy-Duty Box Guideways
DN SOLUTIONS HM 1000 – AXIS TRAVELS / WORK ENVELOPE
Purchasing a used DN Solutions HM 1000 allows manufacturers to acquire a large-frame heavy-duty horizontal machining center while significantly reducing capital investment. Its box guideway construction provides exceptional vibration damping, making it ideal for aggressive roughing operations, interrupted cuts, and machining large steel weldments, castings, and forged components. The gearbox-driven spindle delivers extremely high torque, allowing heavy material removal while maintaining excellent dimensional accuracy and surface finishes.
The shuttle-type automatic pallet changer enables continuous production by allowing operators to prepare the next workpiece while machining continues on the second pallet. Many used HM 1000 machines include valuable factory-installed options such as high-pressure through-spindle coolant, Renishaw probing systems, larger tool magazines, automatic tool measurement, and pallet automation, providing exceptional productivity while minimizing future upgrade costs. The reliable Fanuc CNC control ensures worldwide service support, easy programming, and dependable long-term operation.
HOW MUCH DOES A USED DN SOLUTIONS HM 1000 COST?
The price of a used DN Solutions HM 1000 depends on the year of manufacture, spindle hours, maintenance history, CNC control configuration, installed options, tooling packages, and overall machine condition.
Most used DN Solutions HM 1000 machines typically sell between $325,000 and $850,000, depending on age, spindle configuration, automation options, and machine condition. Machines equipped with the optional 8,000 RPM spindle, expanded tool magazines, high-pressure through-spindle coolant, probing systems, and documented maintenance records typically command higher resale values.
Before purchasing a used HM 1000, buyers should inspect spindle condition, box guideway wear, pallet changer operation, B-axis indexing accuracy, lubrication systems, automatic tool changer performance, coolant systems, and overall machine geometry. Transportation, rigging, installation, electrical work, tooling, and preventive maintenance should also be included when budgeting for ownership. Thanks to its heavy-duty construction, massive work envelope, and outstanding reliability, the HM 1000 continues to maintain strong resale value in the global used CNC market.
INDUSTRIES THAT USE DN SOLUTIONS HM 1000
Heavy Equipment Manufacturing
Aerospace Industry
Mining Equipment Manufacturing
Oil & Gas Industry
Wind Energy Equipment
Industrial Machinery
Defense Manufacturing
Power Generation
Precision Engineering
General Heavy Machining
TYPICAL PARTS DN SOLUTIONS HM 1000 CAN PRODUCE
Engine Blocks
Wind Turbine Components
Mining Equipment Parts
Gearbox Housings
Hydraulic Manifolds
Large Pump Housings
Valve Bodies
Aerospace Structural Components
Heavy Machine Frames
Industrial Castings
Energy Equipment Components
Precision Fixtures
WHY CHOOSE DN SOLUTIONS HM 1000
The DN Solutions HM 1000 is engineered for manufacturers that demand maximum rigidity, exceptional torque, and reliable heavy-duty machining performance on large workpieces. Its box guideway construction, high-torque gearbox-driven spindle, automatic twin-pallet system, expandable tool magazine, and advanced Fanuc CNC control make it one of the industry’s premier large-frame horizontal machining centers.
Whether machining heavy steel fabrications, aerospace structures, mining equipment, energy components, industrial machinery, or oil & gas equipment, the HM 1000 delivers outstanding cutting power, machining accuracy, durability, and production efficiency. Its rugged construction, automation-ready design, and excellent resale value continue to make it one of the most desirable used CNC horizontal machining centers available.
